Common functions to emissivity. It gets supplied from lookup into a dictionary or calculated by the solidThermo: More...

Inheritance diagram for radiationCoupledBase:

[legend]

Collaboration diagram for radiationCoupledBase:

[legend]

Public Types
enum	emissivityMethodType { SOLIDRADIATION , LOOKUP }
	Type of supplied emissivity. More...

Public Member Functions
	TypeName ("radiationCoupledBase")
	Runtime type information. More...

	radiationCoupledBase (const fvPatch &patch, const word &calculationMethod, const scalarField &emissivity)
	Construct from patch, emissivity mode and emissivity. More...

	radiationCoupledBase (const fvPatch &patch, const word &calculationMethod, const scalarField &emissivity, const fvPatchFieldMapper &mapper)
	Construct from patch, emissivity mode and emissivity and mapper. More...

	radiationCoupledBase (const fvPatch &patch, const dictionary &dict)
	Construct from patch and dictionary. More...

virtual	~radiationCoupledBase ()
	Destructor. More...

word	emissivityMethod () const
	Method to obtain emissivity. More...

tmp< scalarField >	emissivity () const
	Calculate corresponding emissivity field. More...

virtual void	map (const fvPatchScalarField &, const fvPatchFieldMapper &)
	Map the given fvPatchField onto this fvPatchField. More...

virtual void	reset (const fvPatchScalarField &)
	Reset the fvPatchField to the given fvPatchField. More...

void	write (Ostream &) const
	Write. More...

Protected Attributes
const emissivityMethodType	method_
	How to get emissivity. More...

scalarField	emissivity_
	Emissivity. More...

Detailed Description

Common functions to emissivity. It gets supplied from lookup into a dictionary or calculated by the solidThermo:

'lookup' : Read the patch emissivity field from the dictionary
'solidRadiation' : Use the emissivity field mapped from the adjacent solid

Source files

Definition at line 55 of file radiationCoupledBase.H.

Member Enumeration Documentation

◆ emissivityMethodType

enum emissivityMethodType

Type of supplied emissivity.

Enumerator
SOLIDRADIATION
LOOKUP

Definition at line 60 of file radiationCoupledBase.H.

Constructor & Destructor Documentation

◆ radiationCoupledBase() [1/3]

radiationCoupledBase	(	const fvPatch &	patch,
		const word &	calculationMethod,
		const scalarField &	emissivity
	)

Construct from patch, emissivity mode and emissivity.

Definition at line 61 of file radiationCoupledBase.C.

◆ radiationCoupledBase() [2/3]

radiationCoupledBase	(	const fvPatch &	patch,
		const word &	calculationMethod,
		const scalarField &	emissivity,
		const fvPatchFieldMapper &	mapper
	)

Construct from patch, emissivity mode and emissivity and mapper.

Definition at line 74 of file radiationCoupledBase.C.

◆ radiationCoupledBase() [3/3]

radiationCoupledBase	(	const fvPatch &	patch,
		const dictionary &	dict
	)

Construct from patch and dictionary.

Definition at line 88 of file radiationCoupledBase.C.

References dict, radiationCoupledBase::emissivity_, radiationCoupledBase::LOOKUP, radiationCoupledBase::method_, fvPatch::size(), and radiationCoupledBase::SOLIDRADIATION.

Here is the call graph for this function:

◆ ~radiationCoupledBase()

~radiationCoupledBase ( )

virtual

Destructor.

Definition at line 116 of file radiationCoupledBase.C.

Member Function Documentation

◆ TypeName()

TypeName ( "radiationCoupledBase" )

Runtime type information.

◆ emissivityMethod()

word emissivityMethod ( ) const

inline

Method to obtain emissivity.

Definition at line 132 of file radiationCoupledBase.H.

References radiationCoupledBase::method_.

◆ emissivity()

Foam::tmp< Foam::scalarField > emissivity ( ) const

Calculate corresponding emissivity field.

Definition at line 122 of file radiationCoupledBase.C.

References Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, mappedPatchBase::fromNeighbour(), mappedPatchBase::getMap(), fvPatch::index(), patchIdentifier::index(), objectRegistry::lookupObject(), mappedPatchBase::nbrMesh(), mappedPatchBase::nbrPolyPatch(), and radiation().

Referenced by viewFactor::calculate(), and wideBandDiffusiveRadiationMixedFvPatchScalarField::wideBandDiffusiveRadiationMixedFvPatchScalarField().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ map()

void map	(	const fvPatchScalarField &	ptf,
		const fvPatchFieldMapper &	mapper
	)

virtual

Map the given fvPatchField onto this fvPatchField.

Reimplemented in wideBandDiffusiveRadiationMixedFvPatchScalarField, MarshakRadiationFixedTemperatureFvPatchScalarField, MarshakRadiationFvPatchScalarField, greyDiffusiveViewFactorFixedValueFvPatchScalarField, and greyDiffusiveRadiationMixedFvPatchScalarField.

Definition at line 180 of file radiationCoupledBase.C.

References radiationCoupledBase::emissivity_.

Referenced by greyDiffusiveRadiationMixedFvPatchScalarField::map(), greyDiffusiveViewFactorFixedValueFvPatchScalarField::map(), MarshakRadiationFvPatchScalarField::map(), MarshakRadiationFixedTemperatureFvPatchScalarField::map(), and wideBandDiffusiveRadiationMixedFvPatchScalarField::map().

Here is the caller graph for this function:

◆ reset()

void reset ( const fvPatchScalarField & ptf )

virtual

Reset the fvPatchField to the given fvPatchField.

Used for mesh to mesh mapping

Reimplemented in wideBandDiffusiveRadiationMixedFvPatchScalarField, MarshakRadiationFixedTemperatureFvPatchScalarField, MarshakRadiationFvPatchScalarField, greyDiffusiveViewFactorFixedValueFvPatchScalarField, and greyDiffusiveRadiationMixedFvPatchScalarField.

Definition at line 193 of file radiationCoupledBase.C.

References radiationCoupledBase::emissivity_.

Referenced by greyDiffusiveRadiationMixedFvPatchScalarField::reset(), greyDiffusiveViewFactorFixedValueFvPatchScalarField::reset(), MarshakRadiationFvPatchScalarField::reset(), MarshakRadiationFixedTemperatureFvPatchScalarField::reset(), and wideBandDiffusiveRadiationMixedFvPatchScalarField::reset().

Here is the caller graph for this function:

◆ write()

void write ( Ostream & os ) const

Write.

Definition at line 205 of file radiationCoupledBase.C.

References Foam::writeEntry().

Referenced by greyDiffusiveRadiationMixedFvPatchScalarField::write(), greyDiffusiveViewFactorFixedValueFvPatchScalarField::write(), MarshakRadiationFvPatchScalarField::write(), MarshakRadiationFixedTemperatureFvPatchScalarField::write(), and wideBandDiffusiveRadiationMixedFvPatchScalarField::write().

Here is the call graph for this function:

Here is the caller graph for this function:

Member Data Documentation

◆ method_

const emissivityMethodType method_

protected

How to get emissivity.

Definition at line 83 of file radiationCoupledBase.H.

Referenced by radiationCoupledBase::emissivityMethod(), and radiationCoupledBase::radiationCoupledBase().

◆ emissivity_

scalarField emissivity_

protected

Emissivity.

Cached locally when is read from dictionary (lookup mode)

Definition at line 87 of file radiationCoupledBase.H.

Referenced by radiationCoupledBase::map(), radiationCoupledBase::radiationCoupledBase(), and radiationCoupledBase::reset().

The documentation for this class was generated from the following files:

src/radiationModels/derivedFvPatchFields/radiationCoupledBase/radiationCoupledBase.H
src/radiationModels/derivedFvPatchFields/radiationCoupledBase/radiationCoupledBase.C
