nutkWallFunctionFvPatchScalarField Class Reference

Turbulent viscosity wall-function boundary condition for high Reynolds number flows based on near-wall turbulence kinetic energy. More...

Inheritance diagram for nutkWallFunctionFvPatchScalarField:
Collaboration diagram for nutkWallFunctionFvPatchScalarField:

Public Member Functions

 TypeName ("nutkWallFunction")
 Runtime type information. More...

 nutkWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
 Construct from patch and internal field. More...

 nutkWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 nutkWallFunctionFvPatchScalarField (const nutkWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
 Construct by mapping given. More...

 nutkWallFunctionFvPatchScalarField (const nutkWallFunctionFvPatchScalarField &)=delete
 Disallow copy without setting internal field reference. More...

 nutkWallFunctionFvPatchScalarField (const nutkWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarFieldclone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

virtual tmp< scalarFieldyPlus () const
 Calculate and return the yPlus at the boundary. More...

- Public Member Functions inherited from nutWallFunctionFvPatchScalarField
 TypeName ("nutWallFunction")
 Runtime type information. More...

 nutWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &)
 Construct from patch and internal field. More...

 nutWallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
 Construct by mapping given. More...

 nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &)=delete
 Disallow copy without setting internal field reference. More...

 nutWallFunctionFvPatchScalarField (const nutWallFunctionFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

scalar Cmu () const
 Return Cmu. More...

scalar kappa () const
 Return kappa. More...

scalar E () const
 Return E. More...

scalar yPlusLam () const
 Return the Y+ at the edge of the laminar sublayer. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Protected Member Functions

virtual tmp< scalarFieldnut () const
 Calculate the turbulence viscosity. More...

- Protected Member Functions inherited from nutWallFunctionFvPatchScalarField
virtual void checkType ()
 Check the type of the patch. More...

virtual void writeLocalEntries (Ostream &) const
 Write local wall function variables. More...


Additional Inherited Members

- Static Public Member Functions inherited from nutWallFunctionFvPatchScalarField
static const nutWallFunctionFvPatchScalarFieldnutw (const momentumTransportModel &turbModel, const label patchi)
 Return the nut patchField for the given wall patch. More...

static scalar yPlusLam (const scalar kappa, const scalar E)
 Calculate the Y+ at the edge of the laminar sublayer. More...

- Protected Attributes inherited from nutWallFunctionFvPatchScalarField
scalar Cmu_
 Cmu coefficient. More...

scalar kappa_
 Von Karman constant. More...

scalar E_
 E coefficient. More...

scalar yPlusLam_
 Y+ at the edge of the laminar sublayer. More...


Detailed Description

Turbulent viscosity wall-function boundary condition for high Reynolds number flows based on near-wall turbulence kinetic energy.

Usage
Example of the boundary condition specification:
<patchName>
{
    type            nutkWallFunction;
    value           uniform 0;
}
See also
Foam::nutWallFunctionFvPatchScalarField
Source files

Definition at line 62 of file nutkWallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ nutkWallFunctionFvPatchScalarField() [1/5]

nutkWallFunctionFvPatchScalarField ( const fvPatch p,
const DimensionedField< scalar, volMesh > &  iF
)

Construct from patch and internal field.

Definition at line 84 of file nutkWallFunctionFvPatchScalarField.C.

Referenced by nutkWallFunctionFvPatchScalarField::clone(), nutkWallFunctionFvPatchScalarField::nut(), and nutkWallFunctionFvPatchScalarField::nutkWallFunctionFvPatchScalarField().

Here is the caller graph for this function:

◆ nutkWallFunctionFvPatchScalarField() [2/5]

nutkWallFunctionFvPatchScalarField ( const fvPatch p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary dict
)

Construct from patch, internal field and dictionary.

Definition at line 94 of file nutkWallFunctionFvPatchScalarField.C.

References nutkWallFunctionFvPatchScalarField::nutkWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ nutkWallFunctionFvPatchScalarField() [3/5]

nutkWallFunctionFvPatchScalarField ( const nutkWallFunctionFvPatchScalarField ptf,
const fvPatch p,
const DimensionedField< scalar, volMesh > &  iF,
const fvPatchFieldMapper mapper
)

Construct by mapping given.

nutkWallFunctionFvPatchScalarField onto a new patch

Definition at line 105 of file nutkWallFunctionFvPatchScalarField.C.

References nutkWallFunctionFvPatchScalarField::nutkWallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ nutkWallFunctionFvPatchScalarField() [4/5]

Disallow copy without setting internal field reference.

◆ nutkWallFunctionFvPatchScalarField() [5/5]

Copy constructor setting internal field reference.

Definition at line 117 of file nutkWallFunctionFvPatchScalarField.C.

Member Function Documentation

◆ nut()

◆ TypeName()

TypeName ( "nutkWallFunction"  )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Reimplemented in nutkAtmRoughWallFunctionFvPatchScalarField, nutkRoughWallFunctionFvPatchScalarField, and nutkFilmWallFunctionFvPatchScalarField.

Definition at line 123 of file nutkWallFunctionFvPatchScalarField.H.

References nutkWallFunctionFvPatchScalarField::nutkWallFunctionFvPatchScalarField(), and nutkWallFunctionFvPatchScalarField::yPlus().

Here is the call graph for this function:

◆ yPlus()


The documentation for this class was generated from the following files:
