Piecewise-linear interpolation method. Uses volPointInterpolation to create values on the points and linear surfaceInterpolation to create values at the face-centres. Then uses a face-centre tetrahedral decomposition to linearly interpolate between the values at the points, at the face-centres and at the cell-centres. More...

Inheritance diagram for cellPointFace< Type >:

[legend]

Collaboration diagram for cellPointFace< Type >:

[legend]

Public Member Functions
	TypeName ("cellPointFace")
	Runtime type information. More...

	cellPointFace (const VolField< Type > &psi)
	Construct from components. More...

	cellPointFace (const cellPointFace< Type > &i)
	Copy construct. More...

virtual autoPtr< interpolation< Type > >	clone () const
	Clone. More...

Type	interpolate (const vector &position, const label celli, const label facei=-1) const
	Interpolate field to the given point in the given cell. More...

Public Member Functions inherited from volPointInterpolation< Type >
	TypeName ("volPointInterpolation")
	Runtime type information. More...

	volPointInterpolation (const VolField< Type > &psi)
	Construct from components. More...

	volPointInterpolation (const volPointInterpolation< Type > &i)
	Copy construct. More...

	volPointInterpolation (const VolField< Type > &psi, tmp< PointField< Type >> psip)
	Construct from components. More...

virtual	~volPointInterpolation ()

const PointField< Type > &	psip () const
	Access the point field. More...

Additional Inherited Members
Protected Attributes inherited from volPointInterpolation< Type >
const PointField< Type >	psip_
	Interpolated volfield. More...

Detailed Description

template<class Type>
class Foam::interpolations::cellPointFace< Type >

Piecewise-linear interpolation method. Uses volPointInterpolation to create values on the points and linear surfaceInterpolation to create values at the face-centres. Then uses a face-centre tetrahedral decomposition to linearly interpolate between the values at the points, at the face-centres and at the cell-centres.

Source files

Definition at line 55 of file cellPointFace.H.

Constructor & Destructor Documentation

◆ cellPointFace() [1/2]

cellPointFace ( const VolField< Type > & psi )

Construct from components.

Definition at line 219 of file cellPointFace.C.

◆ cellPointFace() [2/2]

cellPointFace ( const cellPointFace< Type > & i )

Copy construct.

Definition at line 231 of file cellPointFace.C.

Member Function Documentation

◆ TypeName()

TypeName ( "cellPointFace< Type >" )

Runtime type information.

◆ clone()

virtual autoPtr<interpolation<Type> > clone ( ) const

inlinevirtual

Clone.

Definition at line 110 of file cellPointFace.H.

◆ interpolate()

Type interpolate	(	const vector &	position,
		const label	celli,
		const label	facei = `-1`
	)		const

Interpolate field to the given point in the given cell.

Definition at line 245 of file cellPointFace.C.

References Foam::endl(), forAll, InfoInFunction, Foam::mag(), Foam::max(), Foam::min(), n, patchi, Foam::tracking::position(), List< T >::size(), Foam::tab, and Foam::Zero.

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/interpolation/interpolation/cellPointFace/cellPointFace.H
src/finiteVolume/interpolation/interpolation/cellPointFace/cellPointFace.C
