Classes | Public Member Functions | Static Public Member Functions | List of all members
fvConstraint Class Referenceabstract

Finite volume options abstract base class. More...

Inheritance diagram for fvConstraint:
Inheritance graph
[legend]

Classes

class  iNew
 Return pointer to new fvConstraint object created. More...


Public Member Functions

 TypeName ("fvConstraint")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, fvConstraint, dictionary,(const word &name, const word &constraintType, const fvMesh &mesh, const dictionary &dict),(name, constraintType, mesh, dict))

 fvConstraint (const word &name, const word &constraintType, const fvMesh &mesh, const dictionary &dict)
 Construct from components. More...

autoPtr< fvConstraint > clone () const
 Return clone. More...

virtual ~fvConstraint ()
 Destructor. More...

const word & name () const
 Return const access to the source name. More...

const fvMesh & mesh () const
 Return const access to the mesh database. More...

const dictionary & coeffs () const
 Return dictionary. More...

virtual wordList constrainedFields () const
 Return the list of constrained fields. More...

virtual bool constrainsField (const word &fieldName) const
 Return true if the given field is constrained. More...

 FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN)
 Apply a constraint to an equation. More...

 FOR_ALL_FIELD_TYPES (DEFINE_FV_CONSTRAINT_CONSTRAIN_FIELD)
 Apply constraint to a field. More...

virtual bool movePoints ()=0
 Update for mesh motion. More...

virtual void topoChange (const polyTopoChangeMap &)=0
 Update topology using the given map. More...

virtual void mapMesh (const polyMeshMap &)=0
 Update from another mesh using the given map. More...

virtual void distribute (const polyDistributionMap &)=0
 Redistribute or update using the given distribution map. More...

virtual bool read (const dictionary &dict)
 Read source dictionary. More...


Static Public Member Functions

static autoPtr< fvConstraint > New (const word &name, const fvMesh &mesh, const dictionary &dict)
 Return a reference to the selected fvConstraint. More...


Detailed Description

Finite volume options abstract base class.

Source files

Definition at line 56 of file fvConstraint.H.

Constructor & Destructor Documentation

◆ fvConstraint()

fvConstraint ( const word &  name,
const word &  constraintType,
const fvMesh &  mesh,
const dictionary &  dict
)

Construct from components.

Definition at line 60 of file fvConstraint.C.

References Foam::decrIndent(), Foam::endl(), Foam::incrIndent(), Foam::indent(), and Foam::Info.

Here is the call graph for this function:

◆ ~fvConstraint()

~fvConstraint ( )
virtual

Destructor.

Definition at line 142 of file fvConstraint.C.

Member Function Documentation

◆ TypeName()

TypeName ( "fvConstraint"  )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable ( autoPtr  ,
fvConstraint  ,
dictionary  ,
(const word &name, const word &constraintType, const fvMesh &mesh, const dictionary &dict)  ,
(name, constraintType, mesh, dict)
)

◆ clone()

autoPtr<fvConstraint> clone ( ) const
inline

Return clone.

Definition at line 126 of file fvConstraint.H.

References NotImplemented.

◆ New()

Foam::autoPtr< Foam::fvConstraint > New ( const word &  name,
const fvMesh &  mesh,
const dictionary &  dict
)
static

Return a reference to the selected fvConstraint.

Definition at line 81 of file fvConstraint.C.

References dict, Foam::endl(), Foam::exit(), Foam::FatalError, FatalErrorInFunction, Foam::FatalIOError, FatalIOErrorInFunction, Foam::indent(), Foam::Info, Foam::libs, dictionary::lookup(), Foam::name(), Foam::nl, dlLibraryTable::open(), and string::remove().

Referenced by fvConstraints::fvConstraints(), and fvConstraint::iNew::operator()().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ name()

const Foam::word & name ( ) const
inline

Return const access to the source name.

Definition at line 28 of file fvConstraintI.H.

Referenced by fvConstraints::constrain(), and fvConstraints::read().

Here is the caller graph for this function:

◆ mesh()

const Foam::fvMesh & mesh ( ) const
inline

Return const access to the mesh database.

Definition at line 34 of file fvConstraintI.H.

Referenced by meanVelocityForce::meanVelocityForce(), and zeroDimensionalFixedPressureConstraint::zeroDimensionalFixedPressureConstraint().

Here is the caller graph for this function:

◆ coeffs()

const Foam::dictionary & coeffs ( ) const
inline

Return dictionary.

Definition at line 40 of file fvConstraintI.H.

◆ constrainedFields()

Foam::wordList constrainedFields ( ) const
virtual

Return the list of constrained fields.

Reimplemented in zeroDimensionalFixedPressureConstraint, meanVelocityForce, limitTemperature, limitPressure, limitMag, fixedValueConstraint, fixedTemperatureConstraint, and bound.

Definition at line 148 of file fvConstraint.C.

References List< word >::null().

Here is the call graph for this function:

◆ constrainsField()

bool constrainsField ( const word &  fieldName) const
virtual

Return true if the given field is constrained.

Definition at line 154 of file fvConstraint.C.

References Foam::findIndex().

Referenced by fvConstraints::constrain().

Here is the call graph for this function:
Here is the caller graph for this function:

◆ FOR_ALL_FIELD_TYPES() [1/2]

FOR_ALL_FIELD_TYPES ( DEFINE_FV_CONSTRAINT_CONSTRAIN  )

Apply a constraint to an equation.

◆ FOR_ALL_FIELD_TYPES() [2/2]

FOR_ALL_FIELD_TYPES ( DEFINE_FV_CONSTRAINT_CONSTRAIN_FIELD  )

Apply constraint to a field.

◆ movePoints()

virtual bool movePoints ( )
pure virtual

Update for mesh motion.

Implemented in zeroDimensionalFixedPressureConstraint, meanVelocityForce, limitTemperature, limitPressure, limitMag, fixedValueConstraint, fixedTemperatureConstraint, and bound.

◆ topoChange()

virtual void topoChange ( const polyTopoChangeMap &  )
pure virtual

Update topology using the given map.

Implemented in zeroDimensionalFixedPressureConstraint, meanVelocityForce, limitTemperature, limitPressure, limitMag, fixedValueConstraint, fixedTemperatureConstraint, and bound.

◆ mapMesh()

virtual void mapMesh ( const polyMeshMap &  )
pure virtual

Update from another mesh using the given map.

Implemented in zeroDimensionalFixedPressureConstraint, meanVelocityForce, limitTemperature, limitPressure, limitMag, fixedValueConstraint, fixedTemperatureConstraint, and bound.

◆ distribute()

virtual void distribute ( const polyDistributionMap &  )
pure virtual

Redistribute or update using the given distribution map.

Implemented in zeroDimensionalFixedPressureConstraint, meanVelocityForce, limitTemperature, limitPressure, limitMag, fixedValueConstraint, fixedTemperatureConstraint, and bound.

◆ read()

bool read ( const dictionary &  dict)
virtual

Read source dictionary.

Reimplemented in zeroDimensionalFixedPressureConstraint, patchMeanVelocityForce, meanVelocityForce, limitTemperature, limitPressure, limitMag, fixedValueConstraint, fixedTemperatureConstraint, and bound.

Definition at line 166 of file fvConstraint.C.

References dict, and dictionary::optionalSubDict().

Referenced by fvConstraints::read(), bound::read(), fixedTemperatureConstraint::read(), fixedValueConstraint::read(), limitMag::read(), limitPressure::read(), limitTemperature::read(), meanVelocityForce::read(), and zeroDimensionalFixedPressureConstraint::read().

Here is the call graph for this function:
Here is the caller graph for this function:
The documentation for this class was generated from the following files:
