Function1 which repeats a given 'value' function with a given period or frequency, and with an optional shift along the x-axis. More...

Inheritance diagram for Repeat< Type >:

[legend]

Collaboration diagram for Repeat< Type >:

[legend]

Public Member Functions
	TypeName ("repeat")

	Repeat (const word &name, const unitConversions &units, const dictionary &dict)
	Construct from name and dictionary. More...

	Repeat (const Repeat< Type > &se)
	Copy constructor. More...

virtual	~Repeat ()
	Destructor. More...

virtual Type	value (const scalar x) const
	Return value. More...

virtual Type	integral (const scalar x1, const scalar x2) const
	Integrate between two values. More...

virtual void	write (Ostream &os, const unitConversions &units) const
	Write data to dictionary stream. More...

void	operator= (const Repeat< Type > &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from FieldFunction1< Type, Repeat< Type > >
	FieldFunction1 (const word &name)
	Construct from name. More...

virtual tmp< Function1< Type > >	clone () const
	Construct and return a clone. More...

virtual	~FieldFunction1 ()
	Destructor. More...

virtual tmp< Field< Type > >	value (const scalarField &x) const
	Return value as a function of one scalar field. More...

virtual tmp< Field< Type > >	integral (const scalarField &x1, const scalarField &x2) const
	Integrate between two scalar fields. More...

Public Member Functions inherited from Function1< Type >
	TypeName ("Function1")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, Function1, dictionary,(const word &name, const Function1s::unitConversions &units, const dictionary &dict),(name, units, dict))

	declareRunTimeSelectionTable (autoPtr, Function1, Istream,(const word &name, const Function1s::unitConversions &units, Istream &is),(name, units, is))

	Function1 (const word &name)
	Construct from name. More...

	Function1 (const Function1< Type > &f1)
	Copy constructor. More...

virtual	~Function1 ()
	Destructor. More...

const word &	name () const
	Return the name of the entry. More...

virtual bool	constant () const
	Is this function guaranteed to be constant? More...

void	operator= (const Function1< Type > &)
	Assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Additional Inherited Members
Public Types inherited from Function1< Type >
typedef Type	returnType

Static Public Member Functions inherited from Function1< Type >
static autoPtr< Function1< Type > >	New (const word &name, const Function1s::unitConversions &units, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function1< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &valueUnits, const dictionary &dict)
	Select from dictionary. More...

static autoPtr< Function1< Type > >	New (const word &name, const Function1s::unitConversions &units, const word &Function1Type, Istream &is)
	Select from Istream. More...

static autoPtr< Function1< Type > >	New (const word &name, const unitConversion &xUnits, const unitConversion &valueUnits, const word &Function1Type, Istream &is)
	Select from Istream. More...

Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Protected Attributes inherited from Function1< Type >
const word	name_
	Name of entry. More...

Detailed Description

template<class Type>
class Foam::Function1s::Repeat< Type >

Function1 which repeats a given 'value' function with a given period or frequency, and with an optional shift along the x-axis.

Usage

Example:

    <name>
    {
        type    repeat;

        period  360 [CAD];

        //frequency 0.00277778 [CAD^-1]; // <-- alternative to specifying
                                         //     the period

        start   10 [CAD];                // <-- optional shift

        value
        {
            type    table;
            file    "constant/timeVsFlowRate.foam";
            units   ([ms] [m^3/s]);
        }
    }

Where:
