This function calculates the fluid and acceleration forces and moments at a number of section-planes through a given rigid body. It writes the result into a log file. More...
Public Member Functions | |
| TypeName ("rigidBodySectionalForceProbes") | |
| Runtime type information. More... | |
| rigidBodySectionalForceProbes (const word &name, const Time &runTime, const dictionary &dict) | |
| Construct from Time and dictionary. More... | |
| rigidBodySectionalForceProbes (const rigidBodySectionalForceProbes &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~rigidBodySectionalForceProbes () |
| Destructor. More... | |
| virtual bool | read (const dictionary &) |
| Read the rigidBodySectionalForceProbes data. More... | |
| virtual bool | write () |
| Write the rigidBodySectionalForceProbes. More... | |
| void | operator= (const rigidBodySectionalForceProbes &)=delete |
| Disallow default bitwise assignment. More... | |
 Public Member Functions inherited from rigidBodySectionalForcesBase | |
| TypeName ("rigidBodySectionalForcesBase") | |
| Runtime type information. More... | |
| rigidBodySectionalForcesBase (const word &name, const Time &runTime, const dictionary &dict) | |
| Construct from Time and dictionary. More... | |
| rigidBodySectionalForcesBase (const rigidBodySectionalForcesBase &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~rigidBodySectionalForcesBase () |
| Destructor. More... | |
| virtual void | movePoints (const polyMesh &) |
| Update for mesh point-motion. More... | |
| void | operator= (const rigidBodySectionalForcesBase &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from sectionalForcesBase | |
| TypeName ("sectionalForcesBase") | |
| Runtime type information. More... | |
| sectionalForcesBase (const word &name, const Time &runTime, const dictionary &dict) | |
| Construct from Time and dictionary. More... | |
| sectionalForcesBase (const sectionalForcesBase &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~sectionalForcesBase () |
| Destructor. More... | |
| virtual wordList | fields () const |
| Return the list of fields required. More... | |
| virtual bool | execute () |
| Execute, currently does nothing. More... | |
| virtual bool | end () |
| Execute at the final time-loop, currently does nothing. More... | |
| virtual void | topoChange (const polyTopoChangeMap &) |
| Update topology using the given map. More... | |
| virtual void | mapMesh (const polyMeshMap &) |
| Update from another mesh using the given map. More... | |
| virtual void | distribute (const polyDistributionMap &) |
| Redistribute or update using the given distribution map. More... | |
| void | operator= (const sectionalForcesBase &)=delete |
| Disallow default bitwise assignment. More... | |
| template<class Type > | |
| Foam::tmp< Foam::SurfaceField< Type > > | timesAlpha (const tmp< SurfaceField< Type >> psi) const |
| template<class Type > | |
| Foam::tmp< Foam::Field< Type > > | timesAlpha (const tmp< Field< Type >> psi, const label patchi) const |
| template<class Type > | |
| Foam::tmp< Foam::SurfaceField< Type > > | timesRho (const tmp< SurfaceField< Type >> psi) const |
| template<class Type > | |
| Foam::tmp< Foam::SurfaceField< Type > > | timesAlphaRho (const tmp< SurfaceField< Type >> psi) const |
| Public Member Functions inherited from fvMeshFunctionObject | |
| TypeName ("fvMeshFunctionObject") | |
| Runtime type information. More... | |
| fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict) | |
| Construct from Time and dictionary. More... | |
| fvMeshFunctionObject (const word &name, const objectRegistry &obr) | |
| Construct from the region objectRegistry. More... | |
| fvMeshFunctionObject (const fvMeshFunctionObject &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~fvMeshFunctionObject () |
| Destructor. More... | |
| const fvMesh & | mesh () const |
| Return a reference to the mesh. More... | |
| void | operator= (const fvMeshFunctionObject &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from regionFunctionObject | |
| TypeName ("regionFunctionObject") | |
| Runtime type information. More... | |
| regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict) | |
| Construct from Time and dictionary. More... | |
| regionFunctionObject (const word &name, const objectRegistry &obr) | |
| Construct from the region objectRegistry. More... | |
| regionFunctionObject (const regionFunctionObject &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~regionFunctionObject () |
| Destructor. More... | |
| void | operator= (const regionFunctionObject &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from objectRegistryFunctionObject | |
| TypeName ("objectRegistryFunctionObject") | |
| Runtime type information. More... | |
| objectRegistryFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict) | |
| Construct from an objectRegistry and dictionary. More... | |
| objectRegistryFunctionObject (const word &name, const objectRegistry &obr) | |
| Construct from an objectRegistry. More... | |
| objectRegistryFunctionObject (const objectRegistryFunctionObject &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~objectRegistryFunctionObject () |
| Destructor. More... | |
| void | operator= (const objectRegistryFunctionObject &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from functionObject | |
| ClassName ("functionObject") | |
| virtual const word & | type () const =0 |
| Runtime type information. More... | |
| declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict)) | |
| functionObject (const word &name, const Time &runTime) | |
| Construct from components. More... | |
| functionObject (const word &name, const Time &runTime, const dictionary &dict) | |
| Construct from dictionary. More... | |
| autoPtr< functionObject > | clone () const |
| Return clone. More... | |
| functionObject (const functionObject &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~functionObject () |
| Destructor. More... | |
| const word & | name () const |
| Return the name of this functionObject. More... | |
| virtual bool | executeAtStart () const |
| Return true if the functionObject should be executed at the start. More... | |
| virtual scalar | timeToNextAction () |
| Called by Time::adjustTimeStep(). Allows the functionObject to. More... | |
| virtual scalar | maxDeltaT () const |
| Return the maximum time-step for stable operation. More... | |
| void | operator= (const functionObject &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from logFiles | |
| logFiles (const objectRegistry &obr, const word &prefix) | |
| Construct from objectRegistry and prefix. More... | |
| logFiles (const logFiles &)=delete | |
| Disallow default bitwise copy construction. More... | |
| virtual | ~logFiles () |
| Destructor. More... | |
| const wordList & | toc () const |
| Return the list of log file names. More... | |
| const wordList & | names () const |
| Return the list of log file names. More... | |
| PtrList< OFstream > & | files () |
| Return access to the files. More... | |
| OFstream & | file () |
| Return access to the file (if only 1) More... | |
| OFstream & | file (const label i) |
| Return file 'i'. More... | |
| void | operator= (const logFiles &)=delete |
| Disallow default bitwise assignment. More... | |
| Public Member Functions inherited from writeFile | |
| writeFile (const objectRegistry &obr, const word &prefix) | |
| Construct from objectRegistry and prefix. More... | |
| writeFile (const writeFile &)=delete | |
| Disallow default bitwise copy construction. More... | |
| ~writeFile () | |
| Destructor. More... | |
| void | initStream (Ostream &os) const |
| Initialise the output stream for writing. More... | |
| fileName | baseFileDir () const |
| Return the base directory for output. More... | |
| fileName | baseTimeDir () const |
| Return the base directory for the current time value. More... | |
| Omanip< int > | valueWidth (const label offset=0) const |
| Return the value width when writing to stream with optional offset. More... | |
| void | writeCommented (Ostream &os, const string &str) const |
| Write a commented string to stream. More... | |
| void | writeTabbed (Ostream &os, const string &str) const |
| Write a tabbed string to stream. More... | |
| void | writeHeader (Ostream &os, const string &str) const |
| Write a commented header to stream. More... | |
| void | writeTime (Ostream &os) const |
| Write the current time to stream. More... | |
| template<class Type > | |
