This boundary condition provides a turbulence stress normal to streamlines wall function condition for low- and high-Reynolds number, turbulent flow cases. More...

Inheritance diagram for v2WallFunctionFvPatchScalarField:

[legend]

Collaboration diagram for v2WallFunctionFvPatchScalarField:

[legend]

Public Member Functions
	TypeName ("v2WallFunction")
	Runtime type information. More...

	v2WallFunctionFvPatchScalarField (const fvPatch &, const DimensionedField< scalar, fvMesh > &, const dictionary &)
	Construct from patch, internal field and dictionary. More...

	v2WallFunctionFvPatchScalarField (const v2WallFunctionFvPatchScalarField &, const fvPatch &, const DimensionedField< scalar, fvMesh > &, const fieldMapper &)
	Construct by mapping given v2WallFunctionFvPatchScalarField. More...

	v2WallFunctionFvPatchScalarField (const v2WallFunctionFvPatchScalarField &)=delete
	Disallow copy without setting internal field reference. More...

	v2WallFunctionFvPatchScalarField (const v2WallFunctionFvPatchScalarField &, const DimensionedField< scalar, fvMesh > &)
	Copy constructor setting internal field reference. More...

virtual tmp< fvPatchScalarField >	clone (const DimensionedField< scalar, fvMesh > &iF) const
	Construct and return a clone setting internal field reference. More...

virtual void	updateCoeffs ()
	Update the coefficients associated with the patch field. More...

Detailed Description

This boundary condition provides a turbulence stress normal to streamlines wall function condition for low- and high-Reynolds number, turbulent flow cases.

The model operates in two modes, based on the computed laminar-to-turbulent switch-over y+ value derived from kappa and E specified in the corresponding nutWallFunction.

Usage

Example of the boundary condition specification:

<patchName>
{
    type            v2WallFunction;
}

See also: Foam::fixedValueFvPatchField

Source files

Definition at line 69 of file v2WallFunctionFvPatchScalarField.H.

Constructor & Destructor Documentation

◆ v2WallFunctionFvPatchScalarField() [1/4]

v2WallFunctionFvPatchScalarField	(	const fvPatch &	p,
		const DimensionedField< scalar, fvMesh > &	iF,
		const dictionary &	dict
	)

Construct from patch, internal field and dictionary.

Definition at line 40 of file v2WallFunctionFvPatchScalarField.C.

Referenced by v2WallFunctionFvPatchScalarField::clone().

Here is the caller graph for this function:

◆ v2WallFunctionFvPatchScalarField() [2/4]

v2WallFunctionFvPatchScalarField	(	const v2WallFunctionFvPatchScalarField &	ptf,
		const fvPatch &	p,
		const DimensionedField< scalar, fvMesh > &	iF,
		const fieldMapper &	mapper
	)

Construct by mapping given v2WallFunctionFvPatchScalarField.

onto a new patch

Definition at line 51 of file v2WallFunctionFvPatchScalarField.C.

◆ v2WallFunctionFvPatchScalarField() [3/4]

v2WallFunctionFvPatchScalarField ( const v2WallFunctionFvPatchScalarField & )

delete

Disallow copy without setting internal field reference.

◆ v2WallFunctionFvPatchScalarField() [4/4]

v2WallFunctionFvPatchScalarField	(	const v2WallFunctionFvPatchScalarField &	v2wfpsf,
		const DimensionedField< scalar, fvMesh > &	iF
	)

Copy constructor setting internal field reference.

Definition at line 63 of file v2WallFunctionFvPatchScalarField.C.

Member Function Documentation

◆ TypeName()

TypeName ( "v2WallFunction" )

Runtime type information.

◆ clone()

virtual tmp<fvPatchScalarField> clone ( const DimensionedField< scalar, fvMesh > & iF ) const

inlinevirtual

Construct and return a clone setting internal field reference.

Definition at line 114 of file v2WallFunctionFvPatchScalarField.H.

References v2WallFunctionFvPatchScalarField::v2WallFunctionFvPatchScalarField().

Here is the call graph for this function:

◆ updateCoeffs()

void updateCoeffs ( )

virtual

Update the coefficients associated with the patch field.

Definition at line 75 of file v2WallFunctionFvPatchScalarField.C.

References forAll, k, momentumTransportModel::k(), Foam::log(), momentumTransportModel::nu(), nutWallFunctionFvPatchScalarField::nutw(), patchi, Foam::pow025(), Foam::pow4(), Foam::sqr(), Foam::sqrt(), uTau, y, momentumTransportModel::yb(), and yPlus.
