multiSolidBody Class Reference

Solid-body motion of the mesh parts specified by a run-time selectable motion functions. More...

Inheritance diagram for multiSolidBody:

Collaboration diagram for multiSolidBody:

Public Member Functions
	TypeName ("multiSolidBody")
	Runtime type information. More...
	multiSolidBody (const polyMesh &, const dictionary &)
	Construct from mesh and dictionary. More...
	multiSolidBody (const multiSolidBody &)=delete
	Disallow default bitwise copy construction. More...
	~multiSolidBody ()
	Destructor. More...
virtual tmp< pointField >	newPoints ()
	Return point location obtained from the current motion field. More...
virtual bool	solidBodyMotion () const
	This is a solid body motion. More...
virtual void	topoChange (const polyTopoChangeMap &)
	Update local data for topology changes. More...
virtual void	distribute (const polyDistributionMap &)
	Update corresponding to the given distribution map. More...
virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...
void	operator= (const multiSolidBody &)=delete
	Disallow default bitwise assignment. More...
Public Member Functions inherited from displacementPoints0
	TypeName ("displacementPoints0")
	Runtime type information. More...
	displacementPoints0 (const polyMesh &, const dictionary &, const word &type)
	Construct from mesh and dictionary. More...
	displacementPoints0 (const displacementPoints0 &)=delete
	Disallow default bitwise copy construction. More...
virtual	~displacementPoints0 ()
	Destructor. More...
pointField &	points0 ()
	Return reference to the reference field. More...
const pointField &	points0 () const
	Return reference to the reference field. More...
virtual void	movePoints (const pointField &)
	Update local data for geometry changes. More...
virtual bool	write () const
	Write points0 if the mesh topology changed. More...
void	operator= (const displacementPoints0 &)=delete
	Disallow default bitwise assignment. More...
Public Member Functions inherited from pointMeshMover
	TypeName ("pointMeshMover")
	Runtime type information. More...
	declareRunTimeSelectionTable (autoPtr, pointMeshMover, dictionary,(const polyMesh &mesh, const dictionary &dict),(mesh, dict))
	pointMeshMover (const polyMesh &mesh, const word &type)
	Construct from polyMesh and dictionary and type. More...
virtual autoPtr< pointMeshMover >	clone () const
	Clone function. More...
virtual	~pointMeshMover ()
	Destructor. More...
const polyMesh &	poly () const
	Return reference to mesh. More...
virtual void	twoDCorrectPoints (pointField &) const
	Correct point field for reduced-dimensionality cases. More...

Additional Inherited Members
Static Public Member Functions inherited from displacementPoints0
static pointVectorField	readPoints0 (const polyMesh &mesh)
Static Public Member Functions inherited from pointMeshMover
static autoPtr< pointMeshMover >	New (const polyMesh &, const dictionary &)
	Select constructed from polyMesh and dictionary. More...
Protected Attributes inherited from displacementPoints0
pointVectorField	points0_
	Starting points. More...

Detailed Description

Solid-body motion of the mesh parts specified by a run-time selectable motion functions.

Source files

• multiSolidBody_pointMeshMover.H multiSolidBody_
• pointMeshMover.C

Definition at line 52 of file multiSolidBody_pointMeshMover.H.

Constructor & Destructor Documentation

multiSolidBody() [1/2]

multiSolidBody	(	const polyMesh &	mesh,
		const dictionary &	dict
	)

Construct from mesh and dictionary.

Definition at line 117 of file multiSolidBody_pointMeshMover.C.

References polyMesh::cellZones(), dict, Foam::endl(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, PtrListDictionary< T >::findIndex(), forAll, forAllConstIter, Foam::Info, mesh, IOobject::name(), solidBodyMotionFunction::New(), List< T >::setSize(), fvMesh::time(), and DictionaryBase< IDLListType, T >::toc().

Here is the call graph for this function:

multiSolidBody() [2/2]

multiSolidBody ( const multiSolidBody &  )

delete

Disallow default bitwise copy construction.

~multiSolidBody()

~multiSolidBody

(

)

Destructor.

Definition at line 175 of file multiSolidBody_pointMeshMover.C.

Member Function Documentation

TypeName()

TypeName

(

"multiSolidBody"

)

Runtime type information.

newPoints()

Foam::tmp< Foam::pointField > newPoints ( )

virtual

Return point location obtained from the current motion field.

Implements pointMeshMover.

Definition at line 181 of file multiSolidBody_pointMeshMover.C.

References forAll, points, tmp< T >::ref(), and Foam::transformPoints().

Here is the call graph for this function:

solidBodyMotion()

virtual bool solidBodyMotion ( ) const

inlinevirtual

This is a solid body motion.

Reimplemented from pointMeshMover.

Definition at line 102 of file multiSolidBody_pointMeshMover.H.

topoChange()

void topoChange ( const polyTopoChangeMap &  map )

virtual

Update local data for topology changes.

Reimplemented from displacementPoints0.

Definition at line 202 of file multiSolidBody_pointMeshMover.C.

References IOobject::AUTO_WRITE, Foam::exit(), Foam::FatalError, FatalErrorInFunction, forAll, polyTopoChangeMap::pointMap(), points, and polyTopoChangeMap::reversePointMap().

Here is the call graph for this function:

distribute()

void distribute ( const polyDistributionMap &  map )

virtual

Update corresponding to the given distribution map.

Reimplemented from displacementPoints0.

Definition at line 252 of file multiSolidBody_pointMeshMover.C.

References displacementPoints0::distribute().

Here is the call graph for this function:

mapMesh()

void mapMesh ( const polyMeshMap &  map )

virtual

Update from another mesh using the given map.

Implements displacementPoints0.

Definition at line 263 of file multiSolidBody_pointMeshMover.C.

References IOobject::AUTO_WRITE, forAll, and displacementPoints0::mapMesh().

Here is the call graph for this function:

operator=()

void operator= ( const multiSolidBody &  )

delete

Disallow default bitwise assignment.

---

The documentation for this class was generated from the following files:

• src/pointMeshMovers/multiSolidBody/multiSolidBody_pointMeshMover.H
• src/pointMeshMovers/multiSolidBody/multiSolidBody_pointMeshMover.C
