SpalartAllmaras IDDES turbulence model for incompressible and compressible flows. More...

Inheritance diagram for SpalartAllmarasIDDES< BasicMomentumTransportModel >:

Collaboration diagram for SpalartAllmarasIDDES< BasicMomentumTransportModel >:

Public Types
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from SpalartAllmarasDES< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from LESeddyViscosity< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from eddyViscosity< LESModel< BasicMomentumTransportModel > >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from linearViscousStress< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Member Functions
	TypeName ("SpalartAllmarasIDDES")
	Runtime type information. More...

	SpalartAllmarasIDDES (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	SpalartAllmarasIDDES (const SpalartAllmarasIDDES &)=delete
	Disallow default bitwise copy construction. More...

virtual	~SpalartAllmarasIDDES ()
	Destructor. More...

virtual bool	read ()
	Read model coefficients if they have changed. More...

void	operator= (const SpalartAllmarasIDDES &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from SpalartAllmarasDES< BasicMomentumTransportModel >
	TypeName ("SpalartAllmarasDES")
	Runtime type information. More...

	SpalartAllmarasDES (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	SpalartAllmarasDES (const SpalartAllmarasDES &)=delete
	Disallow default bitwise copy construction. More...

virtual	~SpalartAllmarasDES ()
	Destructor. More...

tmp< volScalarField >	DnuTildaEff () const
	Return the effective diffusivity for nuTilda. More...

virtual tmp< volScalarField >	k () const
	Return SGS kinetic energy. More...

tmp< volScalarField >	nuTilda () const

virtual void	correct ()
	Correct nuTilda and related properties. More...

void	operator= (const SpalartAllmarasDES &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from LESeddyViscosity< BasicMomentumTransportModel >
	LESeddyViscosity (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

	LESeddyViscosity (const LESeddyViscosity &)=delete
	Disallow default bitwise copy construction. More...

virtual	~LESeddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	epsilon () const
	Return sub-grid disipation rate. More...

virtual tmp< volScalarField >	omega () const
	Return the turbulence specific dissipation rate. More...

void	operator= (const LESeddyViscosity &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from eddyViscosity< LESModel< BasicMomentumTransportModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~eddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual tmp< volSymmTensorField >	R () const
	Return the Reynolds stress tensor [m^2/s^2]. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

Public Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~linearViscousStress ()
	Destructor. More...

virtual tmp< surfaceVectorField >	devTau () const
	Return the effective surface stress. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

template<class RhoFieldType >
Foam::tmp< Foam::fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const

Protected Member Functions
virtual tmp< volScalarField::Internal >	dTilda (const volScalarField::Internal &chi, const volScalarField::Internal &fv1, const volTensorField::Internal &gradU) const
	Length scale. More...

Protected Member Functions inherited from SpalartAllmarasDES< BasicMomentumTransportModel >
tmp< volScalarField >	chi () const

tmp< volScalarField >	fv1 (const volScalarField &chi) const

tmp< volScalarField::Internal >	fv2 (const volScalarField::Internal &chi, const volScalarField::Internal &fv1) const

tmp< volScalarField::Internal >	Omega (const volTensorField::Internal &gradU) const

tmp< volScalarField::Internal >	Stilda (const volScalarField::Internal &chi, const volScalarField::Internal &fv1, const volScalarField::Internal &Omega, const volScalarField::Internal &dTilda) const

tmp< volScalarField::Internal >	r (const volScalarField::Internal &nur, const volScalarField::Internal &Omega, const volScalarField::Internal &dTilda) const

tmp< volScalarField::Internal >	fw (const volScalarField::Internal &Omega, const volScalarField::Internal &dTilda) const

virtual void	cacheLESRegion (const volScalarField::Internal &dTilda) const
	Cache the LES region indicator field. More...

void	correctNut (const volScalarField &fv1)

virtual void	correctNut ()

Protected Member Functions inherited from linearViscousStress< BasicMomentumTransportModel >
template<class RhoFieldType >
tmp< fvVectorMatrix >	DivDevTau (const RhoFieldType &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

Additional Inherited Members
Protected Attributes inherited from SpalartAllmarasDES< BasicMomentumTransportModel >
dimensionedScalar	sigmaNut_

dimensionedScalar	kappa_

dimensionedScalar	Cb1_

dimensionedScalar	Cb2_

dimensionedScalar	Cw1_

dimensionedScalar	Cw2_

dimensionedScalar	Cw3_

dimensionedScalar	Cv1_

dimensionedScalar	Cs_

dimensionedScalar	CDES_

dimensionedScalar	ck_

volScalarField	nuTilda_

Protected Attributes inherited from LESeddyViscosity< BasicMomentumTransportModel >
dimensionedScalar	Ck_

dimensionedScalar	Ce_

Protected Attributes inherited from eddyViscosity< LESModel< BasicMomentumTransportModel > >
volScalarField	nut_

Detailed Description

template<class BasicMomentumTransportModel>
class Foam::LESModels::SpalartAllmarasIDDES< BasicMomentumTransportModel >

SpalartAllmaras IDDES turbulence model for incompressible and compressible flows.

Reference:

    Shur, M. L., Spalart, P. R., Strelets, M. K., & Travin, A. K. (2008).
    A hybrid RANS-LES approach with delayed-DES and wall-modelled LES
    capabilities.
    International Journal of Heat and Fluid Flow, 29(6), 1638-1649.

Source files

Definition at line 61 of file SpalartAllmarasIDDES.H.

Member Typedef Documentation

◆ alphaField

typedef BasicMomentumTransportModel::alphaField alphaField

Definition at line 120 of file SpalartAllmarasIDDES.H.

◆ rhoField

typedef BasicMomentumTransportModel::rhoField rhoField

Definition at line 121 of file SpalartAllmarasIDDES.H.

Constructor & Destructor Documentation

◆ SpalartAllmarasIDDES() [1/2]

SpalartAllmarasIDDES	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity,
		const word &	type = `typeName`
	)

Construct from components.

Definition at line 218 of file SpalartAllmarasIDDES.C.

◆ SpalartAllmarasIDDES() [2/2]

SpalartAllmarasIDDES ( const SpalartAllmarasIDDES< BasicMomentumTransportModel > & )

delete

Disallow default bitwise copy construction.

◆ ~SpalartAllmarasIDDES()

virtual ~SpalartAllmarasIDDES ( )

inlinevirtual

Destructor.

Definition at line 147 of file SpalartAllmarasIDDES.H.

Member Function Documentation

◆ dTilda()

tmp< volScalarField::Internal > dTilda	(	const volScalarField::Internal &	chi,
		const volScalarField::Internal &	fv1,
		const volTensorField::Internal &	gradU
	)		const

protectedvirtual

Length scale.

Reimplemented from SpalartAllmarasDES< BasicMomentumTransportModel >.

Definition at line 125 of file SpalartAllmarasIDDES.C.

References alpha(), delta, Foam::dimLength, Foam::exp(), Foam::mag(), Foam::max(), Foam::min(), Foam::neg(), DimensionedField< Type, GeoMesh, PrimitiveField >::New(), Foam::pos0(), Foam::pow(), Foam::sqr(), Foam::sqrt(), Foam::typedName(), and y.

Here is the call graph for this function:

◆ TypeName()

TypeName ( "SpalartAllmarasIDDES< BasicMomentumTransportModel >" )

Runtime type information.

◆ read()

bool read

virtual

Read model coefficients if they have changed.

Reimplemented from SpalartAllmarasDES< BasicMomentumTransportModel >.

Definition at line 248 of file SpalartAllmarasIDDES.C.

◆ operator=()

void operator= ( const SpalartAllmarasIDDES< BasicMomentumTransportModel > & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/MomentumTransportModels/momentumTransportModels/LES/SpalartAllmarasIDDES/SpalartAllmarasIDDES.H
src/MomentumTransportModels/momentumTransportModels/LES/SpalartAllmarasIDDES/SpalartAllmarasIDDES.C