| void | writeHeaderValue (Ostream &os, const string &property, const Type &value) const |
| Write a (commented) header property and value pair. More... | |
| label | charWidth () const |
| Return width of character stream output. More... | |
| void | operator= (const writeFile &)=delete |
| Disallow default bitwise assignment. More... | |
Additional Inherited Members | |
| Static Public Member Functions inherited from functionObject | |
| static autoPtr< functionObject > | New (const word &name, const Time &, const dictionary &) |
| Select from dictionary, based on its "type" entry. More... | |
| Public Attributes inherited from functionObject | |
| Switch | log |
| Switch write log to Info. More... | |
| Switch | executeAtStart_ |
| Switch execute at start time. More... | |
| Static Public Attributes inherited from functionObject | |
| static bool | postProcess |
| Global post-processing mode switch. More... | |
| Static Public Attributes inherited from writeFile | |
| static const word | outputPrefix |
| Directory prefix. More... | |
| static label | addChars = 8 |
| Additional characters for writing. More... | |
| Protected Member Functions inherited from rigidBodySectionalForcesBase | |
| const RBD::rigidBodyMotion & | motion () const |
| Return the motion system. More... | |
| label | bodyIndex () const |
| Return the index of the body. More... | |
| const RBD::rigidBody & | body () const |
| Return the body. More... | |
| label | axisi () const |
| Return the axis on which to plot the result. More... | |
| const word & | axisName () const |
| Return the name of the axis on which to plot the result. More... | |
| vector | axis () const |
| Return the vector axis on which to plot the result. Note that this. More... | |
| const point & | localOrigin () const |
| Return the local origin of the plot. More... | |
| virtual vector | normal () const |
| Return the normal to the section planes. More... | |
| virtual point | origin () const |
| Return the origin of the plot. More... | |
| void | addFluid (vectorField &force, vectorField &moment) const |
| Calculate the forces and moments at the cuts. More... | |
| void | addBody (vectorField &force, vectorField &moment) const |
| Calculate the forces and moments at the cuts. More... | |
| Protected Member Functions inherited from sectionalForcesBase | |
| virtual void | clear () |
| Clear the cached weights. More... | |
| const indirectPrimitivePatch & | patch () const |
| Access the primitive patch. More... | |
| void | clearPatch () |
| Clear the patch. More... | |
| void | clearPatchGeom () |
| Clear the patch geometry. More... | |
| tmp< scalarField > | patchPointDistances () const |
| Return the distance from the origin to the patch points. More... | |
| const List< patchCutPlot::weight > & | weights () const |
| Access the weights. More... | |
| fileName | outputPath () const |
| Return the output path. More... | |
| void | addFluid (vectorField &force, vectorField &moment) const |
| Calculate the forces and moments at the cuts. More... | |
| Protected Member Functions inherited from objectRegistryFunctionObject | |
| template<class ObjectType > | |
| bool | foundObject (const word &fieldName) const |
| Find field in the objectRegistry. More... | |
| template<class ObjectType > | |
| void | cannotFindObject (const word &fieldName) |
| Prints a warning message that fieldName cannot be found. More... | |
| void | cannotFindObject (const word &fieldName) |
| Prints a warning message that fieldName cannot be found. More... | |
| void | cannotFindObjects (const wordList &fieldNames) |
| Prints a warning message that fieldNames cannot be found. More... | |
| template<class ObjectType > | |
| const ObjectType & | lookupObject (const word &fieldName) const |
| Lookup object from the objectRegistry. More... | |
| template<class ObjectType > | |
| ObjectType & | lookupObjectRef (const word &fieldName) |
| Lookup non-const object reference from the objectRegistry. More... | |
| template<class ObjectType > | |
| ObjectType & | store (const tmp< ObjectType > &tfield) |
| Store the given field in the objectRegistry. More... | |
| template<class ObjectType > | |
| ObjectType & | store (const word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false) |
| Store the given field in the objectRegistry under the given name. More... | |
| bool | writeObject (const word &fieldName) |
| Write field if present in objectRegistry. More... | |
| bool | clearObject (const word &fieldName) |
| Clear field from the objectRegistry if present. More... | |
| Protected Member Functions inherited from logFiles | |
| virtual void | createFiles () |
| Create the output file. More... | |
| virtual void | resetNames (const wordList &names) |
| Reset the list of names from a wordList. More... | |
| virtual void | resetName (const word &name) |
| Reset the list of names to a single name entry. More... | |
| Protected Attributes inherited from fvMeshFunctionObject | |
| const fvMesh & | mesh_ |
| Reference to the fvMesh. More... | |
| Protected Attributes inherited from objectRegistryFunctionObject | |
| const objectRegistry & | obr_ |
| Reference to the objectRegistry. More... | |
| Protected Attributes inherited from functionObject | |
| const Time & | time_ |
| Reference to time. More... | |
| Protected Attributes inherited from logFiles | |
| wordList | names_ |
| File names. More... | |
| PtrList< OFstream > | filePtrs_ |
| File pointer. More... | |
| Protected Attributes inherited from writeFile | |
| const objectRegistry & | fileObr_ |
| Reference to the region objectRegistry. More... | |
| const word | prefix_ |
| Prefix. More... | |
This function calculates the fluid and acceleration forces and moments at a number of section-planes through a given rigid body. It writes the result into a log file.
The cut-planes are defined as normal to an axis in the local coordinate system of the rigid body, and through a number of coordinates along that axis.
Note that this function does not take into account the effect of joints or restraints attached to the body, so if these are applied then the forces generated will be somewhat incomplete. Note that ramping, acceleration relaxation, and solution tolerance can also result in components of the forces and moments to be missing from the output.
Example of function object specification
rigidBodySectionalForceProbes
{
type rigidBodySectionalForceProbes;
libs ("librigidBodyForces.so");
body beam;
patches (beam);
axis x;
coordinates (4.2 5 5.8);
}
| Property | Description | Required | Default value |
|---|---|---|---|
type | Type name: rigidBodySectionalForceProbes | yes | |
body | The name of the rigid body | yes | |
patches | Patches included in the forces calculation | yes | |
axis | Local axis normal to the section planes | yes | |
coordinates | Coordinates of the section planes | yes | |
p | Pressure field name | no | p |
U | Velocity field name | no | U |
rho | Density field name | no | rho |
phase | Phase name for phase-fraction | no | |
rhoRef | Reference density | if incompressible | |
pRef | Reference pressure | no | 0 |
Definition at line 152 of file rigidBodySectionalForceProbes.H.
| rigidBodySectionalForceProbes | ( | const word & | name, |
| const Time & | runTime, | ||
| const dictionary & | dict | ||
| ) |
Construct from Time and dictionary.
Definition at line 128 of file rigidBodySectionalForceProbes.C.
References dict, and rigidBodySectionalForceProbes::read().
|
delete |
Disallow default bitwise copy construction.
|
virtual |
Destructor.
Definition at line 147 of file rigidBodySectionalForceProbes.C.
| TypeName | ( | "rigidBodySectionalForceProbes" | ) |
Runtime type information.
|
virtual |
Read the rigidBodySectionalForceProbes data.
Reimplemented from rigidBodySectionalForcesBase.
Definition at line 154 of file rigidBodySectionalForceProbes.C.
References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, rigidBodySectionalForcesBase::read(), and Foam::sortedOrder().
Referenced by rigidBodySectionalForceProbes::rigidBodySectionalForceProbes().
|
virtual |
Write the rigidBodySectionalForceProbes.
Reimplemented from logFiles.
Definition at line 179 of file rigidBodySectionalForceProbes.C.
References rigidBodySectionalForcesBase::addBody(), rigidBodySectionalForcesBase::addFluid(), Foam::file, forAll, Field< Type >::map(), UPstream::master(), logFiles::write(), and Foam::Zero.
|
delete |
Disallow default bitwise assignment.
1.9.1
