Abstract base class for displacement pointMesh movers. More...
Public Member Functions | |
| TypeName ("displacement") | |
| Runtime type information. More... | |
| displacement (const polyMesh &, const dictionary &, const word &type) | |
| Construct from mesh and dictionary. More... | |
| displacement (const displacement &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~displacement () |
| Destructor. More... | |
| pointVectorField & | pointDisplacement () |
| Return reference to the point motion displacement field. More... | |
| const pointVectorField & | pointDisplacement () const |
| Return const reference to the point motion displacement field. More... | |
| virtual tmp< pointField > | newPoints ()=0 |
| Return point location obtained from the current motion field. More... | |
| virtual void | mapMesh (const polyMeshMap &) |
| Update from another mesh using the given map (not implemented) More... | |
| void | operator= (const displacement &)=delete |
| Disallow default bitwise assignment. More... | |
 Public Member Functions inherited from displacementPoints0 | |
| TypeName ("displacementPoints0") | |
| Runtime type information. More... | |
| displacementPoints0 (const polyMesh &, const dictionary &, const word &type) | |
| Construct from mesh and dictionary. More... | |
| displacementPoints0 (const displacementPoints0 &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~displacementPoints0 () |
| Destructor. More... | |
| pointField & | points0 () |
| Return reference to the reference field. More... | |
| const pointField & | points0 () const |
| Return reference to the reference field. More... | |
| virtual void | movePoints (const pointField &) |
| Update local data for geometry changes. More... | |
| virtual void | topoChange (const polyTopoChangeMap &) |
| Update local data for topology changes. More... | |
| virtual void | distribute (const polyDistributionMap &) |
| Update corresponding to the given distribution map. More... | |
| virtual bool | write () const |
| Write points0 if the mesh topology changed. More... | |
| void | operator= (const displacementPoints0 &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from pointMeshMover | |
| TypeName ("pointMeshMover") | |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, pointMeshMover, dictionary,(const polyMesh &mesh, const dictionary &dict),(mesh, dict)) | |
| pointMeshMover (const polyMesh &mesh, const word &type) | |
| Construct from polyMesh and dictionary and type. More... | |
| virtual autoPtr< pointMeshMover > | clone () const |
| Clone function. More... | |
| virtual | ~pointMeshMover () |
| Destructor. More... | |
| const polyMesh & | poly () const |
| Return reference to mesh. More... | |
| virtual void | twoDCorrectPoints (pointField &) const |
| Correct point field for reduced-dimensionality cases. More... | |
| virtual bool | solidBodyMotion () const |
| Is the motion solid body? I.e., are the volumes and area magnitudes. More... | |
Protected Member Functions | |
| tmp< pointField > | points () const |
| Return the points corresponding to the current displacement. More... | |
Protected Attributes | |
| pointVectorField | pointDisplacement_ |
| Point motion field. More... | |
| Protected Attributes inherited from displacementPoints0 | |
| pointVectorField | points0_ |
| Starting points. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from displacementPoints0 | |
| static pointVectorField | readPoints0 (const polyMesh &mesh) |
| Static Public Member Functions inherited from pointMeshMover | |
| static autoPtr< pointMeshMover > | New (const polyMesh &, const dictionary &) |
| Select constructed from polyMesh and dictionary. More... | |
Abstract base class for displacement pointMesh movers.
The boundary displacement is set as a boundary condition on the pointDisplacement pointVectorField.
Definition at line 53 of file displacement_pointMeshMover.H.
| displacement | ( | const polyMesh & | mesh, |
| const dictionary & | dict, | ||
| const word & | type | ||
| ) |
Construct from mesh and dictionary.
Definition at line 50 of file displacement_pointMeshMover.C.
|
delete |
Disallow default bitwise copy construction.
|
virtual |
Destructor.
Definition at line 75 of file displacement_pointMeshMover.C.
|
protected |
Return the points corresponding to the current displacement.
Definition at line 42 of file displacement_pointMeshMover.C.
References displacement::pointDisplacement_, displacementPoints0::points0(), and GeometricField< Type, GeoMesh, PrimitiveField >::primitiveField().
| TypeName | ( | "displacement" | ) |
Runtime type information.
|
inline |
Return reference to the point motion displacement field.
Definition at line 95 of file displacement_pointMeshMover.H.
References displacement::pointDisplacement_.
|
inline |
Return const reference to the point motion displacement field.
Definition at line 101 of file displacement_pointMeshMover.H.
References displacement::pointDisplacement_.
|
pure virtual |
Return point location obtained from the current motion field.
Implements pointMeshMover.
Implemented in layeredDisplacement, externalDisplacement, displacementSBRStress, and displacementLaplacian.
|
virtual |
Update from another mesh using the given map (not implemented)
Implements displacementPoints0.
Reimplemented in layeredDisplacement, displacementSBRStress, and displacementLaplacian.
Definition at line 81 of file displacement_pointMeshMover.C.
References Foam::exit(), Foam::FatalError, FatalErrorInFunction, and Foam::nl.
Referenced by displacementLaplacian::mapMesh(), and displacementSBRStress::mapMesh().
|
delete |
Disallow default bitwise assignment.
|
mutableprotected |
Point motion field.
Definition at line 62 of file displacement_pointMeshMover.H.
Referenced by displacement::pointDisplacement(), and displacement::points().
