Tabulated property function that linearly interpolates between the UniformTable values. More...

Inheritance diagram for UniformTable< Type >:

Collaboration diagram for UniformTable< Type >:

Public Member Functions
	TypeName ("uniformTable")
	Runtime type information. More...

	UniformTable (const word &name, const unitConversions &units, const dictionary &dict)
	Construct from name and dictionary. More...

virtual Type	value (scalar x) const
	Evaluate the function and return the result. More...

virtual Type	integral (const scalar x1, const scalar x2) const
	Integrate between two scalar values. More...

void	write (Ostream &os, const unitConversions &units) const
	Write the function coefficients. More...

Public Member Functions inherited from FieldFunction1< Type, UniformTable< Type > >
	FieldFunction1 (const word &name)
	Construct from name. More...

virtual tmp< Function1< Type > >	clone () const
	Construct and return a clone. More...

virtual	~FieldFunction1 ()
	Destructor. More...

virtual tmp< Field< Type > >	value (const scalarField &x) const
	Return value as a function of one scalar field. More...

virtual tmp< Field< Type > >	integral (const scalarField &x1, const scalarField &x2) const
	Integrate between two scalar fields. More...

Public Member Functions inherited from Function1< Type >
	TypeName ("Function1")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, Function1, dictionary,(const word &name, const Function1s::unitConversions &units, const dictionary &dict),(name, units, dict))

	declareRunTimeSelectionTable (autoPtr, Function1, Istream,(const word &name, const Function1s::unitConversions &units, Istream &is),(name, units, is))

	Function1 (const word &name)
	Construct from name. More...

	Function1 (const Function1< Type > &f1)
	Copy constructor. More...

virtual	~Function1 ()
	Destructor. More...

const word &	name () const
	Return the name of the entry. More...

virtual bool	constant () const
	Is this function guaranteed to be constant? More...

void	operator= (const Function1< Type > &)
	Assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Additional Inherited Members
Public Types inherited from Function1< Type >
typedef Type	returnType

Static Public Member Functions inherited from Function1< Type >
static autoPtr< Function1< Type > >	New (const word &name, const Function1s::unitConversions &units, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function1< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &valueUnits, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function1< Type > >	New (const word &name, const Function1s::unitConversions &units, const word &Function1Type, Istream &is)
	Select from Istream. More...

static autoPtr< Function1< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &valueUnits, const word &Function1Type, Istream &is)
	Select from Istream. More...

Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Protected Attributes inherited from Function1< Type >
const word	name_
	Name of entry. More...

Detailed Description

template<class Type>
class Foam::Function1s::UniformTable< Type >

Tabulated property function that linearly interpolates between the UniformTable values.

Usage

Property	Description
`low`	Lower limit of the table
`high`	Upper limit of the table
`values`	Values, assumed uniformly distributed

Example for the density of water between 280 and 350K

    rho
    {
        type    uniformTable;

        low    280;
        high   350;

        values
        (
            999.87
            991.53
            973.7
        );
    }

Definition at line 87 of file UniformTable1.H.
