Public Member Functions | Static Public Member Functions | List of all members
saturationPressureModel Class Referenceabstract

Model to describe the dependence of saturation pressure on temperature. More...

Inheritance diagram for saturationPressureModel:
Inheritance graph
[legend]

Public Member Functions

 TypeName ("saturationPressureModel")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, saturationPressureModel, dictionary,(const dictionary &dict),(dict))
 Declare runtime construction from dictionary. More...

 declareRunTimeSelectionTable (autoPtr, saturationPressureModel,,(),())
 Declare runtime default construction. More...

 saturationPressureModel ()
 Default construct. More...

virtual ~saturationPressureModel ()
 Destructor. More...

virtual tmp< scalarField > pSat (const scalarField &T) const =0
 Saturation temperature for scalarField. More...

virtual tmp< scalarField > pSatPrime (const scalarField &T) const =0

virtual tmp< scalarField > lnPSat (const scalarField &T) const =0

virtual tmp< volScalarField::Internal > pSat (const volScalarField::Internal &T) const
 Saturation pressure for volScalarField::Internal. More...

virtual tmp< volScalarField::Internal > pSatPrime (const volScalarField::Internal &T) const

virtual tmp< volScalarField::Internal > lnPSat (const volScalarField::Internal &T) const

virtual tmp< volScalarField > pSat (const volScalarField &T) const
 Saturation pressure for volScalarField. More...

virtual tmp< volScalarField > pSatPrime (const volScalarField &T) const

virtual tmp< volScalarField > lnPSat (const volScalarField &T) const

template<class FieldType >
Foam::tmp< FieldType > pSat (const FieldType &T) const

template<class FieldType >
Foam::tmp< FieldType > pSatPrime (const FieldType &T) const

template<class FieldType >
Foam::tmp< FieldType > lnPSat (const FieldType &T) const


Static Public Member Functions

static autoPtr< saturationPressureModel > New (const word &name, const dictionary &dict)
 Select with name within a dictionary. More...


Detailed Description

Model to describe the dependence of saturation pressure on temperature.

Source files

Definition at line 83 of file saturationPressureModel.H.

Constructor & Destructor Documentation

◆ saturationPressureModel()

saturationPressureModel ( )

Default construct.

Definition at line 97 of file saturationPressureModel.C.

◆ ~saturationPressureModel()

~saturationPressureModel ( )
virtual

Destructor.

Definition at line 103 of file saturationPressureModel.C.

Member Function Documentation

◆ TypeName()

TypeName ( "saturationPressureModel"  )

Runtime type information.

◆ declareRunTimeSelectionTable() [1/2]

declareRunTimeSelectionTable ( autoPtr  ,
saturationPressureModel  ,
dictionary  ,
(const dictionary &dict)  ,
(dict)
)

Declare runtime construction from dictionary.

◆ declareRunTimeSelectionTable() [2/2]

declareRunTimeSelectionTable ( autoPtr  ,
saturationPressureModel  ,
()  ,
()
)

Declare runtime default construction.

◆ New()

Foam::autoPtr< Foam::saturationPressureModel > New ( const word &  name,
const dictionary &  dict
)
static

Select with name within a dictionary.

Definition at line 31 of file saturationPressureModelNew.C.

References dict, Foam::dimPressure, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, Foam::indentOrNl(), Foam::Info, token::isWord(), dictionary::lookup(), Foam::name(), dictionary::optionalTypeDict(), and token::wordToken().

Referenced by nonRandomTwoLiquid::nonRandomTwoLiquid(), and cavitationModel::read().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ pSat() [1/4]

virtual tmp< scalarField > pSat ( const scalarField &  T) const
pure virtual

Saturation temperature for scalarField.

Implemented in function1Pressure.

◆ pSatPrime() [1/4]

virtual tmp< scalarField > pSatPrime ( const scalarField &  T) const
pure virtual

Implemented in function1Pressure.

◆ lnPSat() [1/4]

virtual tmp< scalarField > lnPSat ( const scalarField &  T) const
pure virtual

Implemented in function1Pressure.

◆ pSat() [2/4]

Foam::tmp< Foam::volScalarField::Internal > pSat ( const volScalarField::Internal &  T) const
virtual

Saturation pressure for volScalarField::Internal.

Definition at line 109 of file saturationPressureModel.C.

◆ pSatPrime() [2/4]

Foam::tmp< Foam::volScalarField::Internal > pSatPrime ( const volScalarField::Internal &  T) const
virtual

Definition at line 109 of file saturationPressureModel.C.

◆ lnPSat() [2/4]

Foam::tmp< Foam::volScalarField::Internal > lnPSat ( const volScalarField::Internal &  T) const
virtual

Definition at line 109 of file saturationPressureModel.C.

◆ pSat() [3/4]

Foam::tmp< Foam::volScalarField > pSat ( const volScalarField &  T) const
virtual

Saturation pressure for volScalarField.

Definition at line 112 of file saturationPressureModel.C.

◆ pSatPrime() [3/4]

Foam::tmp< Foam::volScalarField > pSatPrime ( const volScalarField &  T) const
virtual

Definition at line 112 of file saturationPressureModel.C.

◆ lnPSat() [3/4]

Foam::tmp< Foam::volScalarField > lnPSat ( const volScalarField &  T) const
virtual

Definition at line 112 of file saturationPressureModel.C.

◆ pSat() [4/4]

Foam::tmp<FieldType> pSat ( const FieldType &  T) const

Definition at line 42 of file saturationPressureModel.C.

References Foam::dimPressure, Foam::saturationModels::evaluate(), and Foam::T().

Here is the call graph for this function:

◆ pSatPrime() [4/4]

Foam::tmp<FieldType> pSatPrime ( const FieldType &  T) const

Definition at line 60 of file saturationPressureModel.C.

References Foam::dimPressure, Foam::dimTemperature, Foam::saturationModels::evaluate(), and Foam::T().

Here is the call graph for this function:

◆ lnPSat() [4/4]

Foam::tmp<FieldType> lnPSat ( const FieldType &  T) const

Definition at line 78 of file saturationPressureModel.C.

References Foam::dimless, Foam::saturationModels::evaluate(), and Foam::T().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
