Public Member Functions | List of all members
hardSphereGroupSurfaceAreaVolumeRatioFvScalarFieldSource Class Reference

This source condition creates an interfacial mass transfer source term in the group surface-area-to-volume-ratio (kappa) equations of the fractal shape model of a population balance model, using a hard-sphere assumption. More...

Inheritance diagram for hardSphereGroupSurfaceAreaVolumeRatioFvScalarFieldSource:
Inheritance graph
[legend]
Collaboration diagram for hardSphereGroupSurfaceAreaVolumeRatioFvScalarFieldSource:
Collaboration graph
[legend]

Public Member Functions

 TypeName ("hardSphereGroupSurfaceAreaVolumeRatio")
 Runtime type information. More...

virtual autoPtr< fvScalarFieldSource > clone (const DimensionedField< scalar, fvMesh > &iF) const
 Construct and return a clone setting internal field reference. More...

virtual tmp< DimensionedField< scalar, fvMesh > > value (const label j, const fvSource &model) const
 Return the value transported from an adjacent group. More...

- Public Member Functions inherited from growthSecondaryPropertyFvScalarFieldSource
 growthSecondaryPropertyFvScalarFieldSource (const DimensionedField< scalar, fvMesh > &, const dictionary &dict)
 Construct from internal field and dictionary. More...

 growthSecondaryPropertyFvScalarFieldSource (const growthSecondaryPropertyFvScalarFieldSource &, const DimensionedField< scalar, fvMesh > &)
 Copy constructor setting internal field reference. More...

virtual tmp< DimensionedField< scalar, fvMesh > > internalCoeff (const fvSource &model, const DimensionedField< scalar, fvMesh > &source) const
 Return the internal coefficient. More...

virtual Pair< tmp< DimensionedField< scalar, fvMesh > > > sourceCoeffs (const fvSource &model) const
 Return the source coefficients for exchange with the groups below. More...

virtual tmp< DimensionedField< scalar, fvMesh > > sourceCoeff (const fvSource &model, const DimensionedField< scalar, fvMesh > &source) const
 Return the combined source coefficient. More...

- Public Member Functions inherited from growthFvScalarFieldSource
virtual tmp< DimensionedField< scalar, fvMesh > > sourceValue (const fvSource &model, const DimensionedField< scalar, fvMesh > &source) const
 Return the source value. Not Implemented. More...

- Public Member Functions inherited from groupPropertyFvScalarField
 groupPropertyFvScalarField (const DimensionedField< scalar, fvMesh > &)
 Construct from internal field. More...

const populationBalanceModel & popBal () const
 Return the population balance. More...

label i () const
 Return the index of this group. More...


Detailed Description

This source condition creates an interfacial mass transfer source term in the group surface-area-to-volume-ratio (kappa) equations of the fractal shape model of a population balance model, using a hard-sphere assumption.

Usage
Example of the source condition specification:
<sourceName>
{
    type            hardSphereGroupSurfaceAreaVolumeRatio;
    libs            ("libmultiphaseEulerFvModels.so");
}
Source files

Definition at line 60 of file hardSphereGroupSurfaceAreaVolumeRatioFvScalarFieldSource.H.

Member Function Documentation

◆ TypeName()

TypeName ( "hardSphereGroupSurfaceAreaVolumeRatio"  )

Runtime type information.

◆ clone()

virtual autoPtr<fvScalarFieldSource> clone ( const DimensionedField< scalar, fvMesh > &  iF) const
inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 78 of file hardSphereGroupSurfaceAreaVolumeRatioFvScalarFieldSource.H.

◆ value()

Foam::tmp< Foam::DimensionedField< Foam::scalar, Foam::fvMesh > > value ( const label  j,
const fvSource &  model
) const
virtual

Return the value transported from an adjacent group.

Implements growthSecondaryPropertyFvScalarFieldSource.

Definition at line 33 of file hardSphereGroupSurfaceAreaVolumeRatioFvScalarFieldSource.C.

References populationBalanceModel::dSph(), fractal::fld(), groupPropertyFvScalarField::i(), groupPropertyFvScalarField::popBal(), and populationBalanceModel::shape().

Here is the call graph for this function:
The documentation for this class was generated from the following files:
