Inheritance diagram for rigidBodySectionalForceGraph:

Collaboration diagram for rigidBodySectionalForceGraph:

Public Member Functions
	TypeName ("rigidBodySectionalForceGraph")
	Runtime type information. More...

	rigidBodySectionalForceGraph (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	rigidBodySectionalForceGraph (const rigidBodySectionalForceGraph &)=delete
	Disallow default bitwise copy construction. More...

virtual	~rigidBodySectionalForceGraph ()
	Destructor. More...

virtual bool	read (const dictionary &)
	Read the rigidBodySectionalForceGraph data. More...

virtual bool	write ()
	Write the rigidBodySectionalForceGraph. More...

void	operator= (const rigidBodySectionalForceGraph &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from rigidBodySectionalForcesBase
	TypeName ("rigidBodySectionalForcesBase")
	Runtime type information. More...

	rigidBodySectionalForcesBase (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	rigidBodySectionalForcesBase (const rigidBodySectionalForcesBase &)=delete
	Disallow default bitwise copy construction. More...

virtual	~rigidBodySectionalForcesBase ()
	Destructor. More...

virtual void	movePoints (const polyMesh &)
	Update for mesh point-motion. More...

void	operator= (const rigidBodySectionalForcesBase &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from sectionalForcesBase
	TypeName ("sectionalForcesBase")
	Runtime type information. More...

	sectionalForcesBase (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	sectionalForcesBase (const sectionalForcesBase &)=delete
	Disallow default bitwise copy construction. More...

virtual	~sectionalForcesBase ()
	Destructor. More...

virtual wordList	fields () const
	Return the list of fields required. More...

virtual bool	execute ()
	Execute, currently does nothing. More...

virtual bool	end ()
	Execute at the final time-loop, currently does nothing. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

void	operator= (const sectionalForcesBase &)=delete
	Disallow default bitwise assignment. More...

template<class Type >
Foam::tmp< Foam::SurfaceField< Type > >	timesAlpha (const tmp< SurfaceField< Type >> psi) const

template<class Type >
Foam::tmp< Foam::Field< Type > >	timesAlpha (const tmp< Field< Type >> psi, const label patchi) const

template<class Type >
Foam::tmp< Foam::SurfaceField< Type > >	timesRho (const tmp< SurfaceField< Type >> psi) const

template<class Type >
Foam::tmp< Foam::SurfaceField< Type > >	timesAlphaRho (const tmp< SurfaceField< Type >> psi) const

Public Member Functions inherited from fvMeshFunctionObject
	TypeName ("fvMeshFunctionObject")
	Runtime type information. More...

	fvMeshFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	fvMeshFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	fvMeshFunctionObject (const fvMeshFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~fvMeshFunctionObject ()
	Destructor. More...

const fvMesh &	mesh () const
	Return a reference to the mesh. More...

void	operator= (const fvMeshFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from regionFunctionObject
	TypeName ("regionFunctionObject")
	Runtime type information. More...

	regionFunctionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from Time and dictionary. More...

	regionFunctionObject (const word &name, const objectRegistry &obr)
	Construct from the region objectRegistry. More...

	regionFunctionObject (const regionFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~regionFunctionObject ()
	Destructor. More...

void	operator= (const regionFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from objectRegistryFunctionObject
	TypeName ("objectRegistryFunctionObject")
	Runtime type information. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr, const dictionary &dict)
	Construct from an objectRegistry and dictionary. More...

	objectRegistryFunctionObject (const word &name, const objectRegistry &obr)
	Construct from an objectRegistry. More...

	objectRegistryFunctionObject (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~objectRegistryFunctionObject ()
	Destructor. More...

void	operator= (const objectRegistryFunctionObject &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from functionObject
	ClassName ("functionObject")

virtual const word &	type () const =0
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, functionObject, dictionary,(const word &name, const Time &runTime, const dictionary &dict),(name, runTime, dict))

	functionObject (const word &name, const Time &runTime)
	Construct from components. More...

	functionObject (const word &name, const Time &runTime, const dictionary &dict)
	Construct from dictionary. More...

autoPtr< functionObject >	clone () const
	Return clone. More...

	functionObject (const functionObject &)=delete
	Disallow default bitwise copy construction. More...

