Cyclic front and back plane patch field. More...

Inheritance diagram for cyclicPointPatchField< Type >:

Collaboration diagram for cyclicPointPatchField< Type >:

Public Member Functions
	TypeName (cyclicPointPatch::typeName_())
	Runtime type information. More...

	cyclicPointPatchField (const pointPatch &, const DimensionedField< Type, pointMesh > &)
	Construct from patch and internal field. More...

	cyclicPointPatchField (const pointPatch &, const DimensionedField< Type, pointMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	cyclicPointPatchField (const cyclicPointPatchField< Type > &, const pointPatch &, const DimensionedField< Type, pointMesh > &, const pointPatchFieldMapper &)
	Construct by mapping given patchField<Type> onto a new patch. More...

	cyclicPointPatchField (const cyclicPointPatchField< Type > &, const DimensionedField< Type, pointMesh > &)
	Construct as copy setting internal field reference. More...

virtual autoPtr< pointPatchField< Type > >	clone (const DimensionedField< Type, pointMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual const transformer &	transform () const
	Return transformation between the coupled patches. More...

virtual void	evaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)
	Evaluate the patch field. More...

Public Member Functions inherited from coupledPointPatchField< Type >
	TypeName (coupledPointPatch::typeName_())
	Runtime type information. More...

	coupledPointPatchField (const pointPatch &, const DimensionedField< Type, pointMesh > &)
	Construct from patch and internal field. More...

	coupledPointPatchField (const pointPatch &, const DimensionedField< Type, pointMesh > &, const dictionary &dict)
	Construct from patch, internal field and dictionary. More...

	coupledPointPatchField (const coupledPointPatchField< Type > &, const pointPatch &, const DimensionedField< Type, pointMesh > &, const pointPatchFieldMapper &)
	Construct by mapping given patchField<Type> onto a new patch. More...

	coupledPointPatchField (const coupledPointPatchField< Type > &, const DimensionedField< Type, pointMesh > &)
	Construct as copy setting internal field reference. More...

virtual bool	coupled () const
	Return true if this patch field is derived from. More...

Public Member Functions inherited from pointPatchField< Type >
	TypeName ("pointPatchField")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, pointPatchField, pointPatch,(const pointPatch &p, const DimensionedField< Type, pointMesh > &iF),(p, iF))

	declareRunTimeSelectionTable (autoPtr, pointPatchField, patchMapper,(const pointPatchField< Type > &ptf, const pointPatch &p, const DimensionedField< Type, pointMesh > &iF, const pointPatchFieldMapper &m),(dynamic_cast< const pointPatchFieldType & >(ptf), p, iF, m))

	declareRunTimeSelectionTable (autoPtr, pointPatchField, dictionary,(const pointPatch &p, const DimensionedField< Type, pointMesh > &iF, const dictionary &dict),(p, iF, dict))

	pointPatchField (const pointPatch &, const DimensionedField< Type, pointMesh > &)
	Construct from patch and internal field. More...

	pointPatchField (const pointPatch &, const DimensionedField< Type, pointMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	pointPatchField (const pointPatchField< Type > &, const pointPatch &, const DimensionedField< Type, pointMesh > &, const pointPatchFieldMapper &)
	Construct by mapping given pointPatchField<Type> onto a new patch. More...

	pointPatchField (const pointPatchField< Type > &)=delete
	Disallow copy without setting internal field reference. More...

autoPtr< pointPatchField< Type > >	clone () const
	Disallow clone without setting internal field reference. More...

	pointPatchField (const pointPatchField< Type > &, const DimensionedField< Type, pointMesh > &)
	Construct as copy setting internal field reference. More...

virtual autoPtr< pointPatchField< Type > >	clone (const pointPatch &patch, const DimensionedField< Type, pointMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual	~pointPatchField ()
	Destructor. More...

label	size () const
	Return size. More...

virtual bool	fixesValue () const
	Return true if this patch field fixes a value. More...

bool	overridesConstraint () const
	Return true if this overrides the underlying constraint type. More...

const objectRegistry &	db () const
	Return local objectRegistry. More...

const pointPatch &	patch () const
	Return patch. More...

const DimensionedField< Type, pointMesh > &	internalField () const
	Return dimensioned internal field reference. More...

const Field< Type > &	primitiveField () const
	Return internal field reference. More...

bool	updated () const
	Return true if the boundary condition has already been updated. More...

tmp< Field< Type > >	patchInternalField () const
	Return field created from appropriate internal field values. More...

template<class Type1 >
tmp< Field< Type1 > >	patchInternalField (const Field< Type1 > &iF) const
	Return field created from appropriate internal field values. More...

template<class Type1 >
tmp< Field< Type1 > >	patchInternalField (const Field< Type1 > &iF, const labelList &meshPoints) const
	Return field created from selected internal field values. More...

template<class Type1 >
void	addToInternalField (Field< Type1 > &iF, const Field< Type1 > &pF) const
	Given the internal field and a patch field,. More...

