pressureFvPatchScalarField Class Reference

Static pressure boundary condition. More...

Inheritance diagram for pressureFvPatchScalarField:
Collaboration diagram for pressureFvPatchScalarField:

Public Member Functions

 TypeName ("pressure")
 Runtime type information. More...

 pressureFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, volMesh > &, const dictionary &)
 Construct from patch, internal field and dictionary. More...

 pressureFvPatchScalarField (const pressureFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, volMesh > &, const fvPatchFieldMapper &)
 Construct by mapping given. More...

 pressureFvPatchScalarField (const pressureFvPatchScalarField &)=delete
 Disallow copy without setting internal field reference. More...

 pressureFvPatchScalarField (const pressureFvPatchScalarField &, const DimensionedField< scalar, volMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarFieldclone (const DimensionedField< scalar, volMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

const scalarFieldp () const
 Return the static pressure. More...

scalarFieldp ()
 Return reference to the static pressure to allow adjustment. More...

virtual void map (const fvPatchScalarField &, const fvPatchFieldMapper &)
 Map the given fvPatchField onto this fvPatchField. More...

virtual void reset (const fvPatchScalarField &)
 Reset the fvPatchField to the given fvPatchField. More...

virtual void updateCoeffs ()
 Update the coefficients associated with the patch field. More...

virtual void write (Ostream &) const
 Write. More...


Protected Attributes

scalarField p_
 Static pressure. More...


Detailed Description

Static pressure boundary condition.

Used as the base-class for static pressure boundary conditions force alternative pressure variables, e.g. p_rgh.

Usage
Property Description Required Default value
p static pressure yes

Example of the boundary condition specification:

    <patchName>
    {
        type            pressure;
        p               uniform 0;
        value           uniform 0; // optional initial value
    }
See also
Foam::fixedValueFvPatchScalarField Foam::PrghPressureFvPatchScalarField
Source files

Definition at line 81 of file pressureFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ pressureFvPatchScalarField() [1/4]

pressureFvPatchScalarField ( const fvPatch p,
const DimensionedField< scalar, volMesh > &  iF,
const dictionary dict
)

Construct from patch, internal field and dictionary.

Definition at line 34 of file pressureFvPatchScalarField.C.

References dict, fvPatchField< Type >::operator, fvPatchField< Type >::operator=(), pressureFvPatchScalarField::p(), pressureFvPatchScalarField::p_, and List< T >::size().

Referenced by pressureFvPatchScalarField::clone().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ pressureFvPatchScalarField() [2/4]

pressureFvPatchScalarField ( const pressureFvPatchScalarField ptf,
const fvPatch p,
const DimensionedField< scalar, volMesh > &  iF,
const fvPatchFieldMapper mapper
)

Construct by mapping given.

pressureFvPatchScalarField onto a new patch

Definition at line 58 of file pressureFvPatchScalarField.C.

◆ pressureFvPatchScalarField() [3/4]

Disallow copy without setting internal field reference.

◆ pressureFvPatchScalarField() [4/4]

pressureFvPatchScalarField ( const pressureFvPatchScalarField ptf,
const DimensionedField< scalar, volMesh > &  iF
)

Copy constructor setting internal field reference.

Definition at line 71 of file pressureFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "pressure"  )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, volMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 131 of file pressureFvPatchScalarField.H.

References pressureFvPatchScalarField::pressureFvPatchScalarField().

Here is the call graph for this function:

◆ p() [1/2]

const scalarField& p ( ) const
inline

Return the static pressure.

Definition at line 148 of file pressureFvPatchScalarField.H.

References pressureFvPatchScalarField::p_.

Referenced by pressureFvPatchScalarField::pressureFvPatchScalarField().

Here is the caller graph for this function:

◆ p() [2/2]

scalarField& p ( )
inline

Return reference to the static pressure to allow adjustment.

Definition at line 154 of file pressureFvPatchScalarField.H.

References pressureFvPatchScalarField::p_.

◆ map()

void map ( const fvPatchScalarField ptf,
const fvPatchFieldMapper mapper
)
virtual

Map the given fvPatchField onto this fvPatchField.

Definition at line 84 of file pressureFvPatchScalarField.C.

References pressureFvPatchScalarField::p_.

◆ reset()

void reset ( const fvPatchScalarField ptf)
virtual

Reset the fvPatchField to the given fvPatchField.

Used for mesh to mesh mapping

Definition at line 99 of file pressureFvPatchScalarField.C.

References pressureFvPatchScalarField::p_.

◆ updateCoeffs()

void updateCoeffs ( )
virtual

Update the coefficients associated with the patch field.

Definition at line 113 of file pressureFvPatchScalarField.C.

References Foam::operator==().

Here is the call graph for this function:

◆ write()

void write ( Ostream os) const
virtual

Write.

Definition at line 126 of file pressureFvPatchScalarField.C.

References fvPatchField< Type >::write(), and Foam::writeEntry().

Here is the call graph for this function:

Member Data Documentation

◆ p_


The documentation for this class was generated from the following files:
