PCICG< Type, DType, LUType > Class Template Reference

Preconditioned conjugate gradient solver for symmetric lduMatrices using a run-time selectable preconditioner. More...

Inheritance diagram for PCICG< Type, DType, LUType >:
Collaboration diagram for PCICG< Type, DType, LUType >:

Public Member Functions

 TypeName ("PCICG")
 Runtime type information. More...

 PCICG (const word &fieldName, const LduMatrix< Type, DType, LUType > &matrix, const dictionary &solverDict)
 Construct from matrix components and solver data dictionary. More...

 PCICG (const PCICG &)=delete
 Disallow default bitwise copy construction. More...

virtual ~PCICG ()

virtual SolverPerformance< Type > solve (Field< Type > &psi) const
 Solve the matrix with this solver. More...

void operator= (const PCICG &)=delete
 Disallow default bitwise assignment. More...

- Public Member Functions inherited from LduMatrix< Type, DType, LUType >::solver
virtual const wordtype () const =0
 Runtime type information. More...

 declareRunTimeSelectionTable (autoPtr, solver, symMatrix,(const word &fieldName, const LduMatrix< Type, DType, LUType > &matrix, const dictionary &solverDict),(fieldName, matrix, solverDict))

 declareRunTimeSelectionTable (autoPtr, solver, asymMatrix,(const word &fieldName, const LduMatrix< Type, DType, LUType > &matrix, const dictionary &solverDict),(fieldName, matrix, solverDict))

 solver (const word &fieldName, const LduMatrix< Type, DType, LUType > &matrix, const dictionary &solverDict)

virtual ~solver ()

const wordfieldName () const

const LduMatrix< Type, DType, LUType > & matrix () const

virtual void read (const dictionary &solverDict)
 Read and reset the solver parameters from the given dictionary. More...

Type normFactor (const Field< Type > &psi, const Field< Type > &Apsi, Field< Type > &tmpField) const
 Return the matrix norm used to normalise the residual for the. More...


Additional Inherited Members

- Static Public Member Functions inherited from LduMatrix< Type, DType, LUType >::solver
static autoPtr< solverNew (const word &fieldName, const LduMatrix< Type, DType, LUType > &matrix, const dictionary &solverDict)
 Return a new solver. More...

- Protected Member Functions inherited from LduMatrix< Type, DType, LUType >::solver
template<class T >
void readControl (const dictionary &controlDict, T &control, const word &controlName)
 Read a control parameter from controlDict. More...

virtual void readControls ()
 Read the control parameters from the controlDict_. More...

- Protected Attributes inherited from LduMatrix< Type, DType, LUType >::solver
word fieldName_

const LduMatrix< Type, DType, LUType > & matrix_

dictionary controlDict_
 Dictionary of controls. More...

label maxIter_
 Maximum number of iterations in the solver. More...

label minIter_
 Minimum number of iterations in the solver. More...

Type tolerance_
 Final convergence tolerance. More...

Type relTol_
 Convergence tolerance relative to the initial. More...

- Static Protected Attributes inherited from LduMatrix< Type, DType, LUType >::solver
static const label defaultMaxIter_ = 1000
 Default maximum number of iterations in the solver. More...


Detailed Description

template<class Type, class DType, class LUType>
class Foam::PCICG< Type, DType, LUType >

Preconditioned conjugate gradient solver for symmetric lduMatrices using a run-time selectable preconditioner.

Source files

Definition at line 50 of file PCICG.H.

Constructor & Destructor Documentation

◆ PCICG() [1/2]

PCICG ( const word fieldName,
const LduMatrix< Type, DType, LUType > &  matrix,
const dictionary solverDict
)

Construct from matrix components and solver data dictionary.

Definition at line 31 of file PCICG.C.

◆ PCICG() [2/2]

PCICG ( const PCICG< Type, DType, LUType > &  )
delete

Disallow default bitwise copy construction.

◆ ~PCICG()

virtual ~PCICG ( )
inlinevirtual

Definition at line 77 of file PCICG.H.

Member Function Documentation

◆ TypeName()

TypeName ( "PCICG< Type, DType, LUType >"  )

Runtime type information.

◆ solve()

◆ operator=()

void operator= ( const PCICG< Type, DType, LUType > &  )
delete

Disallow default bitwise assignment.


The documentation for this class was generated from the following files:
