Kusters Class Reference

Solid particle breakage model of Kusters (1991). The breakage rate is calculated by. More...

Inheritance diagram for Kusters:
Collaboration diagram for Kusters:

Public Member Functions

 TypeName ("Kusters")
 Runtime type information. More...

 Kusters (const populationBalanceModel &popBal, const dictionary &dict)

virtual ~Kusters ()
 Destructor. More...

virtual void setBreakupRate (volScalarField &breakupRate, const label i)
 Set total breakupRate. More...

- Public Member Functions inherited from breakupModel
 TypeName ("breakupModel")
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, breakupModel, dictionary,(const populationBalanceModel &popBal, const dictionary &dict),(popBal, dict))

 breakupModel (const populationBalanceModel &popBal, const dictionary &dict)

autoPtr< breakupModelclone () const

virtual ~breakupModel ()
 Destructor. More...

const populationBalanceModelpopBal () const
 Return reference to the populationBalanceModel. More...

const autoPtr< daughterSizeDistributionModel > & dsdPtr () const
 Return const-reference to daughter size distribution pointer. More...

autoPtr< daughterSizeDistributionModel > & dsdPtr ()
 Return reference to daughter size distribution pointer. More...

virtual void precompute ()
 Precompute diameter independent expressions. More...


Additional Inherited Members

- Static Public Member Functions inherited from breakupModel
static autoPtr< breakupModelNew (const word &type, const populationBalanceModel &popBal, const dictionary &dict)

- Protected Attributes inherited from breakupModel
const populationBalanceModelpopBal_
 Reference to the populationBalanceModel. More...

dictionary dict_
 Dictionary. More...

autoPtr< daughterSizeDistributionModeldsd_
 Daughter size distribution model. More...


Detailed Description

Solid particle breakage model of Kusters (1991). The breakage rate is calculated by.

\[ \sqrt{\frac{4}{15\pi}}\sqrt{\frac{\epsilon}{\nu}} \exp\left(-\frac{\epsilon_{crit}}{\epsilon}\right) \]

\[ \epsilon_{crit}=\frac{B}{R_{ci}} \]

\[ R_{ci} = 0.5d_{p}\left(\frac{n_i}{k_c}\right)^{1/D_f} \]

\[ n_i = \left(\frac{d_i}{d_{p}}\right)^{D_f} \]

where

$ B $ = Critical force parameter for breakage [m3/s3]
$ d_i $ = Diameter of transported particle [m]
$ d_{p} $ = Diameter of primary particles [m]
$ D_f $ = Fractal dimension of particle [-]
$ k_c $ = Constant relative to packing density [-]
$ n_i $ = Number of primary particles in agglomerate [-]
$ \nu $ = Kinematic viscosity of continuous phase [m2/s]
$ \epsilon $ = Continuous phase turbulent dissipation rate [m2/s3]
$ \epsilon_{crit} $ = Critical turbulent dissipation rate [m2/s3]

Reference:

        Kusters, K. A. (1991).
        The influence of turbulence on aggregation of small particles in
        agitated vessels.
        PhD Thesis
Source files

Definition at line 128 of file Kusters.H.

Constructor & Destructor Documentation

◆ Kusters()

Kusters ( const populationBalanceModel popBal,
const dictionary dict
)

Definition at line 53 of file Kusters.C.

◆ ~Kusters()

virtual ~Kusters ( )
inlinevirtual

Destructor.

Definition at line 162 of file Kusters.H.

Member Function Documentation

◆ TypeName()

TypeName ( "Kusters"  )

Runtime type information.

◆ setBreakupRate()

void setBreakupRate ( volScalarField breakupRate,
const label  i
)
virtual

Set total breakupRate.

Implements breakupModel.

Definition at line 69 of file Kusters.C.

References sizeGroup::d(), Foam::exp(), Foam::constant::mathematical::pi(), Foam::pow(), and Foam::sqrt().

Here is the call graph for this function:

The documentation for this class was generated from the following files:
