Unit conversion structure. Contains the associated dimensions and the multiplier with which to convert values. More...

Inheritance diagram for unitSet:

Collaboration diagram for unitSet:

Classes
struct	makeStandardOp
	Functor to convert to standard. More...

struct	makeUserOp
	Functor to convert to user. More...

Public Types
enum	{ nDimlessUnits = 2 }
	Define an enumeration for the number of dimensionless units. More...

enum	dimlessUnitType { FRACTION , ANGLE }
	Define an enumeration for the names of the dimensionless unit. More...

Public Member Functions
	ClassName ("unitSet")
	Run time type information. More...

	unitSet (const dimensionSet &, const scalar fraction, const scalar angle, const scalar multiplier)
	Construct from components. More...

	unitSet (const dimensionSet &)
	Construct from a dimension set. No dimensionless units. Unity. More...

	unitSet (const unitSet &)=default
	Copy constructor. More...

	unitSet (unitSet &&)=default
	Move constructor. More...

	unitSet (Istream &is)
	Construct from stream. More...

const dimensionSet &	dimensions () const
	Access the dimensions. More...

bool	dimensionless () const
	Return true if it is dimensionless. More...

template<class T >
T	toStandard (const T &) const
	Convert a value to standard units. More...

template<class T >
void	makeStandard (T &) const
	Convert a value to standard units. More...

template<class T >
T	toUser (const T &) const
	Convert a value to user units. More...

template<class T >
void	makeUser (T &) const
	Convert a value to user units. More...

bool	any () const
	Return whether this is the "any" unit. I.e., the case where. More...

bool	none () const
	Return whether this is the "none" unit. I.e., the case where unit. More...

bool	standard () const
	Return whether this unit is standard. I.e., is its multiplier one? More...

void	reset (const unitSet &)
	Reset the unit conversion. More...

void	read (const word &keyword, const dictionary &)
	Update. More...

void	read (Istream &is)
	Update. More...

void	read (const word &keyword, const dictionary &, Istream &is)
	Update. More...

bool	readIfPresent (const word &keyword, const dictionary &)
	Update if found in the dictionary. More...

bool	readIfPresent (Istream &is)
	Update if found on the stream. More...

bool	readIfPresent (const word &keyword, const dictionary &, Istream &is)
	Update if found on the dictionary stream. More...

InfoProxy< unitSet >	info () const
	Return info proxy. More...

scalar	operator[] (const dimensionSet::dimensionType type) const
	Access the dimension exponents. More...

scalar	operator[] (const dimlessUnitType type) const
	Access the dimensionless unit exponents. More...

void	operator= (const unitSet &)=delete
	Disallow default bitwise assignment. More...

void	operator= (const unitSet &&)=delete
	Disallow default bitwise move assignment. More...

Static Public Member Functions
static unitSet	newUnitless ()
	Return a new "unitless" unit set. More...

static unitSet	newAny ()
	Return a new "any" unit set. More...

static unitSet	newNone ()
	Return a new "none" unit set. More...

Static Public Attributes
static const NamedEnum< dimlessUnitType, 2 > &	dimlessUnitTypeNames_ = dimlessUnitTypeNamesPtr_()
	Names of the dimensionless units. More...

static const scalar	smallExponent = rootSmall
	A small exponent with which to perform inexact comparisons. More...

Friends
unitSet	pow (const unitSet &, const scalar)
	Raise to a power. More...

const unitSet &	operator+ (const unitSet &, const unitSet &)
	Combine. More...

unitSet	operator* (const unitSet &, const unitSet &)
	Multiply. More...

unitSet	operator/ (const unitSet &, const unitSet &)
	Divide. More...

Istream &	operator>> (Istream &, unitSet &)
	Read from stream. More...

Ostream &	operator<< (Ostream &, const unitSet &)
	Write to stream. More...

Ostream &	operator<< (Ostream &, const InfoProxy< unitSet > &)
	Write info to stream. More...

Detailed Description

Unit conversion structure. Contains the associated dimensions and the multiplier with which to convert values.

Source files

Definition at line 67 of file unitSet.H.

Member Enumeration Documentation

◆ anonymous enum

anonymous enum

Define an enumeration for the number of dimensionless units.

Enumerator
nDimlessUnits

Definition at line 74 of file unitSet.H.

◆ dimlessUnitType

enum dimlessUnitType

Define an enumeration for the names of the dimensionless unit.

exponents

Enumerator
FRACTION
ANGLE

Definition at line 81 of file unitSet.H.

Constructor & Destructor Documentation

◆ unitSet() [1/5]

unitSet	(	const dimensionSet &	dimensions,
		const scalar	fraction,
		const scalar	angle,
		const scalar	multiplier
	)

Construct from components.

Definition at line 89 of file unitSet.C.

References unitSet::ANGLE, Foam::units::fraction, and unitSet::FRACTION.

Referenced by unitSet::newUnitless().

Here is the caller graph for this function:

◆ unitSet() [2/5]

unitSet ( const dimensionSet & dimensions )

Construct from a dimension set. No dimensionless units. Unity.

multiplier.

Definition at line 105 of file unitSet.C.

References unitSet::ANGLE, and unitSet::FRACTION.

◆ unitSet() [3/5]

unitSet ( const unitSet & )

default

Copy constructor.

◆ unitSet() [4/5]

unitSet ( unitSet && )

default

Move constructor.

◆ unitSet() [5/5]

unitSet ( Istream & is )

Construct from stream.

Definition at line 33 of file unitSetIO.C.

Member Function Documentation

◆ ClassName()

ClassName ( "unitSet" )

Run time type information.

◆ newUnitless()

Foam::unitSet newUnitless ( )

inlinestatic

Return a new "unitless" unit set.

Definition at line 30 of file unitSetI.H.

References unitSet::unitSet().

Here is the call graph for this function:

◆ newAny()

Foam::unitSet newAny ( )

inlinestatic

Return a new "any" unit set.

Definition at line 36 of file unitSetI.H.

Referenced by Foam::readAndConvert().

Here is the caller graph for this function:

◆ newNone()

Foam::unitSet newNone ( )

inlinestatic

Return a new "none" unit set.

Definition at line 42 of file unitSetI.H.

◆ dimensions()

const Foam::dimensionSet & dimensions ( ) const

inline

Access the dimensions.

Definition at line 50 of file unitSetI.H.

Referenced by Foam::dimensionedConstant().

Here is the caller graph for this function:

◆ dimensionless()

bool dimensionless ( ) const

inline

Return true if it is dimensionless.

Definition at line 56 of file unitSetI.H.

◆ toStandard()

T toStandard ( const T & t ) const

Convert a value to standard units.

Definition at line 33 of file unitSetTemplates.C.

References unitSet::standard().

Referenced by TableReader< Coordinate, Value >::convertRead(), Foam::degToRad(), and Foam::dimensionedConstant().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ makeStandard()

void makeStandard ( T & t ) const

Convert a value to standard units.

Definition at line 40 of file unitSetTemplates.C.

Referenced by unitSet::makeStandardOp::operator()().

Here is the caller graph for this function:

◆ toUser()

T toUser ( const T & t ) const

Convert a value to user units.

Definition at line 50 of file unitSetTemplates.C.

Referenced by greyMean::aCont(), wideBand::aCont(), TableReader< Coordinate, Value >::convertWrite(), Foam::radToDeg(), and cyclicTransform::str().

Here is the caller graph for this function:

◆ makeUser()

void makeUser ( T & t ) const

Convert a value to user units.

Definition at line 57 of file unitSetTemplates.C.

Referenced by unitSet::makeUserOp::operator()().

Here is the caller graph for this function:

◆ any()

bool any ( ) const

inline

Return whether this is the "any" unit. I.e., the case where.

dimensions and dimensionless units are not checked, and any conversion is permitted.

Definition at line 62 of file unitSetI.H.

Referenced by Foam::operator<<(), and Foam::pow().

Here is the caller graph for this function:

◆ none()

bool none ( ) const

inline

Return whether this is the "none" unit. I.e., the case where unit.

conversions are prohibited.

Definition at line 68 of file unitSetI.H.

Referenced by Foam::operator<<(), and Foam::pow().

Here is the caller graph for this function:

◆ standard()

bool standard ( ) const

inline

Return whether this unit is standard. I.e., is its multiplier one?

Definition at line 74 of file unitSetI.H.

References Foam::any().

Referenced by Foam::assertNoConvertUnits(), unitSet::toStandard(), and Foam::writeEntry().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ reset()

void reset ( const unitSet & units )

Reset the unit conversion.

Definition at line 117 of file unitSet.C.

References unitSet::nDimlessUnits.

Referenced by Foam::operator>>(), Foam::units::setLength(), and unitSets::unitSets().

Here is the caller graph for this function:

◆ read() [1/3]

void read	(	const word &	keyword,
		const dictionary &	dict
	)

Update.

Definition at line 44 of file unitSetIO.C.

References Foam::abort(), dict, Foam::FatalIOError, FatalIOErrorInFunction, unitSet::info(), dictionary::lookup(), and dictionaryName::name().

Referenced by namedUnitSet::read().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ read() [2/3]

void read ( Istream & is )

Update.

Definition at line 63 of file unitSetIO.C.

References Foam::abort(), Foam::FatalIOError, FatalIOErrorInFunction, and unitSet::info().

Here is the call graph for this function:

◆ read() [3/3]

void read	(	const word &	keyword,
		const dictionary &	dict,
		Istream &	is
	)

Update.

Definition at line 81 of file unitSetIO.C.

References Foam::abort(), dict, Foam::FatalIOError, FatalIOErrorInFunction, unitSet::info(), and dictionaryName::name().

Here is the call graph for this function:

◆ readIfPresent() [1/3]

bool readIfPresent	(	const word &	keyword,
		const dictionary &	dict
	)

Update if found in the dictionary.

Definition at line 105 of file unitSetIO.C.

References Foam::abort(), dict, Foam::FatalIOError, FatalIOErrorInFunction, unitSet::info(), dictionary::lookupEntryPtr(), dictionaryName::name(), and entry::stream().

Referenced by Field< tensor >::clone(), Foam::readAndConvert(), namedUnitSet::readIfPresent(), and Field< tensor >::rmap().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ readIfPresent() [2/3]

bool readIfPresent ( Istream & is )

Update if found on the stream.

Definition at line 139 of file unitSetIO.C.

References Foam::abort(), Foam::any(), token::BEGIN_SQR, Foam::endl(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, unitSet::info(), IOstream::lineNumber(), IOstream::name(), and Istream::putBack().

Here is the call graph for this function:

◆ readIfPresent() [3/3]

bool readIfPresent	(	const word &	keyword,
		const dictionary &	dict,
		Istream &	is
	)

Update if found on the dictionary stream.

Definition at line 171 of file unitSetIO.C.

References Foam::abort(), Foam::any(), token::BEGIN_SQR, dict, Foam::endl(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::Info, unitSet::info(), dictionaryName::name(), and Istream::putBack().

Here is the call graph for this function:

◆ info()

InfoProxy<unitSet> info ( ) const

inline

Return info proxy.

Definition at line 228 of file unitSet.H.

Referenced by unitSet::read(), and unitSet::readIfPresent().

Here is the caller graph for this function:

◆ operator[]() [1/2]

Foam::scalar operator[] ( const dimensionSet::dimensionType type ) const

inline

Access the dimension exponents.

Definition at line 82 of file unitSetI.H.

References Foam::type().

Here is the call graph for this function:

◆ operator[]() [2/2]

Foam::scalar operator[] ( const dimlessUnitType type ) const

inline

Access the dimensionless unit exponents.

Definition at line 91 of file unitSetI.H.

References Foam::type().

Here is the call graph for this function:

◆ operator=() [1/2]

void operator= ( const unitSet & )

delete

Disallow default bitwise assignment.

◆ operator=() [2/2]

void operator= ( const unitSet && )

delete

Disallow default bitwise move assignment.

Friends And Related Function Documentation

◆ pow

unitSet pow	(	const unitSet &	,
		const	scalar
	)

friend

Raise to a power.

◆ operator+

const unitSet& operator+	(	const unitSet &	,
		const unitSet &
	)

friend

Combine.

◆ operator*

unitSet operator*	(	const unitSet &	,
		const unitSet &
	)

friend

Multiply.

◆ operator/

unitSet operator/	(	const unitSet &	,
		const unitSet &
	)

friend

Divide.

◆ operator>>

Istream& operator>>	(	Istream &	,
		unitSet &
	)

friend

Read from stream.

◆ operator<< [1/2]

Ostream& operator<<	(	Ostream &	,
		const unitSet &
	)

friend

Write to stream.

◆ operator<< [2/2]

Ostream& operator<<	(	Ostream &	,
		const InfoProxy< unitSet > &
	)

friend

Write info to stream.

Member Data Documentation

◆ dimlessUnitTypeNames_

const Foam::NamedEnum< Foam::unitSet::dimlessUnitType, 2 > & dimlessUnitTypeNames_ = dimlessUnitTypeNamesPtr_()

static

Names of the dimensionless units.

Definition at line 88 of file unitSet.H.

Referenced by Foam::operator<<().

◆ smallExponent

const Foam::scalar smallExponent = rootSmall

static

A small exponent with which to perform inexact comparisons.

Definition at line 94 of file unitSet.H.

Referenced by Foam::operator<<().

The documentation for this class was generated from the following files:

src/OpenFOAM/unitSet/unitSet.H
src/OpenFOAM/unitSet/unitSet.C
src/OpenFOAM/unitSet/unitSetI.H
src/OpenFOAM/unitSet/unitSetIO.C
src/OpenFOAM/unitSet/unitSetTemplates.C

Classes

Public Types

Public Member Functions

Static Public Member Functions

Static Public Attributes

Friends

Detailed Description

Member Enumeration Documentation

◆ anonymous enum

◆ dimlessUnitType

Constructor & Destructor Documentation

◆ unitSet() [1/5]

◆ unitSet() [2/5]

◆ unitSet() [3/5]

◆ unitSet() [4/5]

◆ unitSet() [5/5]

Member Function Documentation

◆ ClassName()

◆ newUnitless()

◆ newAny()

◆ newNone()

◆ dimensions()

◆ dimensionless()

◆ toStandard()

◆ makeStandard()

◆ toUser()

◆ makeUser()

◆ any()

◆ none()

◆ standard()

◆ reset()

◆ read() [1/3]

◆ read() [2/3]

◆ read() [3/3]

◆ readIfPresent() [1/3]

◆ readIfPresent() [2/3]

◆ readIfPresent() [3/3]

◆ info()

◆ operator[]() [1/2]

◆ operator[]() [2/2]

◆ operator=() [1/2]

◆ operator=() [2/2]

Friends And Related Function Documentation

◆ pow

◆ operator+

◆ operator*

◆ operator/

◆ operator>>

◆ operator<< [1/2]

◆ operator<< [2/2]

Member Data Documentation

◆ dimlessUnitTypeNames_

◆ smallExponent
