Public Member Functions | Protected Attributes | List of all members
variableHeightFlowRateFvPatchScalarField Class Reference

This boundary condition provides a phase fraction condition based on the local flow conditions, whereby the values are constrained to lay between user-specified upper and lower bounds. The behaviour is described by: More...

Inheritance diagram for variableHeightFlowRateFvPatchScalarField:
Inheritance graph
[legend]
Collaboration diagram for variableHeightFlowRateFvPatchScalarField:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("variableHeightFlowRate")
 Runtime scalar information. More...

 variableHeightFlowRateFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 variableHeightFlowRateFvPatchScalarField (const variableHeightFlowRateFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
 Construct by mapping given. More...

 variableHeightFlowRateFvPatchScalarField (const variableHeightFlowRateFvPatchScalarField &)=delete
 Disallow copy without setting internal field reference. More...

 variableHeightFlowRateFvPatchScalarField (const variableHeightFlowRateFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< fvPatchField< scalar > > clone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Protected Attributes

word phiName_
 Name of flux field. More...

scalar lowerBound_
 Lower bound for alpha1. More...

scalar upperBound_
 Upper bound for alpha1. More...


Detailed Description

This boundary condition provides a phase fraction condition based on the local flow conditions, whereby the values are constrained to lay between user-specified upper and lower bounds. The behaviour is described by:

if alpha > upperBound:

  • apply a fixed value condition, with a uniform level of the upper bound

if lower bound <= alpha <= upper bound:

  • apply a zero-gradient condition

if alpha < lowerBound:

  • apply a fixed value condition, with a uniform level of the lower bound
Usage
Property Description Required Default value
phi flux field name no phi
lowerBound lower bound for clipping yes
upperBound upper bound for clipping yes

Example of the boundary condition specification:

    <patchName>
    {
        type            variableHeightFlowRate;
        lowerBound      0.0;
        upperBound      0.9;
        value           uniform 0;
    }
Source files

Definition at line 98 of file variableHeightFlowRateFvPatchField.H.

Constructor & Destructor Documentation

◆ variableHeightFlowRateFvPatchScalarField() [1/4]

variableHeightFlowRateFvPatchScalarField ( const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary &  dict
)

Construct from patch, internal field and dictionary.

Definition at line 34 of file variableHeightFlowRateFvPatchField.C.

References dict, fvPatchField< Type >::operator, fvPatchField< Type >::operator=(), and p.

Referenced by variableHeightFlowRateFvPatchScalarField::clone().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ variableHeightFlowRateFvPatchScalarField() [2/4]

variableHeightFlowRateFvPatchScalarField ( const variableHeightFlowRateFvPatchScalarField &  ptf,
const fvPatch &  p,
const DimensionedField< scalar, volMesh > &  iF,
const fvPatchFieldMapper &  mapper
)

Construct by mapping given.

variableHeightFlowRateFvPatchScalarField onto a new patch

Definition at line 66 of file variableHeightFlowRateFvPatchField.C.

◆ variableHeightFlowRateFvPatchScalarField() [3/4]

variableHeightFlowRateFvPatchScalarField ( const variableHeightFlowRateFvPatchScalarField &  )
delete

Disallow copy without setting internal field reference.

◆ variableHeightFlowRateFvPatchScalarField() [4/4]

variableHeightFlowRateFvPatchScalarField ( const variableHeightFlowRateFvPatchScalarField &  ptf,
const DimensionedField< scalar, volMesh > &  iF
)

Copy constructor setting internal field reference.

Definition at line 82 of file variableHeightFlowRateFvPatchField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "variableHeightFlowRate"  )

Runtime scalar information.

◆ clone()

virtual tmp<fvPatchField<scalar> > clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 157 of file variableHeightFlowRateFvPatchField.H.

References variableHeightFlowRateFvPatchScalarField::variableHeightFlowRateFvPatchScalarField().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Update the coefficients associated with the patch field.

Definition at line 98 of file variableHeightFlowRateFvPatchField.C.

References forAll.

◆ write()

void write ( Ostream &  os) const
virtual

Write.

Definition at line 141 of file variableHeightFlowRateFvPatchField.C.

References fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:

Member Data Documentation

◆ phiName_

word phiName_
protected

Name of flux field.

Definition at line 108 of file variableHeightFlowRateFvPatchField.H.

◆ lowerBound_

scalar lowerBound_
protected

Lower bound for alpha1.

Definition at line 111 of file variableHeightFlowRateFvPatchField.H.

◆ upperBound_

scalar upperBound_
protected

Upper bound for alpha1.

Definition at line 114 of file variableHeightFlowRateFvPatchField.H.

The documentation for this class was generated from the following files:
