This source condition creates an interfacial mass transfer source term in the group surface-area-to-volume-ratio (kappa) equations of the fractal shape model of a population balance model, according to the model of Park and Rogak. More...
Public Member Functions | |
| TypeName ("ParkRogakGroupSurfaceAreaVolumeRatio") | |
| Runtime type information. More... | |
| virtual autoPtr< fvScalarFieldSource > | clone (const DimensionedField< scalar, fvMesh > &iF) const |
| Construct and return a clone setting internal field reference. More... | |
| virtual tmp< DimensionedField< scalar, fvMesh > > | value (const label j, const fvSource &model) const |
| Return the value transported from an adjacent group. More... | |
 Public Member Functions inherited from growthSecondaryPropertyFvScalarFieldSource | |
| growthSecondaryPropertyFvScalarFieldSource (const DimensionedField< scalar, fvMesh > &, const dictionary &dict) | |
| Construct from internal field and dictionary. More... | |
| growthSecondaryPropertyFvScalarFieldSource (const growthSecondaryPropertyFvScalarFieldSource &, const DimensionedField< scalar, fvMesh > &) | |
| Copy constructor setting internal field reference. More... | |
| virtual tmp< DimensionedField< scalar, fvMesh > > | internalCoeff (const fvSource &model, const DimensionedField< scalar, fvMesh > &source) const |
| Return the internal coefficient. More... | |
| virtual Pair< tmp< DimensionedField< scalar, fvMesh > > > | sourceCoeffs (const fvSource &model) const |
| Return the source coefficients for exchange with the groups below. More... | |
| virtual tmp< DimensionedField< scalar, fvMesh > > | sourceCoeff (const fvSource &model, const DimensionedField< scalar, fvMesh > &source) const |
| Return the combined source coefficient. More... | |
| Public Member Functions inherited from growthFvScalarFieldSource | |
| virtual tmp< DimensionedField< scalar, fvMesh > > | sourceValue (const fvSource &model, const DimensionedField< scalar, fvMesh > &source) const |
| Return the source value. Not Implemented. More... | |
| Public Member Functions inherited from groupPropertyFvScalarField | |
| groupPropertyFvScalarField (const DimensionedField< scalar, fvMesh > &) | |
| Construct from internal field. More... | |
| const populationBalanceModel & | popBal () const |
| Return the population balance. More... | |
| label | i () const |
| Return the index of this group. More... | |
This source condition creates an interfacial mass transfer source term in the group surface-area-to-volume-ratio (kappa) equations of the fractal shape model of a population balance model, according to the model of Park and Rogak.
Reference:
Park, S. H., & Rogak, S. N. (2004).
A novel fixed-sectional model for the formation and growth of aerosol
agglomerates.
Journal of Aerosol Science, 35(11), 1385-1404.
\endbverbatim
\par Usage
Example of the source condition specification:
\verbatim
<sourceName>
{
type ParkRogakGroupSurfaceAreaVolumeRatio;
libs ("libmultiphaseEulerFvModels.so");
}
Definition at line 69 of file ParkRogakGroupSurfaceAreaVolumeRatioFvScalarFieldSource.H.
| TypeName | ( | "ParkRogakGroupSurfaceAreaVolumeRatio" | ) |
Runtime type information.
|
inlinevirtual |
Construct and return a clone setting internal field reference.
Definition at line 87 of file ParkRogakGroupSurfaceAreaVolumeRatioFvScalarFieldSource.H.
|
virtual |
Return the value transported from an adjacent group.
Implements growthSecondaryPropertyFvScalarFieldSource.
Definition at line 33 of file ParkRogakGroupSurfaceAreaVolumeRatioFvScalarFieldSource.C.
References fractal::alphaC(), fractal::d(), fractal::Df(), fractal::fld(), groupPropertyFvScalarField::i(), Foam::constant::mathematical::pi(), groupPropertyFvScalarField::popBal(), Foam::pow(), Foam::pow3(), populationBalanceModel::shape(), Foam::sqr(), and populationBalanceModel::v().
