Foam::Lagrangianm Namespace Reference

Functions
template<class Type >
bool	initDdt (const dimensionSet &mDims, const LagrangianSubSubField< Type > &psi, const bool instantaneousDdt=false)
	Initialise time-derivative information. Registers fields used to. More...
template<class Type , template< class > class PrimitiveField>
bool	initDdt (const dimensionSet &mDims, const LagrangianSubField< Type, PrimitiveField > &psi, const bool instantaneousDdt=false)
	Initialise time-derivative information. Registers fields used to. More...
template<class Type >
tmp< LagrangianEqn< Type > >	noDdt (const LagrangianSubScalarField &deltaT, const dimensionSet &mDims, const LagrangianSubSubField< Type > &psi)
	Return the no-time-derivative matrix containing higher-order. More...
template<class Type , template< class > class PrimitiveField>
tmp< LagrangianEqn< Type > >	noDdt (const LagrangianSubScalarField &deltaT, const dimensionSet &mDims, const LagrangianSubField< Type, PrimitiveField > &psi)
	Return the no-time-derivative matrix containing higher-order. More...
template<class Type >
tmp< LagrangianEqn< Type > >	Ddt (const LagrangianSubScalarField &deltaT, LagrangianSubSubField< Type > &psi)
	Return the time-derivative matrix. More...
template<class Type >
tmp< LagrangianEqn< Type > >	Ddt (const LagrangianSubScalarField &deltaT, const LagrangianSubScalarSubField &m, LagrangianSubSubField< Type > &psi)
	Return the time-derivative matrix. More...
template<class Type >
tmp< LagrangianEqn< Type > >	ddt (const LagrangianSubSubField< Type > &psi)
	Return a Euler implicit time derivative matrix. More...
template<class Type >
tmp< LagrangianEqn< Type > >	ddt (const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &psi)
	Return a Euler implicit time derivative matrix. More...
template<class Type >
tmp< LagrangianEqn< Type > >	ddt0 (const LagrangianSubSubField< Type > &psi)
	Return a Euler explicit/forward time derivative matrix. More...
template<class Type >
tmp< LagrangianEqn< Type > >	ddt0 (const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &psi)
	Return a Euler explicit/forward time derivative matrix. More...
template<class Type , class SpType >
tmp< LagrangianEqn< Type > >	Sp (const LagrangianSubField< SpType > &Sp, const LagrangianSubSubField< Type > &psi)
	Return a source matrix. More...
template<class Type , class SpType , template< class > class PrimitiveField>
tmp< LagrangianEqn< Type > >	Sp (const LagrangianSubField< SpType > &Sp, const LagrangianSubField< Type, PrimitiveField > &psi)
	Return a source matrix. More...
template<class Type >
tmp< LagrangianEqn< Type > >	explicitSp0 (const LagrangianSubScalarField &Sp, const LagrangianSubSubField< Type > &psi)
template<class Type >
tmp< LagrangianEqn< Type > >	explicitSp0 (const LagrangianSubScalarField &Sp, const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &psi)
template<class Type >
tmp< LagrangianEqn< Type > >	implicitDeltaTSp (const LagrangianSubScalarField &Sp, const LagrangianSubSubField< Type > &psi)

Function Documentation

initDdt() [1/2]

bool initDdt	(	const dimensionSet &	mDims,
		const LagrangianSubSubField< Type > &	psi,
		const bool	instantaneousDdt = false
	)

Initialise time-derivative information. Registers fields used to.

construct for higher-order schemes and to evaluate instantaneous time derivatives.

Definition at line 34 of file LagrangianmDdt.C.

References fvSchemes::ddt(), mesh, Foam::New(), psi, and fvMesh::schemes().

Referenced by initDdt(), coupled::initPsicDdt(), dynamicParcel::reCalculateModified(), dynamicParticle::reCalculateModified(), kinematicParcel::reCalculateModified(), kinematicParticle::reCalculateModified(), multicomponentParcel::reCalculateModified(), multicomponentParticle::reCalculateModified(), parcel::reCalculateModified(), and particle::reCalculateModified().

Here is the call graph for this function:

Here is the caller graph for this function:

initDdt() [2/2]

bool initDdt	(	const dimensionSet &	mDims,
		const LagrangianSubField< Type, PrimitiveField > &	psi,
		const bool	instantaneousDdt = false
	)

Initialise time-derivative information. Registers fields used to.

construct for higher-order schemes and to evaluate instantaneous time derivatives.

Definition at line 53 of file LagrangianmDdt.C.

References initDdt(), psi, and Foam::toSubField().

Here is the call graph for this function:

noDdt() [1/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::noDdt	(	const LagrangianSubScalarField &	deltaT,
		const dimensionSet &	mDims,
		const LagrangianSubSubField< Type > &	psi
	)

Return the no-time-derivative matrix containing higher-order.

modifications to source terms

Referenced by coupled::psicEqn().

Here is the caller graph for this function:

noDdt() [2/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::noDdt	(	const LagrangianSubScalarField &	deltaT,
		const dimensionSet &	mDims,
		const LagrangianSubField< Type, PrimitiveField > &	psi
	)

Return the no-time-derivative matrix containing higher-order.

modifications to source terms

Ddt() [1/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::Ddt	(	const LagrangianSubScalarField &	deltaT,
		LagrangianSubSubField< Type > &	psi
	)

Return the time-derivative matrix.

Referenced by dynamicParcel::calculate(), dynamicParticle::calculate(), kinematicParcel::calculate(), kinematicParticle::calculate(), multicomponentParcel::calculate(), multicomponentParticle::calculate(), parcel::calculate(), and particle::calculate().

Here is the caller graph for this function:

Ddt() [2/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::Ddt	(	const LagrangianSubScalarField &	deltaT,
		const LagrangianSubScalarSubField &	m,
		LagrangianSubSubField< Type > &	psi
	)

Return the time-derivative matrix.

ddt() [1/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::ddt

(

const LagrangianSubSubField< Type > &

psi

)

Return a Euler implicit time derivative matrix.

ddt() [2/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::ddt	(	const LagrangianSubScalarSubField &	m,
		const LagrangianSubSubField< Type > &	psi
	)

Return a Euler implicit time derivative matrix.

ddt0() [1/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::ddt0

(

const LagrangianSubSubField< Type > &

psi

)

Return a Euler explicit/forward time derivative matrix.

Referenced by pressureWork::addSup(), CrankNicolsonDdtScheme< Type >::ddt0_(), CrankNicolsonDdtScheme< Type >::fvcDdt(), CrankNicolsonDdtScheme< Type >::fvcDdtPhiCorr(), CrankNicolsonDdtScheme< Type >::fvcDdtUfCorr(), and CrankNicolsonDdtScheme< Type >::fvmDdt().

Here is the caller graph for this function:

ddt0() [2/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::ddt0	(	const LagrangianSubScalarSubField &	m,
		const LagrangianSubSubField< Type > &	psi
	)

Return a Euler explicit/forward time derivative matrix.

Sp() [1/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::Sp	(	const LagrangianSubField< SpType > &	Sp,
		const LagrangianSubSubField< Type > &	psi
	)

Return a source matrix.

Referenced by heatTransfer::addSup().

Here is the caller graph for this function:

Sp() [2/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::Sp	(	const LagrangianSubField< SpType > &	Sp,
		const LagrangianSubField< Type, PrimitiveField > &	psi
	)

Return a source matrix.

explicitSp0() [1/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::explicitSp0	(	const LagrangianSubScalarField &	Sp,
		const LagrangianSubSubField< Type > &	psi
	)

explicitSp0() [2/2]

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::explicitSp0	(	const LagrangianSubScalarField &	Sp,
		const LagrangianSubScalarSubField &	m,
		const LagrangianSubSubField< Type > &	psi
	)

implicitDeltaTSp()

tmp<LagrangianEqn<Type> > Foam::Lagrangianm::implicitDeltaTSp	(	const LagrangianSubScalarField &	Sp,
		const LagrangianSubSubField< Type > &	psi
	)