template<class Type1 >
void	addToInternalField (Field< Type1 > &iF, const Field< Type1 > &pF, const labelList &points) const
	Given the internal field and a patch field,. More...

template<class Type1 >
void	setInternalField (Field< Type1 > &iF, const Field< Type1 > &pF, const labelList &meshPoints) const
	Given the internal field and a patch field,. More...

template<class Type1 >
void	setInternalField (Field< Type1 > &iF, const Field< Type1 > &pF) const
	Given the internal field and a patch field,. More...

virtual void	map (const pointPatchField< Type > &, const pointPatchFieldMapper &)
	Map the given pointPatchField onto this pointPatchField. More...

virtual void	reset (const pointPatchField< Type > &)
	Reset the pointPatchField to the given pointPatchField. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

virtual void	initEvaluate (const Pstream::commsTypes commsType=Pstream::commsTypes::blocking)
	Initialise evaluation of the patch field (do nothing) More...

virtual void	write (Ostream &) const
	Write. More...

virtual void	operator= (const pointPatchField< Type > &)

virtual void	operator= (pointPatchField< Type > &&)

virtual void	operator+= (const pointPatchField< Type > &)

virtual void	operator-= (const pointPatchField< Type > &)

virtual void	operator*= (const pointPatchField< scalar > &)

virtual void	operator/= (const pointPatchField< scalar > &)

virtual void	operator= (const Field< Type > &)

virtual void	operator+= (const Field< Type > &)

virtual void	operator-= (const Field< Type > &)

virtual void	operator*= (const Field< scalar > &)

virtual void	operator/= (const Field< scalar > &)

virtual void	operator= (const Type &)

virtual void	operator+= (const Type &)

virtual void	operator-= (const Type &)

virtual void	operator*= (const scalar)

virtual void	operator/= (const scalar)

virtual void	operator== (const pointPatchField< Type > &)

virtual void	operator== (const Field< Type > &)

virtual void	operator== (const Type &)

template<class Type2 >
Foam::autoPtr< Foam::pointPatchField< Type > >	NewCalculatedType (const pointPatchField< Type2 > &pf)

template<class Type1 >
Foam::tmp< Foam::Field< Type1 > >	patchInternalField (const Field< Type1 > &iF, const labelList &meshPoints) const

template<class Type1 >
Foam::tmp< Foam::Field< Type1 > >	patchInternalField (const Field< Type1 > &iF) const

Additional Inherited Members
Public Types inherited from pointPatchField< Type >
typedef Type	value_type

typedef pointPatch	Patch

typedef calculatedPointPatchField< Type >	Calculated

Static Public Member Functions inherited from pointPatchField< Type >
static autoPtr< pointPatchField< Type > >	New (const word &, const pointPatch &, const DimensionedField< Type, pointMesh > &)
	Return a pointer to a new patchField created on freestore given. More...

static autoPtr< pointPatchField< Type > >	New (const word &, const word &actualPatchType, const pointPatch &, const DimensionedField< Type, pointMesh > &)
	Return a pointer to a new patchField created on freestore given. More...

static autoPtr< pointPatchField< Type > >	New (const pointPatchField< Type > &, const pointPatch &, const DimensionedField< Type, pointMesh > &, const pointPatchFieldMapper &)
	Return a pointer to a new patchField created on freestore from. More...

static autoPtr< pointPatchField< Type > >	New (const pointPatch &, const DimensionedField< Type, pointMesh > &, const dictionary &)
	Return a pointer to a new patchField created on freestore. More...

template<class Type2 >
static autoPtr< pointPatchField< Type > >	NewCalculatedType (const pointPatchField< Type2 > &)
	Return a pointer to a new calculatedPointPatchField created on. More...

static const word &	calculatedType ()
	Return the type of the calculated form of pointPatchField. More...

Static Public Attributes inherited from pointPatchField< Type >
static int	disallowGenericPointPatchField
	Debug switch to disallow the use of genericPointPatchField. More...

Detailed Description

template<class Type>
class Foam::cyclicPointPatchField< Type >

Cyclic front and back plane patch field.

Source files

Definition at line 50 of file cyclicPointPatchField.H.

Constructor & Destructor Documentation

◆ cyclicPointPatchField() [1/4]

cyclicPointPatchField	(	const pointPatch &	p,
		const DimensionedField< Type, pointMesh > &	iF
	)

Construct from patch and internal field.

Definition at line 34 of file cyclicPointPatchField.C.

◆ cyclicPointPatchField() [2/4]

cyclicPointPatchField	(	const pointPatch &	p,
		const DimensionedField< Type, pointMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 46 of file cyclicPointPatchField.C.

References dict, Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, pointPatch::index(), p, and pointPatchField< Type >::patch().

Here is the call graph for this function:

◆ cyclicPointPatchField() [3/4]

cyclicPointPatchField	(	const cyclicPointPatchField< Type > &	ptf,
		const pointPatch &	p,
		const DimensionedField< Type, pointMesh > &	iF,
		const pointPatchFieldMapper &	mapper
	)
