A zoneGenerator which prints pointZones and/or cellZone and/or faceZones from the mesh. More...
Public Member Functions | |
| TypeName ("print") | |
| Runtime type information. More... | |
| print (const word &name, const polyMesh &mesh, const dictionary &dict) | |
| Construct from dictionary. More... | |
| virtual | ~print () |
| Destructor. More... | |
| virtual zoneSet | generate () const |
| Generate and return the zoneSet. More... | |
 Public Member Functions inherited from zoneGenerator | |
| TypeName ("zoneGenerator") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, zoneGenerator, dictionary,(const word &name, const polyMesh &mesh, const dictionary &dict),(name, mesh, dict)) | |
| zoneGenerator (const word &name, const polyMesh &mesh, const dictionary &dict) | |
| Construct from name, polyMesh and dictionary. More... | |
| zoneGenerator (const zoneGenerator &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~zoneGenerator () |
| Destructor. More... | |
| const word & | name () const |
| Return the zoneGenerator name. More... | |
| const word & | zoneName () const |
| Return the zone name. More... | |
| const polyMesh & | mesh () const |
| Return reference to the polyMesh. More... | |
| bool | moveUpdate () const |
| Return true if the zoneGenerator updates any of the zones. More... | |
| virtual zoneSet | movePoints () const |
| Regenerate the zoneSet following mesh point motion. More... | |
| void | operator= (const zoneGenerator &)=delete |
| Disallow default bitwise assignment. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from zoneGenerator | |
| static autoPtr< zoneGenerator > | New (const word &name, const polyMesh &mesh, const dictionary &dict) |
| Select constructed from name, mesh and dictionary. More... | |
| static autoPtr< zoneGenerator > | New (const word &name, const zoneTypes &zoneType, const polyMesh &mesh, const dictionary &dict) |
| Select constructed from name, zoneType, mesh and dictionary. More... | |
| static autoPtr< zoneGenerator > | New (const polyMesh &mesh, const dictionary &dict) |
| Select constructed from mesh and first valid dictionary. More... | |
| static labelList | indices (const boolList &selected) |
| Return the list of selected indices. More... | |
| Protected Attributes inherited from zoneGenerator | |
| const word | name_ |
| Name of zone generator. More... | |
| const dictionary | dict_ |
| Dictionary cached for error context. More... | |
| const word | zoneName_ |
| Name of the zone (defaults to the name of the generator) More... | |
| const polyMesh & | mesh_ |
| Reference to the polyMesh. More... | |
| bool | moveUpdate_ |
| Switch to update the zones if the mesh points are moved. More... | |
A zoneGenerator which prints pointZones and/or cellZone and/or faceZones from the mesh.
| Property | Description | Required | Default value |
|---|---|---|---|
type | Type: print | yes | |
zoneType | Type of zone | no | all |
zone | Name of the zone to print | no | |
zones | List of zone names to print | no | |
geometry | Print the geometry? | no | true |
Example:
printCellZones
{
type print;
}
| ( | const word & | name, | |
| const polyMesh & | mesh, | ||
| const dictionary & | dict | ||
| ) |
| TypeName | ( | "print" | ) |
Runtime type information.
|
virtual |
Generate and return the zoneSet.
Implements zoneGenerator.
Definition at line 82 of file print.C.
References Foam::all, DynamicList< T, SizeInc, SizeMult, SizeDiv >::append(), boundSphere::c(), Foam::cell, cells, DynamicList< T, SizeInc, SizeMult, SizeDiv >::clear(), Foam::endl(), Foam::face, forAll, boundSphere::global(), Foam::Info, HashSet< Key, Hash >::insert(), boundBox::max(), boundBox::min(), Foam::name(), Foam::nl, Foam::point, points, boundSphere::r(), Foam::reduce(), Foam::returnReduce(), List< T >::size(), HashTable< T, Key, Hash >::toc(), and VectorSpace< Form, Cmpt, Ncmpts >::zero.
