GeometricScalarField.H File Reference

Scalar specific part of the implementation of GeometricField. More...

Include dependency graph for GeometricScalarField.H:

This graph shows which files directly or indirectly include this file:

Go to the source code of this file.

Namespaces
	Foam
	Namespace for OpenFOAM.

Macros
#define	TEMPLATE
#define	TEMPLATE2
#define	TEMPLATE3
#define	BesselFunc(func)

Functions
template<class Type , class GeoMesh , template< class > class PrimitiveField1, template< class > class PrimitiveField2>
void	stabilise (GeometricField< scalar, GeoMesh, PrimitiveField1 > &result, const GeometricField< scalar, GeoMesh, PrimitiveField2 > &gsf, const dimensioned< scalar > &ds)
template<class Type , class GeoMesh , template< class > class PrimitiveField>
tmp< GeometricField< scalar, GeoMesh, Field > >	stabilise (const GeometricField< scalar, GeoMesh, PrimitiveField > &gsf, const dimensioned< scalar > &ds)
template<class Type , class GeoMesh , template< class > class PrimitiveField>
tmp< GeometricField< scalar, GeoMesh, Field > >	stabilise (const tmp< GeometricField< scalar, GeoMesh, PrimitiveField >> &tgsf, const dimensioned< scalar > &ds)
template<class Type , class GeoMesh , template< class > class PrimitiveField1, template< class > class PrimitiveField2>
void	jn (GeometricField< scalar, GeoMesh, PrimitiveField1 > &gsf, const int n, const GeometricField< scalar, GeoMesh, PrimitiveField2 > &gsf1)
template<class Type , class GeoMesh , template< class > class PrimitiveField>
tmp< GeometricField< scalar, GeoMesh, Field > >	jn (const int n, const GeometricField< scalar, GeoMesh, PrimitiveField > &gsf)
template<class Type , class GeoMesh , template< class > class PrimitiveField>
tmp< GeometricField< scalar, GeoMesh, Field > >	jn (const int n, const tmp< GeometricField< scalar, GeoMesh, PrimitiveField >> &tgsf)
template<class Type , class GeoMesh , template< class > class PrimitiveField1, template< class > class PrimitiveField2>
void	yn (GeometricField< scalar, GeoMesh, PrimitiveField1 > &gsf, const int n, const GeometricField< scalar, GeoMesh, PrimitiveField2 > &gsf1)
template<class Type , class GeoMesh , template< class > class PrimitiveField>
tmp< GeometricField< scalar, GeoMesh, Field > >	yn (const int n, const GeometricField< scalar, GeoMesh, PrimitiveField > &gsf)
template<class Type , class GeoMesh , template< class > class PrimitiveField>
tmp< GeometricField< scalar, GeoMesh, Field > >	yn (const int n, const tmp< GeometricField< scalar, GeoMesh, PrimitiveField >> &tgsf)

Detailed Description

Scalar specific part of the implementation of GeometricField.

Original source file GeometricScalarField.H

InClass Foam::GeometricScalarField

Source files

• GeometricScalarField.H
• GeometricScalarField.C

Definition in file GeometricScalarField.H.

Macro Definition Documentation

TEMPLATE

#define TEMPLATE

Value:

    template                                                                   \
    <                                                                          \
        class Type,                                                            \
        class GeoMesh,                                                         \
        template<class> class PrimitiveField                                   \
    >

Definition at line 41 of file GeometricScalarField.H.

TEMPLATE2

#define TEMPLATE2

Value:

    template                                                                   \
    <                                                                          \
        class Type,                                                            \
        class GeoMesh,                                                         \
        template<class> class PrimitiveField1,                                 \
        template<class> class PrimitiveField2                                  \
    >

Definition at line 48 of file GeometricScalarField.H.

TEMPLATE3

#define TEMPLATE3

Value:

    template                                                                   \
    <                                                                          \
        class Type,                                                            \
        class GeoMesh,                                                         \
        template<class> class PrimitiveField1,                                 \
        template<class> class PrimitiveField2                                  \
        template<class> class PrimitiveField3                                  \
    >

Definition at line 56 of file GeometricScalarField.H.

BesselFunc

#define BesselFunc

(

func

)

Value:

                                                                               \
TEMPLATE2                                                                      \
void func                                                                      \
(                                                                              \
    GeometricField<scalar, GeoMesh, PrimitiveField1>& Res,                     \
    const int n,                                                               \
    const GeometricField<scalar, GeoMesh, PrimitiveField2>& sf                 \
);                                                                             \
                                                                               \
TEMPLATE                                                                       \
tmp<GeometricField<scalar, GeoMesh, Field>> func                               \
(                                                                              \
    const int n,                                                               \
    const GeometricField<scalar, GeoMesh, PrimitiveField>&                     \
);                                                                             \
                                                                               \
TEMPLATE                                                                       \
tmp<GeometricField<scalar, GeoMesh, Field>> func                               \
(                                                                              \
    const int n,                                                               \
    const tmp<GeometricField<scalar, GeoMesh, PrimitiveField>>&                \
);

Definition at line 157 of file GeometricScalarField.H.
