JohnsonJacksonParticleThetaFvPatchScalarField Class Reference

Robin condition for the particulate granular temperature. More...

Inheritance diagram for JohnsonJacksonParticleThetaFvPatchScalarField:

Collaboration diagram for JohnsonJacksonParticleThetaFvPatchScalarField:

Public Member Functions
	TypeName ("JohnsonJacksonParticleTheta")
	Runtime type information. More...
	JohnsonJacksonParticleThetaFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...
	JohnsonJacksonParticleThetaFvPatchScalarField (const JohnsonJacksonParticleThetaFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fieldMapper &)
	Construct by mapping onto a new patch. More...
	JohnsonJacksonParticleThetaFvPatchScalarField (const JohnsonJacksonParticleThetaFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...
	JohnsonJacksonParticleThetaFvPatchScalarField (const JohnsonJacksonParticleThetaFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
	Copy constructor setting internal field reference. More...
virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, volMesh > &iF) const
	Construct and return a clone setting internal field reference. More...
virtual void	updateCoeffs ()
	Update the coefficients. More...
virtual void	write (Ostream &) const
	Write. More...

Detailed Description

Robin condition for the particulate granular temperature.

References:

    Reuge, N., Cadoret, L., Coufort-Saudejaud, C., Pannala, S., Syamlal, M.,
    & Caussat, B. (2008).
    Multifluid Eulerian modeling of dense gas–solids fluidised bed
    hydrodynamics: influence of the dissipation parameters.
    Chemical Engineering Science, 63(22), 5540-5551.

    Johnson, P. C., & Jackson, R. (1987).
    Frictional–collisional constitutive relations for granular materials,
    with application to plane shearing.
    Journal of fluid Mechanics, 176, 67-93.

Source files

• JohnsonJacksonParticleThetaFvPatchScalarField.H
• JohnsonJacksonParticleThetaFvPatchScalarField.C

Definition at line 64 of file JohnsonJacksonParticleThetaFvPatchScalarField.H.

Constructor & Destructor Documentation

JohnsonJacksonParticleThetaFvPatchScalarField() [1/4]

JohnsonJacksonParticleThetaFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 43 of file JohnsonJacksonParticleThetaFvPatchScalarField.C.

References Foam::abort(), dict, DimensionedField< Type, GeoMesh, PrimitiveField >::dimensions(), Foam::FatalError, FatalErrorInFunction, fvPatchField< Type >::operator, and p.

Referenced by JohnsonJacksonParticleThetaFvPatchScalarField::clone().

Here is the call graph for this function:

Here is the caller graph for this function:

JohnsonJacksonParticleThetaFvPatchScalarField() [2/4]

JohnsonJacksonParticleThetaFvPatchScalarField	(	const JohnsonJacksonParticleThetaFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, volMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping onto a new patch.

Definition at line 82 of file JohnsonJacksonParticleThetaFvPatchScalarField.C.

JohnsonJacksonParticleThetaFvPatchScalarField() [3/4]

JohnsonJacksonParticleThetaFvPatchScalarField ( const JohnsonJacksonParticleThetaFvPatchScalarField &  )

delete

Disallow copy without setting internal field reference.

JohnsonJacksonParticleThetaFvPatchScalarField() [4/4]

JohnsonJacksonParticleThetaFvPatchScalarField	(	const JohnsonJacksonParticleThetaFvPatchScalarField &	ptf,
		const DimensionedField< scalar, volMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 98 of file JohnsonJacksonParticleThetaFvPatchScalarField.C.

Member Function Documentation

TypeName()

TypeName

(

"JohnsonJacksonParticleTheta"

)

Runtime type information.

clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 116 of file JohnsonJacksonParticleThetaFvPatchScalarField.H.

References JohnsonJacksonParticleThetaFvPatchScalarField::JohnsonJacksonParticleThetaFvPatchScalarField().

Here is the call graph for this function:

updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients.

Definition at line 113 of file JohnsonJacksonParticleThetaFvPatchScalarField.C.

References alpha(), Foam::constant::universal::c, Foam::constant::atomic::group, IOobject::groupName(), Foam::constant::electromagnetic::kappa, Foam::magSqr(), Foam::max(), phaseSystem::phases(), Foam::constant::mathematical::pi(), Foam::pos0(), phaseSystem::propertiesName, Foam::sqr(), Foam::sqrt(), and U.

Here is the call graph for this function:

write()

void write ( Ostream &  os ) const

virtual

Write.

Definition at line 219 of file JohnsonJacksonParticleThetaFvPatchScalarField.C.

References fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• applications/modules/multiphaseEuler/momentumTransportModels/derivedFvPatchFields/JohnsonJacksonParticleTheta/JohnsonJacksonParticleThetaFvPatchScalarField.H
• applications/modules/multiphaseEuler/momentumTransportModels/derivedFvPatchFields/JohnsonJacksonParticleTheta/JohnsonJacksonParticleThetaFvPatchScalarField.C
