Abstract base class for GAMG agglomerated interfaces. More...

Inheritance diagram for GAMGInterface:

[legend]

Collaboration diagram for GAMGInterface:

[legend]

Public Member Functions
	TypeName ("GAMGInterface")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, GAMGInterface, lduInterface,(const label index, const lduInterfacePtrsList &coarseInterfaces, const lduInterface &fineInterface, const labelField &localRestrictAddressing, const labelField &neighbourRestrictAddressing, const label fineLevelIndex, const label coarseComm),(index, coarseInterfaces, fineInterface, localRestrictAddressing, neighbourRestrictAddressing, fineLevelIndex, coarseComm))

	declareRunTimeSelectionTable (autoPtr, GAMGInterface, Istream,(const label index, const lduInterfacePtrsList &coarseInterfaces, Istream &is),(index, coarseInterfaces, is))

	GAMGInterface (const label index, const lduInterfacePtrsList &coarseInterfaces)
	Construct from interfaces, restrict addressing set later on. More...

	GAMGInterface (const label index, const lduInterfacePtrsList &coarseInterfaces, const labelUList &faceCells, const labelUList &faceRestrictAddressing)
	Construct from interfaces and restrict addressing. More...

	GAMGInterface (const label index, const lduInterfacePtrsList &coarseInterfaces, Istream &is)
	Construct from Istream. More...

	GAMGInterface (const GAMGInterface &)=delete
	Disallow default bitwise copy construction. More...

virtual label	size () const
	Return size. More...

virtual label	index () const

virtual const lduInterfacePtrsList &	coarseInterfaces () const

virtual const labelUList &	faceCells () const
	Return faceCell addressing. More...

virtual const labelList &	faceRestrictAddressing () const
	Return (local)face restrict addressing. More...

virtual labelList &	faceRestrictAddressing ()
	Return non-const access to face restrict addressing. More...

template<class Type >
tmp< Field< Type > >	interfaceInternalField (const UList< Type > &internalData) const
	Return the interface internal field of the given field. More...

template<class Type >
void	interfaceInternalField (const UList< Type > &internalData, List< Type > &) const
	Get the interface internal field of the given field. More...

virtual tmp< labelField >	interfaceInternalField (const labelUList &internalData) const
	Return the values of the given internal data adjacent to. More...

void	combine (const GAMGInterface &)
	Merge the next level with this level. More...

virtual tmp< scalarField >	agglomerateCoeffs (const scalarField &fineCoeffs) const
	Agglomerating the given fine-level coefficients and return. More...

virtual void	write (Ostream &) const =0
	Write to stream. More...

void	operator= (const GAMGInterface &)=delete
	Disallow default bitwise assignment. More...

template<class Type >
Foam::tmp< Foam::Field< Type > >	interfaceInternalField (const UList< Type > &iF) const

Public Member Functions inherited from lduInterface
	TypeName ("lduInterface")
	Runtime type information. More...

	lduInterface ()
	Construct null. More...

	lduInterface (const lduInterface &)=delete
	Disallow default bitwise copy construction. More...

virtual	~lduInterface ()
	Destructor. More...

virtual void	initInternalFieldTransfer (const Pstream::commsTypes commsType, const labelUList &iF) const
	Initialise transfer of internal field adjacent to the interface. More...

virtual tmp< labelField >	internalFieldTransfer (const Pstream::commsTypes commsType, const labelUList &iF) const =0
	Transfer and return internal field adjacent to the interface. More...

void	operator= (const lduInterface &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< GAMGInterface >	New (const label index, const lduInterfacePtrsList &coarseInterfaces, const lduInterface &fineInterface, const labelField &localRestrictAddressing, const labelField &neighbourRestrictAddressing, const label fineLevelIndex, const label coarseComm)
	Return a pointer to a new interface created on freestore given. More...

static autoPtr< GAMGInterface >	New (const word &coupleType, const label index, const lduInterfacePtrsList &coarseInterfaces, Istream &is)
	Return a pointer to a new interface created on freestore given. More...

Protected Attributes
const label	index_
	My index in coarseInterfaces. More...

const lduInterfacePtrsList &	coarseInterfaces_
	All interfaces. More...

labelList	faceCells_
	Face-cell addressing. More...

labelList	faceRestrictAddressing_
	Face restrict addressing. More...

Detailed Description

Abstract base class for GAMG agglomerated interfaces.

Source files

Definition at line 51 of file GAMGInterface.H.

Constructor & Destructor Documentation

◆ GAMGInterface() [1/4]

GAMGInterface	(	const label	index,
		const lduInterfacePtrsList &	coarseInterfaces
	)

inline

Construct from interfaces, restrict addressing set later on.

Definition at line 153 of file GAMGInterface.H.

