k-epsilon model for the gas-phase in a two-phase system supporting phase-inversion. More...

Inheritance diagram for continuousGasKEpsilon< BasicMomentumTransportModel >:

Collaboration diagram for continuousGasKEpsilon< BasicMomentumTransportModel >:

Public Types
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from kEpsilon< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Types inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
typedef RASModel< BasicMomentumTransportModel > ::alphaField	alphaField

typedef RASModel< BasicMomentumTransportModel > ::rhoField	rhoField

Public Types inherited from linearViscousStress< RASModel< BasicMomentumTransportModel > >
typedef RASModel< BasicMomentumTransportModel > ::alphaField	alphaField

typedef RASModel< BasicMomentumTransportModel > ::rhoField	rhoField

Public Types inherited from RASModel< BasicMomentumTransportModel >
typedef BasicMomentumTransportModel::alphaField	alphaField

typedef BasicMomentumTransportModel::rhoField	rhoField

Public Member Functions
	TypeName ("continuousGasKEpsilon")
	Runtime type information. More...

	continuousGasKEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	continuousGasKEpsilon (const continuousGasKEpsilon &)=delete
	Disallow default bitwise copy construction. More...

virtual	~continuousGasKEpsilon ()
	Destructor. More...

virtual bool	read ()
	Re-read model coefficients if they have changed. More...

const momentumTransportModel &	liquidTurbulence () const
	Return the turbulence model for the liquid phase. More...

virtual tmp< volScalarField >	nuEff () const
	Return the effective viscosity. More...

virtual tmp< volScalarField >	rhoEff () const
	Return the effective density for the stress. More...

virtual tmp< volSymmTensorField >	sigma () const
	Return the stress tensor [m^2/s^2]. More...

void	operator= (const continuousGasKEpsilon &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from kEpsilon< BasicMomentumTransportModel >
	TypeName ("kEpsilon")
	Runtime type information. More...

	kEpsilon (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity, const word &type=typeName)
	Construct from components. More...

	kEpsilon (const kEpsilon &)=delete
	Disallow default bitwise copy construction. More...

virtual	~kEpsilon ()
	Destructor. More...

tmp< volScalarField >	DkEff () const
	Return the effective diffusivity for k. More...

tmp< volScalarField >	DepsilonEff () const
	Return the effective diffusivity for epsilon. More...

virtual tmp< volScalarField >	k () const
	Return the turbulence kinetic energy. More...

virtual tmp< volScalarField >	epsilon () const
	Return the turbulence kinetic energy dissipation rate. More...

virtual tmp< volScalarField >	omega () const
	Return the turbulence specific dissipation rate. More...

virtual void	correct ()
	Solve the turbulence equations and correct the turbulence viscosity. More...

void	operator= (const kEpsilon &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
	eddyViscosity (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~eddyViscosity ()
	Destructor. More...

virtual tmp< volScalarField >	nut () const
	Return the turbulence viscosity. More...

virtual tmp< scalarField >	nut (const label patchi) const
	Return the turbulence viscosity on patch. More...

virtual void	validate ()
	Validate the turbulence fields after construction. More...

Public Member Functions inherited from linearViscousStress< RASModel< BasicMomentumTransportModel > >
	linearViscousStress (const word &modelName, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

virtual	~linearViscousStress ()
	Destructor. More...

virtual tmp< volSymmTensorField >	devTau () const
	Return the effective stress tensor. More...

virtual tmp< fvVectorMatrix >	divDevTau (volVectorField &U) const
	Return the source term for the momentum equation. More...

virtual tmp< fvVectorMatrix >	divDevTau (const volScalarField &rho, volVectorField &U) const
	Return the source term for the momentum equation. More...

Public Member Functions inherited from RASModel< BasicMomentumTransportModel >
	TypeName ("RAS")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, RASModel, dictionary,(const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity),(alpha, rho, U, alphaRhoPhi, phi, viscosity))

	RASModel (const word &type, const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Construct from components. More...

	RASModel (const RASModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~RASModel ()
	Destructor. More...

const dimensionedScalar &	kMin () const
	Return the lower allowable limit for k (default: small) More...

const dimensionedScalar &	epsilonMin () const
	Return the lower allowable limit for epsilon (default: small) More...

const dimensionedScalar &	omegaMin () const
	Return the lower allowable limit for omega (default: small) More...

dimensionedScalar &	kMin ()
	Allow kMin to be changed. More...

dimensionedScalar &	epsilonMin ()
	Allow epsilonMin to be changed. More...

dimensionedScalar &	omegaMin ()
	Allow omegaMin to be changed. More...

virtual const dictionary &	coeffDict () const
	Const access to the coefficients dictionary. More...

virtual tmp< volScalarField >	nu () const
	Return the laminar viscosity. More...

virtual tmp< scalarField >	nu (const label patchi) const
	Return the laminar viscosity on patchi. More...

virtual tmp< scalarField >	nuEff (const label patchi) const
	Return the effective viscosity on patch. More...

void	operator= (const RASModel &)=delete
	Disallow default bitwise assignment. More...

Protected Member Functions
virtual void	correctNut ()

tmp< volScalarField >	phaseTransferCoeff () const

virtual tmp< fvScalarMatrix >	kSource () const

virtual tmp< fvScalarMatrix >	epsilonSource () const

Protected Member Functions inherited from RASModel< BasicMomentumTransportModel >
virtual void	printCoeffs (const word &type)
	Print model coefficients. More...

Protected Attributes
dimensionedScalar	alphaInversion_

Protected Attributes inherited from kEpsilon< BasicMomentumTransportModel >
dimensionedScalar	Cmu_

dimensionedScalar	C1_

dimensionedScalar	C2_

dimensionedScalar	C3_

dimensionedScalar	sigmak_

dimensionedScalar	sigmaEps_

volScalarField	k_

volScalarField	epsilon_

Protected Attributes inherited from eddyViscosity< RASModel< BasicMomentumTransportModel > >
volScalarField	nut_

Protected Attributes inherited from RASModel< BasicMomentumTransportModel >
dictionary	RASDict_
	RAS coefficients dictionary. More...

Switch	turbulence_
	Turbulence on/off flag. More...

Switch	printCoeffs_
	Flag to print the model coeffs at run-time. More...

dictionary	coeffDict_
	Model coefficients dictionary. More...

dimensionedScalar	kMin_
	Lower limit of k. More...

dimensionedScalar	epsilonMin_
	Lower limit of epsilon. More...

dimensionedScalar	omegaMin_
	Lower limit for omega. More...

autoPtr< laminarModels::generalisedNewtonianViscosityModel >	viscosityModel_
	Run-time selectable generalised Newtonian viscosity model. More...

Additional Inherited Members
Static Public Member Functions inherited from RASModel< BasicMomentumTransportModel >
static autoPtr< RASModel >	New (const alphaField &alpha, const rhoField &rho, const volVectorField &U, const surfaceScalarField &alphaRhoPhi, const surfaceScalarField &phi, const viscosity &viscosity)
	Return a reference to the selected RAS model. More...

Detailed Description

template<class BasicMomentumTransportModel>
class Foam::RASModels::continuousGasKEpsilon< BasicMomentumTransportModel >

k-epsilon model for the gas-phase in a two-phase system supporting phase-inversion.

In the limit that the gas-phase fraction approaches zero a contribution from the other phase is blended into the k and epsilon equations up to the phase-fraction of alphaInversion at which point phase-inversion is considered to have occurred and the model reverts to the pure single-phase form.

This model is unpublished and is provided as a stable numerical framework on which a more physical model may be built.

The default model coefficients are

    continuousGasKEpsilonCoeffs
    {
        Cmu             0.09;
        C1              1.44;
        C2              1.92;
        C3              0;
        sigmak          1.0;
        sigmaEps        1.3;
        alphaInversion  0.7;
    }

Source files

Definition at line 75 of file continuousGasKEpsilon.H.

Member Typedef Documentation

◆ alphaField

typedef BasicMomentumTransportModel::alphaField alphaField

Definition at line 105 of file continuousGasKEpsilon.H.

◆ rhoField

typedef BasicMomentumTransportModel::rhoField rhoField

Definition at line 106 of file continuousGasKEpsilon.H.

Constructor & Destructor Documentation

◆ continuousGasKEpsilon() [1/2]

continuousGasKEpsilon	(	const alphaField &	alpha,
		const rhoField &	rho,
		const volVectorField &	U,
		const surfaceScalarField &	alphaRhoPhi,
		const surfaceScalarField &	phi,
		const viscosity &	viscosity,
		const word &	type = `typeName`
	)

Construct from components.

Definition at line 44 of file continuousGasKEpsilon.C.

◆ continuousGasKEpsilon() [2/2]

continuousGasKEpsilon ( const continuousGasKEpsilon< BasicMomentumTransportModel > & )

delete

Disallow default bitwise copy construction.

◆ ~continuousGasKEpsilon()

virtual ~continuousGasKEpsilon ( )

inlinevirtual

Destructor.

Definition at line 132 of file continuousGasKEpsilon.H.

References continuousGasKEpsilon< BasicMomentumTransportModel >::liquidTurbulence(), continuousGasKEpsilon< BasicMomentumTransportModel >::nuEff(), continuousGasKEpsilon< BasicMomentumTransportModel >::operator=(), continuousGasKEpsilon< BasicMomentumTransportModel >::read(), continuousGasKEpsilon< BasicMomentumTransportModel >::rhoEff(), and continuousGasKEpsilon< BasicMomentumTransportModel >::sigma().

Here is the call graph for this function:

Member Function Documentation

◆ correctNut()

void correctNut ( )

protectedvirtual

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 116 of file continuousGasKEpsilon.C.

References kEpsilon< BasicMomentumTransportModel >::correctNut(), dispersedVirtualMassModel::Cvm(), phaseModel::d(), momentumTransportModel::epsilon(), Foam::exp(), fluid, phaseModel::fluid(), momentumTransportModel::k(), Foam::min(), dictionary::New(), fluidThermo::nu(), momentumTransportModel::nut(), phaseModel::rho(), Foam::sqr(), and phaseModel::thermo().

Here is the call graph for this function:

◆ phaseTransferCoeff()

tmp< volScalarField > phaseTransferCoeff ( ) const

protected

Definition at line 229 of file continuousGasKEpsilon.C.

References TimeState::deltaT(), momentumTransportModel::epsilon(), momentumTransportModel::k(), Foam::max(), Foam::min(), and IOobject::time().

Here is the call graph for this function:

◆ kSource()

tmp< fvScalarMatrix > kSource ( ) const

protectedvirtual

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 252 of file continuousGasKEpsilon.C.

References momentumTransportModel::k(), and Foam::fvm::Sp().

Here is the call graph for this function:

◆ epsilonSource()

tmp< fvScalarMatrix > epsilonSource ( ) const

protectedvirtual

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 265 of file continuousGasKEpsilon.C.

References momentumTransportModel::epsilon(), and Foam::fvm::Sp().

Here is the call graph for this function:

◆ TypeName()

TypeName ( "continuousGasKEpsilon< BasicMomentumTransportModel >" )

Runtime type information.

◆ read()

bool read ( )

virtual

Re-read model coefficients if they have changed.

Reimplemented from kEpsilon< BasicMomentumTransportModel >.

Definition at line 100 of file continuousGasKEpsilon.C.

Referenced by continuousGasKEpsilon< BasicMomentumTransportModel >::~continuousGasKEpsilon().

Here is the caller graph for this function:

◆ liquidTurbulence()

const momentumTransportModel & liquidTurbulence ( ) const

Return the turbulence model for the liquid phase.

Definition at line 154 of file continuousGasKEpsilon.C.

References IOobject::db(), fluid, phaseModel::fluid(), IOobject::groupName(), objectRegistry::lookupObject(), and phaseModel::name().

Referenced by continuousGasKEpsilon< BasicMomentumTransportModel >::~continuousGasKEpsilon().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ nuEff()

tmp< Foam::volScalarField > nuEff ( ) const

virtual

Return the effective viscosity.

Reimplemented from RASModel< BasicMomentumTransportModel >.

Definition at line 181 of file continuousGasKEpsilon.C.

References IOobject::groupName(), Foam::max(), Foam::min(), and GeometricField< scalar, fvPatchField, volMesh >::New().

Referenced by continuousGasKEpsilon< BasicMomentumTransportModel >::~continuousGasKEpsilon().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ rhoEff()

tmp< Foam::volScalarField > rhoEff ( ) const

virtual

Return the effective density for the stress.

Definition at line 208 of file continuousGasKEpsilon.C.

References dispersedVirtualMassModel::Cvm(), fluid, phaseModel::fluid(), IOobject::groupName(), GeometricField< scalar, fvPatchField, volMesh >::New(), and phaseModel::rho().

Referenced by continuousGasKEpsilon< BasicMomentumTransportModel >::~continuousGasKEpsilon().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ sigma()

tmp< volSymmTensorField > sigma ( ) const

virtual

Return the stress tensor [m^2/s^2].

Reimplemented from eddyViscosity< RASModel< BasicMomentumTransportModel > >.

Definition at line 278 of file continuousGasKEpsilon.C.

References Foam::dev(), Foam::fvc::grad(), IOobject::groupName(), Foam::I, k, GeometricField< symmTensor, fvPatchField, volMesh >::New(), and Foam::twoSymm().

Referenced by continuousGasKEpsilon< BasicMomentumTransportModel >::~continuousGasKEpsilon().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ operator=()

void operator= ( const continuousGasKEpsilon< BasicMomentumTransportModel > & )

delete

Disallow default bitwise assignment.

Referenced by continuousGasKEpsilon< BasicMomentumTransportModel >::~continuousGasKEpsilon().

Here is the caller graph for this function:

Member Data Documentation

◆ alphaInversion_

dimensionedScalar alphaInversion_

protected

Definition at line 92 of file continuousGasKEpsilon.H.

The documentation for this class was generated from the following files:

src/MomentumTransportModels/phaseCompressible/RAS/continuousGasKEpsilon/continuousGasKEpsilon.H
src/MomentumTransportModels/phaseCompressible/RAS/continuousGasKEpsilon/continuousGasKEpsilon.C

Public Types

Public Member Functions

Protected Member Functions

Protected Attributes

Additional Inherited Members

Detailed Description

template<class BasicMomentumTransportModel> class Foam::RASModels::continuousGasKEpsilon< BasicMomentumTransportModel >

Member Typedef Documentation

◆ alphaField

◆ rhoField

Constructor & Destructor Documentation

◆ continuousGasKEpsilon() [1/2]

◆ continuousGasKEpsilon() [2/2]

◆ ~continuousGasKEpsilon()

Member Function Documentation

◆ correctNut()

◆ phaseTransferCoeff()

◆ kSource()

◆ epsilonSource()

◆ TypeName()

◆ read()

◆ liquidTurbulence()

◆ nuEff()

◆ rhoEff()

◆ sigma()

◆ operator=()

Member Data Documentation

◆ alphaInversion_

template<class BasicMomentumTransportModel>
class Foam::RASModels::continuousGasKEpsilon< BasicMomentumTransportModel >