virtual	~functionObject ()
	Destructor. More...

const word &	name () const
	Return the name of this functionObject. More...

virtual bool	executeAtStart () const
	Return true if the functionObject should be executed at the start. More...

virtual scalar	timeToNextAction ()
	Called by Time::adjustTimeStep(). Allows the functionObject to. More...

virtual scalar	maxDeltaT () const
	Return the maximum time-step for stable operation. More...

void	operator= (const functionObject &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Static Public Member Functions inherited from functionObject
static autoPtr< functionObject >	New (const word &name, const Time &, const dictionary &)
	Select from dictionary, based on its "type" entry. More...

Public Attributes inherited from functionObject
Switch	log
	Switch write log to Info. More...

Switch	executeAtStart_
	Switch execute at start time. More...

Static Public Attributes inherited from functionObject
static bool	postProcess
	Global post-processing mode switch. More...

Protected Member Functions inherited from rigidBodySectionalForcesBase
const RBD::rigidBodyMotion &	motion () const
	Return the motion system. More...

label	bodyIndex () const
	Return the index of the body. More...

const RBD::rigidBody &	body () const
	Return the body. More...

label	axisi () const
	Return the axis on which to plot the result. More...

const word &	axisName () const
	Return the name of the axis on which to plot the result. More...

vector	axis () const
	Return the vector axis on which to plot the result. Note that this. More...

const point &	localOrigin () const
	Return the local origin of the plot. More...

virtual vector	normal () const
	Return the normal to the section planes. More...

virtual point	origin () const
	Return the origin of the plot. More...

void	addFluid (vectorField &force, vectorField &moment) const
	Calculate the forces and moments at the cuts. More...

void	addBody (vectorField &force, vectorField &moment) const
	Calculate the forces and moments at the cuts. More...

Protected Member Functions inherited from sectionalForcesBase
const indirectPrimitivePatch &	patch () const
	Access the primitive patch. More...

void	clearPatch ()
	Clear the patch. More...

void	clearPatchGeom ()
	Clear the patch geometry. More...

tmp< scalarField >	patchPointDistances () const
	Return the distance from the origin to the patch points. More...

const List< patchCutPlot::weight > &	weights () const
	Access the weights. More...

fileName	outputPath () const
	Return the output path. More...

void	addFluid (vectorField &force, vectorField &moment) const
	Calculate the forces and moments at the cuts. More...

Protected Member Functions inherited from objectRegistryFunctionObject
template<class ObjectType >
bool	foundObject (const word &fieldName) const
	Find field in the objectRegistry. More...

template<class ObjectType >
void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObject (const word &fieldName)
	Prints a warning message that fieldName cannot be found. More...

void	cannotFindObjects (const wordList &fieldNames)
	Prints a warning message that fieldNames cannot be found. More...

template<class ObjectType >
const ObjectType &	lookupObject (const word &fieldName) const
	Lookup object from the objectRegistry. More...

template<class ObjectType >
ObjectType &	lookupObjectRef (const word &fieldName)
	Lookup non-const object reference from the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const tmp< ObjectType > &tfield)
	Store the given field in the objectRegistry. More...

template<class ObjectType >
ObjectType &	store (const word &fieldName, const tmp< ObjectType > &tfield, bool cacheable=false)
	Store the given field in the objectRegistry under the given name. More...

bool	writeObject (const word &fieldName)
	Write field if present in objectRegistry. More...

bool	clearObject (const word &fieldName)
	Clear field from the objectRegistry if present. More...

Protected Attributes inherited from fvMeshFunctionObject
const fvMesh &	mesh_
	Reference to the fvMesh. More...

Protected Attributes inherited from objectRegistryFunctionObject
const objectRegistry &	obr_
	Reference to the objectRegistry. More...

Protected Attributes inherited from functionObject
const Time &	time_
	Reference to time. More...

Detailed Description

Description This function calculates the fluid and acceleration forces and moments at a series of section-planes through a given rigid body. It writes the result into a graph which can be used to construct (potentially just a part of) a shear force and bending moment diagram. Points in the graph are graded to approximately match the resolution of the mesh.