◆ GAMGInterface() [2/4]

GAMGInterface	(	const label	index,
		const lduInterfacePtrsList &	coarseInterfaces,
		const labelUList &	faceCells,
		const labelUList &	faceRestrictAddressing
	)

inline

Construct from interfaces and restrict addressing.

Definition at line 165 of file GAMGInterface.H.

◆ GAMGInterface() [3/4]

GAMGInterface	(	const label	index,
		const lduInterfacePtrsList &	coarseInterfaces,
		Istream &	is
	)

Construct from Istream.

Definition at line 40 of file GAMGInterface.C.

◆ GAMGInterface() [4/4]

GAMGInterface ( const GAMGInterface & )

delete

Disallow default bitwise copy construction.

Member Function Documentation

◆ TypeName()

TypeName ( "GAMGInterface" )

Runtime type information.

◆ declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable	(	autoPtr	,
		GAMGInterface	,
		lduInterface	,
		(const label index, const lduInterfacePtrsList &coarseInterfaces, const lduInterface &fineInterface, const labelField &localRestrictAddressing, const labelField &neighbourRestrictAddressing, const label fineLevelIndex, const label coarseComm)	,
		(index, coarseInterfaces, fineInterface, localRestrictAddressing, neighbourRestrictAddressing, fineLevelIndex, coarseComm)
	)

◆ declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable	(	autoPtr	,
		GAMGInterface	,
		Istream	,
		(const label index, const lduInterfacePtrsList &coarseInterfaces, Istream &is)	,
		(index, coarseInterfaces, is)
	)

◆ New() [1/2]

Foam::autoPtr< Foam::GAMGInterface > New	(	const label	index,
		const lduInterfacePtrsList &	coarseInterfaces,
		const lduInterface &	fineInterface,
		const labelField &	localRestrictAddressing,
		const labelField &	neighbourRestrictAddressing,
		const label	fineLevelIndex,
		const label	coarseComm
	)

static

Return a pointer to a new interface created on freestore given.

the fine interface

Definition at line 33 of file GAMGInterfaceNew.C.

References GAMGInterface::coarseInterfaces(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, and GAMGInterface::index().

Referenced by GAMGAgglomeration::agglomerateLduAddressing(), GAMGSolver::GAMGSolver(), and lduPrimitiveMesh::gather().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ New() [2/2]

Foam::autoPtr< Foam::GAMGInterface > New	(	const word &	coupleType,
		const label	index,
		const lduInterfacePtrsList &	coarseInterfaces,
		Istream &	is
	)

static

Return a pointer to a new interface created on freestore given.

the fine interface

Definition at line 74 of file GAMGInterfaceNew.C.

References Foam::exit(), Foam::FatalError, and FatalErrorInFunction.

Here is the call graph for this function:

◆ size()

virtual label size ( ) const

inlinevirtual

Return size.

Definition at line 197 of file GAMGInterface.H.

References GAMGInterface::faceCells_, and List< T >::size().

Referenced by GAMGInterface::interfaceInternalField(), cyclicGAMGInterfaceField::size(), and processorGAMGInterfaceField::size().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ index()

virtual label index ( ) const

inlinevirtual

Definition at line 202 of file GAMGInterface.H.

References GAMGInterface::index_.

Referenced by GAMGInterface::New().

Here is the caller graph for this function:

◆ coarseInterfaces()

virtual const lduInterfacePtrsList& coarseInterfaces ( ) const

inlinevirtual

Definition at line 207 of file GAMGInterface.H.

References GAMGInterface::coarseInterfaces_.

Referenced by GAMGInterface::New().

Here is the caller graph for this function:

◆ faceCells()

virtual const labelUList& faceCells ( ) const

inlinevirtual

Return faceCell addressing.

Implements lduInterface.

Definition at line 213 of file GAMGInterface.H.

References GAMGInterface::faceCells_.

Referenced by cyclicGAMGInterface::internalFieldTransfer().

Here is the caller graph for this function:

◆ faceRestrictAddressing() [1/2]

virtual const labelList& faceRestrictAddressing ( ) const

inlinevirtual

Return (local)face restrict addressing.

Definition at line 219 of file GAMGInterface.H.

References GAMGInterface::faceRestrictAddressing_.

◆ faceRestrictAddressing() [2/2]

virtual labelList& faceRestrictAddressing ( )

inlinevirtual

Return non-const access to face restrict addressing.

Definition at line 225 of file GAMGInterface.H.

References GAMGInterface::faceRestrictAddressing_.

◆ interfaceInternalField() [1/4]

tmp<Field<Type> > interfaceInternalField ( const UList< Type > & internalData ) const

Return the interface internal field of the given field.

Referenced by GAMGInterface::interfaceInternalField().

Here is the caller graph for this function:

◆ interfaceInternalField() [2/4]

void interfaceInternalField	(	const UList< Type > &	internalData,
		List< Type > &	result
	)		const

Get the interface internal field of the given field.

Definition at line 43 of file GAMGInterfaceTemplates.C.

References forAll, and List< T >::setSize().

Here is the call graph for this function:

◆ interfaceInternalField() [3/4]

Foam::tmp< Foam::labelField > interfaceInternalField ( const labelUList & internalData ) const

virtual

Return the values of the given internal data adjacent to.

the interface as a field

Implements lduInterface.

Definition at line 69 of file GAMGInterface.C.

◆ combine()

void combine ( const GAMGInterface & coarseGi )

Merge the next level with this level.

combining the face-restrict addressing and copying the face-cell addressing

Definition at line 56 of file GAMGInterface.C.

References GAMGInterface::faceCells_, GAMGInterface::faceRestrictAddressing_, and forAll.

Referenced by GAMGAgglomeration::combineLevels().

Here is the caller graph for this function:

◆ agglomerateCoeffs()

Foam::tmp< Foam::scalarField > agglomerateCoeffs ( const scalarField & fineCoeffs ) const

virtual

Agglomerating the given fine-level coefficients and return.

Definition at line 78 of file GAMGInterface.C.

References Foam::abort(), Foam::FatalError, FatalErrorInFunction, forAll, Foam::max(), tmp< T >::ref(), and List< T >::size().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

pure virtual

Write to stream.

Implemented in processorGAMGInterface, and cyclicGAMGInterface.

Definition at line 112 of file GAMGInterface.C.

References token::SPACE.

Referenced by cyclicGAMGInterface::write(), and processorGAMGInterface::write().

Here is the caller graph for this function:

◆ operator=()

void operator= ( const GAMGInterface & )

delete

Disallow default bitwise assignment.

◆ interfaceInternalField() [4/4]

Foam::tmp<Foam::Field<Type> > interfaceInternalField ( const UList< Type > & iF ) const

Definition at line 31 of file GAMGInterfaceTemplates.C.

References GAMGInterface::interfaceInternalField(), tmp< T >::ref(), and GAMGInterface::size().

Here is the call graph for this function:

Member Data Documentation

◆ index_

const label index_

protected

My index in coarseInterfaces.

Definition at line 61 of file GAMGInterface.H.

Referenced by GAMGInterface::index().

◆ coarseInterfaces_

const lduInterfacePtrsList& coarseInterfaces_

protected

All interfaces.

Definition at line 64 of file GAMGInterface.H.

Referenced by GAMGInterface::coarseInterfaces(), and cyclicGAMGInterface::nbrPatch().

◆ faceCells_

labelList faceCells_

protected

Face-cell addressing.

Definition at line 67 of file GAMGInterface.H.

Referenced by GAMGInterface::combine(), cyclicGAMGInterface::cyclicGAMGInterface(), GAMGInterface::faceCells(), processorGAMGInterface::processorGAMGInterface(), and GAMGInterface::size().

◆ faceRestrictAddressing_

labelList faceRestrictAddressing_

protected

Face restrict addressing.

Definition at line 70 of file GAMGInterface.H.

Referenced by GAMGInterface::combine(), cyclicGAMGInterface::cyclicGAMGInterface(), GAMGInterface::faceRestrictAddressing(), and processorGAMGInterface::processorGAMGInterface().

The documentation for this class was generated from the following files:

src/OpenFOAM/matrices/lduMatrix/solvers/GAMG/interfaces/GAMGInterface/GAMGInterface.H
src/OpenFOAM/matrices/lduMatrix/solvers/GAMG/interfaces/GAMGInterface/GAMGInterface.C
src/OpenFOAM/matrices/lduMatrix/solvers/GAMG/interfaces/GAMGInterface/GAMGInterfaceNew.C
src/OpenFOAM/matrices/lduMatrix/solvers/GAMG/interfaces/GAMGInterface/GAMGInterfaceTemplates.C

Public Member Functions

Static Public Member Functions

Protected Attributes

Detailed Description

Constructor & Destructor Documentation

◆ GAMGInterface() [1/4]

◆ GAMGInterface() [2/4]

◆ GAMGInterface() [3/4]

◆ GAMGInterface() [4/4]

Member Function Documentation

◆ TypeName()

◆ declareRunTimeSelectionTable() [1/2]

◆ declareRunTimeSelectionTable() [2/2]

◆ New() [1/2]

◆ New() [2/2]

◆ size()

◆ index()

◆ coarseInterfaces()

◆ faceCells()

◆ faceRestrictAddressing() [1/2]

◆ faceRestrictAddressing() [2/2]

◆ interfaceInternalField() [1/4]

◆ interfaceInternalField() [2/4]

◆ interfaceInternalField() [3/4]

◆ combine()

◆ agglomerateCoeffs()

◆ write()

◆ operator=()

◆ interfaceInternalField() [4/4]

Member Data Documentation

◆ index_

◆ coarseInterfaces_

◆ faceCells_

◆ faceRestrictAddressing_
