LarsenBorgnakkeVariableHardSphere< CloudType > Class Template Reference

Variable Hard Sphere BinaryCollision Model with Larsen Borgnakke internal energy redistribution. Based on the INELRS subroutine in Bird's DSMC0R.FOR. More...

Inheritance diagram for LarsenBorgnakkeVariableHardSphere< CloudType >:

Collaboration diagram for LarsenBorgnakkeVariableHardSphere< CloudType >:

Public Member Functions
	TypeName ("LarsenBorgnakkeVariableHardSphere")
	Runtime type information. More...
	LarsenBorgnakkeVariableHardSphere (const dictionary &dict, CloudType &cloud)
	Construct from dictionary. More...
virtual	~LarsenBorgnakkeVariableHardSphere ()
	Destructor. More...
virtual scalar	sigmaTcR (const typename CloudType::parcelType &pP, const typename CloudType::parcelType &pQ) const
	Return the collision cross section * relative velocity product. More...
virtual void	collide (typename CloudType::parcelType &pP, typename CloudType::parcelType &pQ)
	Apply collision. More...
Public Member Functions inherited from BinaryCollisionModel< CloudType >
	TypeName ("BinaryCollisionModel")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, BinaryCollisionModel, dictionary,(const dictionary &dict, CloudType &owner),(dict, owner))
	Declare runtime constructor selection table. More...
	BinaryCollisionModel (CloudType &owner)
	Construct null from owner. More...
	BinaryCollisionModel (const dictionary &dict, CloudType &owner, const word &type)
	Construct from components. More...
virtual	~BinaryCollisionModel ()
	Destructor. More...
const CloudType &	owner () const
	Return the owner cloud object. More...
CloudType &	owner ()
	Return non-const access to the owner cloud object. More...
const dictionary &	dict () const
	Return the dictionary. More...
const dictionary &	coeffDict () const
	Return the coefficients dictionary. More...

Additional Inherited Members
Static Public Member Functions inherited from BinaryCollisionModel< CloudType >
static autoPtr< BinaryCollisionModel< CloudType > >	New (const dictionary &dict, CloudType &owner)
	Selector. More...

Detailed Description

template<class CloudType>
class Foam::LarsenBorgnakkeVariableHardSphere< CloudType >

Variable Hard Sphere BinaryCollision Model with Larsen Borgnakke internal energy redistribution. Based on the INELRS subroutine in Bird's DSMC0R.FOR.

Definition at line 46 of file LarsenBorgnakkeVariableHardSphere.H.

Constructor & Destructor Documentation

LarsenBorgnakkeVariableHardSphere()

LarsenBorgnakkeVariableHardSphere	(	const dictionary &	dict,
		CloudType &	cloud
	)

Construct from dictionary.

Definition at line 93 of file LarsenBorgnakkeVariableHardSphere.C.

~LarsenBorgnakkeVariableHardSphere()

~LarsenBorgnakkeVariableHardSphere

virtual

Destructor.

Definition at line 112 of file LarsenBorgnakkeVariableHardSphere.C.

Member Function Documentation

TypeName()

TypeName

(

"LarsenBorgnakkeVariableHardSphere< CloudType >"

)

Runtime type information.

sigmaTcR()

Foam::scalar sigmaTcR ( const typename CloudType::parcelType &  pP, const typename CloudType::parcelType &  pQ  ) const

virtual

Return the collision cross section * relative velocity product.

Implements BinaryCollisionModel< CloudType >.

Definition at line 120 of file LarsenBorgnakkeVariableHardSphere.C.

References Foam::exp(), k, Foam::lgamma(), Foam::mag(), Foam::constant::mathematical::pi(), and Foam::pow().

Here is the call graph for this function:

collide()

void collide ( typename CloudType::parcelType &  pP, typename CloudType::parcelType &  pQ  )

virtual

Apply collision.

Implements BinaryCollisionModel< CloudType >.

Definition at line 167 of file LarsenBorgnakkeVariableHardSphere.C.

References Foam::cos(), Foam::magSqr(), Foam::pow(), rndGen(), randomGenerator::scalar01(), Foam::sin(), Foam::sqrt(), and Foam::constant::mathematical::twoPi().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• src/lagrangian/DSMC/submodels/BinaryCollisionModel/LarsenBorgnakkeVariableHardSphere/LarsenBorgnakkeVariableHardSphere.H
• src/lagrangian/DSMC/submodels/BinaryCollisionModel/LarsenBorgnakkeVariableHardSphere/LarsenBorgnakkeVariableHardSphere.C
