multiValveEnginePistonMotion Class Reference

Motion function for solid regions representing a piston. Looks up the multiValveEngine mover from the associated fluid region and uses the motion specified for the piston. More...

Inheritance diagram for multiValveEnginePistonMotion:

Collaboration diagram for multiValveEnginePistonMotion:

Public Member Functions
	TypeName ("multiValveEnginePistonMotion")
	Runtime type information. More...
	multiValveEnginePistonMotion (const word &name, const dictionary &SBMFCoeffs, const Time &runTime)
	Construct from components. More...
	multiValveEnginePistonMotion (const multiValveEnginePistonMotion &)=delete
	Disallow default bitwise copy construction. More...
virtual autoPtr< solidBodyMotionFunction >	clone () const
	Construct and return a clone. More...
virtual	~multiValveEnginePistonMotion ()
	Destructor. More...
virtual septernion	transformation () const
	Return the solid-body motion transformation septernion. More...
virtual bool	read (const dictionary &SBMFCoeffs)
	Update properties from given dictionary. More...
void	operator= (const multiValveEnginePistonMotion &)=delete
	Disallow default bitwise assignment. More...
Public Member Functions inherited from solidBodyMotionFunction
	TypeName ("solidBodyMotionFunction")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, solidBodyMotionFunction, dictionary,(const word &name, const dictionary &SBMFCoeffs, const Time &runTime),(name, SBMFCoeffs, runTime))
	solidBodyMotionFunction (const word &name, const dictionary &dict, const Time &runTime)
	Construct from the SBMFCoeffs dictionary and Time. More...
	solidBodyMotionFunction (const solidBodyMotionFunction &)=delete
	Disallow default bitwise copy construction. More...
virtual	~solidBodyMotionFunction ()
	Destructor. More...
const word &	name () const
virtual void	writeData (Ostream &) const
	Write in dictionary format. More...
void	operator= (const solidBodyMotionFunction &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from solidBodyMotionFunction
static autoPtr< solidBodyMotionFunction >	New (const dictionary &SBMFCoeffs, const Time &runTime, const word &name="solidBodyMotionFunction")
	Select constructed from the SBMFCoeffs dictionary and Time. More...
Protected Attributes inherited from solidBodyMotionFunction
const word	name_
dictionary	SBMFCoeffs_
const Time &	time_

Detailed Description

Motion function for solid regions representing a piston. Looks up the multiValveEngine mover from the associated fluid region and uses the motion specified for the piston.

Example specification, in constant/<solidRegion>/dynamicMeshDict:

mover
{
    type            pointMeshMover;
    libs            ("libfvMotionSolvers.so");

    pointMeshMover
    {
        type            solidBody;
        cellZone        all;
        solidBodyMotionFunction multiValveEnginePistonMotion;
        fluidRegion     fluid;
    }
}

Source files

• multiValveEnginePistonMotion.H
• multiValveEnginePistonMotion.C

Definition at line 69 of file multiValveEnginePistonMotion.H.

Constructor & Destructor Documentation

multiValveEnginePistonMotion() [1/2]

multiValveEnginePistonMotion	(	const word &	name,
		const dictionary &	SBMFCoeffs,
		const Time &	runTime
	)

Construct from components.

Definition at line 49 of file multiValveEnginePistonMotion.C.

References multiValveEnginePistonMotion::read().

Here is the call graph for this function:

multiValveEnginePistonMotion() [2/2]

multiValveEnginePistonMotion ( const multiValveEnginePistonMotion &  )

delete

Disallow default bitwise copy construction.

~multiValveEnginePistonMotion()

~multiValveEnginePistonMotion ( )

virtual

Destructor.

Definition at line 66 of file multiValveEnginePistonMotion.C.

Member Function Documentation

TypeName()

TypeName

(

"multiValveEnginePistonMotion"

)

Runtime type information.

clone()

virtual autoPtr<solidBodyMotionFunction> clone ( ) const

inlinevirtual

Construct and return a clone.

Implements solidBodyMotionFunction.

Definition at line 104 of file multiValveEnginePistonMotion.H.

References solidBodyMotionFunction::name_, solidBodyMotionFunction::SBMFCoeffs_, and solidBodyMotionFunction::time_.

transformation()

Foam::septernion transformation ( ) const

virtual

Return the solid-body motion transformation septernion.

Implements solidBodyMotionFunction.

Definition at line 74 of file multiValveEnginePistonMotion.C.

References multiValveEngine::movingObject::axis, Foam::exit(), Foam::FatalError, FatalErrorInFunction, objectRegistry::lookupObject(), fvMesh::mover(), multiValveEngine::piston, multiValveEngine::pistonObject::position(), and Foam::typeName().

Here is the call graph for this function:

read()

bool read ( const dictionary &  SBMFCoeffs )

virtual

Update properties from given dictionary.

Implements solidBodyMotionFunction.

Definition at line 103 of file multiValveEnginePistonMotion.C.

References dictionary::lookup(), and solidBodyMotionFunction::read().

Referenced by multiValveEnginePistonMotion::multiValveEnginePistonMotion().

Here is the call graph for this function:

Here is the caller graph for this function:

operator=()

void operator= ( const multiValveEnginePistonMotion &  )

delete

Disallow default bitwise assignment.

---

The documentation for this class was generated from the following files:

• src/fvMeshMovers/multiValveEngine/solidBodyMotionFunctions/multiValveEnginePistonMotion/multiValveEnginePistonMotion.H
• src/fvMeshMovers/multiValveEngine/solidBodyMotionFunctions/multiValveEnginePistonMotion/multiValveEnginePistonMotion.C
