InertPhaseModel< BasePhaseModel > Class Template Reference

Class which represents an inert phase, with no reactions. Returns zero reaction rate and heat. More...

Inheritance diagram for InertPhaseModel< BasePhaseModel >:

Collaboration diagram for InertPhaseModel< BasePhaseModel >:

Public Member Functions
	InertPhaseModel (const phaseSystem &fluid, const word &phaseName, const bool referencePhase, const label index)
virtual	~InertPhaseModel ()
	Destructor. More...
virtual tmp< volScalarField::Internal >	R (const label speciei) const
	Return the consumption rate for a specie. More...
virtual tmp< fvScalarMatrix >	R (volScalarField &Yi) const
	Return consumption rate matrix for a specie. More...
virtual tmp< volScalarField >	Qdot () const
	Return the heat release rate. More...

Detailed Description

template<class BasePhaseModel>
class Foam::InertPhaseModel< BasePhaseModel >

Class which represents an inert phase, with no reactions. Returns zero reaction rate and heat.

Source files

• InertPhaseModel.H
• InertPhaseModel.C

Definition at line 50 of file InertPhaseModel.H.

Constructor & Destructor Documentation

InertPhaseModel()

InertPhaseModel	(	const phaseSystem &	fluid,
		const word &	phaseName,
		const bool	referencePhase,
		const label	index
	)

Definition at line 33 of file InertPhaseModel.C.

~InertPhaseModel()

~InertPhaseModel

virtual

Destructor.

Definition at line 48 of file InertPhaseModel.C.

Member Function Documentation

R() [1/2]

Foam::tmp< Foam::volScalarField::Internal > R ( const label  speciei ) const

virtual

Return the consumption rate for a specie.

Definition at line 56 of file InertPhaseModel.C.

References Foam::dimDensity, Foam::dimTime, IOobject::groupName(), mesh, Foam::name(), DimensionedField< Type, GeoMesh, PrimitiveField >::New(), and Y.

Here is the call graph for this function:

R() [2/2]

Foam::tmp< Foam::fvScalarMatrix > R ( volScalarField &  Yi ) const

virtual

Return consumption rate matrix for a specie.

Definition at line 70 of file InertPhaseModel.C.

References Foam::dimMass, and Foam::dimTime.

Qdot()

Foam::tmp< Foam::volScalarField > Qdot

virtual

Return the heat release rate.

Definition at line 81 of file InertPhaseModel.C.

References Foam::dimEnergy, Foam::dimTime, Foam::dimVolume, IOobject::groupName(), mesh, Foam::name(), and GeometricField< Type, GeoMesh, PrimitiveField >::New().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• applications/modules/multiphaseEuler/phaseSystem/phaseModels/InertPhaseModel/InertPhaseModel.H
• applications/modules/multiphaseEuler/phaseSystem/phaseModels/InertPhaseModel/InertPhaseModel.C
