Base-class for all Xi models used by the b-Xi combustion model. See Technical Report SH/RE/01R for details on the PDR modelling. More...

Inheritance diagram for XiModel:

[legend]

Collaboration diagram for XiModel:

[legend]

Public Member Functions
	TypeName ("XiModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, XiModel, dictionary,(const dictionary &XiProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su, const volScalarField &rho, const volScalarField &b, const surfaceScalarField &phi),(XiProperties, thermo, turbulence, Su, rho, b, phi))

	XiModel (const dictionary &XiProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su, const volScalarField &rho, const volScalarField &b, const surfaceScalarField &phi)
	Construct from components. More...

	XiModel (const XiModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~XiModel ()
	Destructor. More...

virtual const volScalarField &	Xi () const
	Return the flame-wrinkling Xi. More...

virtual tmp< volScalarField >	Db () const
	Return the flame diffusivity. More...

virtual void	addXi (multivariateSurfaceInterpolationScheme< scalar >::fieldTable &)
	Add Xi to the multivariateSurfaceInterpolationScheme table. More...

virtual void	correct ()=0
	Correct the flame-wrinkling Xi. More...

virtual void	correct (const fv::convectionScheme< scalar > &)
	Correct the flame-wrinkling Xi using the given convection scheme. More...

virtual bool	read (const dictionary &XiProperties)=0
	Update properties from given dictionary. More...

virtual void	writeFields ()=0
	Write fields related to Xi model. More...

void	operator= (const XiModel &)=delete
	Disallow default bitwise assignment. More...

Static Public Member Functions
static autoPtr< XiModel >	New (const dictionary &XiProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su, const volScalarField &rho, const volScalarField &b, const surfaceScalarField &phi)
	Return a reference to the selected Xi model. More...

Protected Attributes
dictionary	XiModelCoeffs_

const psiuMulticomponentThermo &	thermo_

const compressible::RASModel &	turbulence_

const volScalarField &	Su_

const volScalarField &	rho_

const volScalarField &	b_

const surfaceScalarField &	phi_

volScalarField	Xi_
	Flame wrinkling field. More...

Detailed Description

Base-class for all Xi models used by the b-Xi combustion model. See Technical Report SH/RE/01R for details on the PDR modelling.

Xi is given through an algebraic expression (algebraic.H), by solving a transport equation (transport.H) or a fixed value (fixed.H).

See report TR/HGW/10 for details on the Weller two equations model.

In the algebraic and transport methods $\Xi_{eq}$ is calculated in similar way. In the algebraic approach, $\Xi_{eq}$ is the value used in the transport equation.

$\Xi_{eq}$ is calculated as follows:

$\Xi_{eq} = 1 + (1 + 2\Xi_{coeff}(0.5 - \dwea{b}))(\Xi^* - 1)$

where:

$\dwea{b}$ is the regress variable.

$\Xi_{coeff}$ is a model constant.

$\Xi^*$ is the total equilibrium wrinkling combining the effects of the flame instability and turbulence interaction and is given by

$\Xi^* = \frac {R}{R - G_\eta - G_{in}}$

where:

$G_\eta$ is the generation rate of wrinkling due to turbulence interaction.

$G_{in} = \kappa \rho_{u}/\rho_{b}$ is the generation rate due to the flame instability.

By adding the removal rates of the two effects:

$R = G_\eta \frac{\Xi_{\eta_{eq}}}{\Xi_{\eta_{eq}} - 1} + G_{in} \frac{\Xi_{{in}_{eq}}}{\Xi_{{in}_{eq}} - 1}$

where:

is the total removal.

$G_\eta$ is a model constant.

$\Xi_{\eta_{eq}}$ is the flame wrinkling due to turbulence.

$\Xi_{{in}_{eq}}$ is the equilibrium level of the flame wrinkling generated by instability. It is a constant (default 2.5).

Source files

Definition at line 108 of file XiModel.H.

Constructor & Destructor Documentation

◆ XiModel() [1/2]

XiModel	(	const dictionary &	XiProperties,
		const psiuMulticomponentThermo &	thermo,
		const compressible::RASModel &	turbulence,
		const volScalarField &	Su,
		const volScalarField &	rho,
		const volScalarField &	b,
		const surfaceScalarField &	phi
	)

Construct from components.

Definition at line 39 of file XiModel.C.

◆ XiModel() [2/2]

XiModel ( const XiModel & )

delete

Disallow default bitwise copy construction.

◆ ~XiModel()

~XiModel ( )

virtual

Destructor.

Definition at line 80 of file XiModel.C.

Member Function Documentation

◆ TypeName()

TypeName ( "XiModel" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	autoPtr	,
		XiModel	,
		dictionary	,
		(const dictionary &XiProperties, const psiuMulticomponentThermo &thermo, const compressible::RASModel &turbulence, const volScalarField &Su, const volScalarField &rho, const volScalarField &b, const surfaceScalarField &phi)	,
		(XiProperties, thermo, turbulence, Su, rho, b, phi)
	)

◆ New()

Foam::autoPtr< Foam::XiModel > New	(	const dictionary &	XiProperties,
		const psiuMulticomponentThermo &	thermo,
		const compressible::RASModel &	turbulence,
		const volScalarField &	Su,
		const volScalarField &	rho,
		const volScalarField &	b,
		const surfaceScalarField &	phi
	)