The cut-planes are defined as normal to an axis in the local coordinate system of the rigid body, and the line of the graph extends along the axis from an origin defined in the same local coordinate system. Forces and moments are calculated on the side of the plane on which coordinates have a positive axis-component.

Note that this function does not take into account the effect of joints or restraints attached to the body, so if these are applied then the shear force and bending moment diagrams generated will be somewhat incomplete. Note that ramping, acceleration relaxation, and solution tolerance can also result in components of the forces and moments to be missing from the output.

Example of function object specification:

    rigidBodySectionalForceGraph
    {
        type            rigidBodySectionalForceGraph;
        libs            ("librigidBodyForces.so");
        body            beam;
        patches         (beam);
        axis            x;
        nPoints         101;
        setFormat       raw;
        writeControl    writeTime;
    }

Usage

Property	Description	Required	Default value
`type`	Type name: rigidBodySectionalForceGraph	yes
`body`	The name of the rigid body	yes
`patches`	Patches included in the forces calculation	yes
`axis`	Local axis normal to the section planes	yes
`origin`	Local origin of the plot	no	body centroid
`nPoints`	Number of points in the plot	yes
`setFormat`	Graph output format	yes
`p`	Pressure field name	no	p
`U`	Velocity field name	no	U
`rho`	Density field name	no	rho
`phase`	Phase name for phase-fraction	no
`rhoRef`	Reference density	if incompressible
`pRef`	Reference pressure	no	0

Source files

Definition at line 170 of file rigidBodySectionalForceGraph.H.

Constructor & Destructor Documentation

◆ rigidBodySectionalForceGraph() [1/2]

rigidBodySectionalForceGraph	(	const word &	name,
		const Time &	runTime,
		const dictionary &	dict
	)

Construct from Time and dictionary.

Definition at line 88 of file rigidBodySectionalForceGraph.C.

References dict, and rigidBodySectionalForceGraph::read().

Here is the call graph for this function:

◆ rigidBodySectionalForceGraph() [2/2]

rigidBodySectionalForceGraph ( const rigidBodySectionalForceGraph & )

delete

Disallow default bitwise copy construction.

◆ ~rigidBodySectionalForceGraph()

~rigidBodySectionalForceGraph ( )

virtual

Destructor.

Definition at line 108 of file rigidBodySectionalForceGraph.C.

Member Function Documentation

◆ TypeName()

TypeName ( "rigidBodySectionalForceGraph" )

Runtime type information.

◆ read()

bool read ( const dictionary & dict )

virtual

Read the rigidBodySectionalForceGraph data.

Reimplemented from rigidBodySectionalForcesBase.

Definition at line 115 of file rigidBodySectionalForceGraph.C.

References dict, setWriter::New(), and rigidBodySectionalForcesBase::read().

Referenced by rigidBodySectionalForceGraph::rigidBodySectionalForceGraph().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ write()

bool write ( )

virtual

Write the rigidBodySectionalForceGraph.

Implements functionObject.

Definition at line 132 of file rigidBodySectionalForceGraph.C.

References rigidBodySectionalForcesBase::addBody(), rigidBodySectionalForcesBase::addFluid(), coordSet::axisTypeNames_, DeclareTypeFieldValues, coordSet::DISTANCE, fieldNames, Foam::FOR_ALL_FIELD_TYPES(), forAll, UPstream::master(), Foam::mkDir(), List< T >::size(), TypeFieldValuesParameter, and VectorSpace< Form, Cmpt, Ncmpts >::zero.

Here is the call graph for this function:

◆ operator=()

void operator= ( const rigidBodySectionalForceGraph & )

delete

Disallow default bitwise assignment.

The documentation for this class was generated from the following files:

src/rigidBodyMotion/rigidBodyForces/rigidBodySectionalForceGraph/rigidBodySectionalForceGraph.H
src/rigidBodyMotion/rigidBodyForces/rigidBodySectionalForceGraph/rigidBodySectionalForceGraph.C

Public Member Functions

Additional Inherited Members

Detailed Description

Constructor & Destructor Documentation

◆ rigidBodySectionalForceGraph() [1/2]

◆ rigidBodySectionalForceGraph() [2/2]

◆ ~rigidBodySectionalForceGraph()

Member Function Documentation

◆ TypeName()

◆ read()

◆ write()

◆ operator=()
