Manual injection model. This injects particles instantaneously at a list of positions specified in a separate file. More...

Inheritance diagram for manualInjection:

[legend]

Collaboration diagram for manualInjection:

[legend]

Public Member Functions
	TypeName ("manualInjection")
	Runtime type information. More...

	manualInjection (const word &name, const LagrangianMesh &mesh, const dictionary &modelDict, const dictionary &stateDict)
	Construct from components. More...

LagrangianSubMesh	modify (LagrangianMesh &mesh, const LagrangianSubMesh &) const
	Create new elements in the Lagrangian mesh. More...

virtual bool	read (const dictionary &modelDict)
	Read dictionary. More...

Public Member Functions inherited from LagrangianInjection
	TypeName ("LagrangianInjection")
	Runtime type information. More...

	LagrangianInjection (const word &name, const LagrangianMesh &mesh)
	Construct from components. More...

virtual	~LagrangianInjection ()
	Destructor. More...

virtual bool	addsSupToField (const word &fieldName, const word &eqnFieldName) const
	Return true if the LagrangianModel adds a source term to the. More...

Public Member Functions inherited from LagrangianModel
	TypeName ("LagrangianModel")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, LagrangianModel, dictionary,(const word &name, const LagrangianMesh &mesh, const dictionary &modelDict, const dictionary &stateDict),(name, mesh, modelDict, stateDict))
	Declare run-time constructor selection table. More...

	LagrangianModel (const word &name, const LagrangianMesh &mesh)
	Construct from components. More...

	LagrangianModel (const LagrangianModel &)=delete
	Disallow default bitwise copy construction. More...

autoPtr< LagrangianModel >	clone () const
	Clone. More...

virtual	~LagrangianModel ()
	Destructor. More...

const word &	name () const
	The source name. More...

const objectRegistry &	db () const
	The database. More...

const Time &	time () const
	Return time. More...

const LagrangianMesh &	mesh () const
	The mesh. More...

virtual wordList	addSupFields () const
	Return the list of fields for which the LagrangianModel adds. More...

template<class Type , template< class > class PrimitiveField, template< class > class PrimitiveEqnField>
bool	addsSupToField (const LagrangianSubField< Type, PrimitiveField > &field, const LagrangianSubField< Type, PrimitiveEqnField > &eqnfield) const
	Return true if the LagrangianModels adds a source term to the. More...

virtual void	postConstruct ()
	Do post construction steps which require access to other models. More...

virtual void	correct ()
	Correct the LagrangianModel. More...

virtual void	preModify (const LagrangianMesh &mesh, DynamicList< elementModification > &elementModifications) const
	Identify elements in the Lagrangian mesh which are to be. More...

virtual void	calculate (const LagrangianSubScalarField &deltaT, const bool final)
	Solve equations and/or update continually changing properties. More...

virtual void	preAddSup (const LagrangianSubScalarField &deltaT, const bool final)
	Hook before source evaluation. More...

virtual void	addSup (const LagrangianSubScalarField &deltaT, LagrangianEqn< scalar > &eqn) const
	Add a fractional source term. More...

virtual void	postAddSup (const LagrangianSubScalarField &deltaT, const bool final)
	Add a source term to an equation. More...

virtual void	topoChange (const polyTopoChangeMap &)
	Update topology using the given map. More...

virtual void	mapMesh (const polyMeshMap &)
	Update from another mesh using the given map. More...

virtual void	distribute (const polyDistributionMap &)
	Redistribute or update using the given distribution map. More...

virtual bool	write (const bool write) const
	Write data. More...

void	operator= (const LagrangianModel &)=delete
	Disallow default bitwise assignment. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::word	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class Type , class GeoMesh , template< class > class PrimitiveField>
const Foam::word &	fieldName (const GeometricField< Type, GeoMesh, PrimitiveField > &field)

template<class Type , class GeoMesh , template< class > class PrimitiveField>
const Foam::word &	fieldName (const DimensionedField< Type, GeoMesh, PrimitiveField > &field)

template<class Type , template< class > class PrimitiveField>
Foam::word	fieldName (const DimensionedField< Type, LagrangianSubMesh, PrimitiveField > &field)

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
Foam::word	fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)

template<class AlphaRhoFieldType >
Foam::word	fieldsName (const AlphaRhoFieldType &alphaRhoField)

Public Member Functions inherited from stateModel
	stateModel ()
	Construct null. More...

	stateModel (const stateModel &)=delete
	Disallow default bitwise copy construction. More...

virtual	~stateModel ()
	Destructor. More...

bool	writeState (const bool write) const
	Write state. More...

virtual void	writeState (Ostream &os) const
	Write state. More...

virtual void	writeProcessorState (Ostream &os) const
	Write processor state. More...

void	operator= (const stateModel &)=delete
	Disallow default bitwise assignment. More...

Additional Inherited Members
Public Types inherited from LagrangianModel
enum class	modification : label { change = 0 , remove = 1 }
	Enumeration of the types of instantaneous modification. More...

typedef LagrangianMesh::elementGroup< modification >	elementModification
	Class containing an element-index and a modification-enumeration. More...

Static Public Member Functions inherited from LagrangianModel
template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static word	fieldName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the field associated with a source term. More...

template<class Type , class GeoMesh , template< class > class PrimitiveField>
static const word &	fieldName (const GeometricField< Type, GeoMesh, PrimitiveField > &)
	Return the name of the field associated with a source term (base. More...

template<class Type , class GeoMesh , template< class > class PrimitiveField>
static const word &	fieldName (const DimensionedField< Type, GeoMesh, PrimitiveField > &)
	Return the name of the field associated with a source term (base. More...

template<class Type , template< class > class PrimitiveField>
static word	fieldName (const DimensionedField< Type, LagrangianSubMesh, PrimitiveField > &)
	Return the name of the field associated with a source term (base. More...

template<class AlphaRhoFieldType , class ... AlphaRhoFieldTypes>
static word	fieldsName (const AlphaRhoFieldType &alphaRhoField, const AlphaRhoFieldTypes &... alphaRhoFields)
	Return the name of the product of the fields associated with a. More...

template<class AlphaRhoFieldType >
static word	fieldsName (const AlphaRhoFieldType &alphaRhoField)
	Return the name of the product of the fields associated with a. More...

static autoPtr< LagrangianModel >	New (const word &name, const LagrangianMesh &mesh, const dictionary &modelDict)
	Selector. More...

Static Public Member Functions inherited from stateModel
static dictionary	stateDict (const word &name, const objectRegistry &db)
	Construct and return the state dictionary for reading. More...

Protected Member Functions inherited from LagrangianInjection
void	checkLocation (const LagrangianMesh::location, const point &) const
	Check the location and error or warn as appropriate. More...

void	checkLocation (const List< LagrangianMesh::location > &, const List< point > &) const
	Check the locations and error or warn as appropriate. More...

Protected Member Functions inherited from LagrangianModel
template<class Type >
void	addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const
	Add a source term to an equation. More...

template<class Type >
void	addSupType (const LagrangianSubScalarField &deltaT, const LagrangianSubScalarSubField &vOrM, const LagrangianSubSubField< Type > &field, LagrangianEqn< Type > &eqn) const
	Add a source term to a volume or mass-weighted equation. More...

Static Protected Member Functions inherited from LagrangianInjection
template<class ... OtherFields>
static void	filter (barycentricField &coordinates, labelField &celli, labelField &facei, labelField &faceTrii, OtherFields &... otherFields)
	Filter out injected elements that are on other processes. These. More...

Detailed Description

Manual injection model. This injects particles instantaneously at a list of positions specified in a separate file.

Usage

Property	Description	Required?	Default
`positions`	Positions at which to inject	if file not specified
`file`	File containing the positions	if positions not specified
`units`	Units of the positions in the file	if file specified	[m]
`time`	The time at which to inject	no	0

Example specification:

    <LagrangianModelName>
    {
        type        manualInjection;
        positions   ((0 0 0) (1 1 1) (2 2 2)) [m];
        time        1.23 [s];
    }

Example specification with positions in a file:

    <LagrangianModelName>
    {
        type        manualInjection;
        file        "manualInjectionPositions";
        units       [mm];
    }

Source files

Definition at line 105 of file manualInjection.H.

Constructor & Destructor Documentation

◆ manualInjection()

manualInjection	(	const word &	name,
		const LagrangianMesh &	mesh,
		const dictionary &	modelDict,
		const dictionary &	stateDict
	)

Construct from components.

Definition at line 90 of file manualInjection.C.

Member Function Documentation

◆ TypeName()

TypeName ( "manualInjection" )

Runtime type information.

◆ modify()

Foam::LagrangianSubMesh modify	(	LagrangianMesh &	mesh,
		const LagrangianSubMesh &
	)		const

virtual

Create new elements in the Lagrangian mesh.

Reimplemented from LagrangianModel.

Definition at line 110 of file manualInjection.C.

References TimePaths::constant(), Foam::tracking::coordinates(), TimeState::deltaT(), Foam::units::fraction, LagrangianMesh::fractionName, mesh, IOobject::MUST_READ, IOobject::NO_WRITE, fileName::null, tmp< T >::ref(), List< T >::size(), fvMesh::time(), and dimensioned< Type >::value().

Here is the call graph for this function:

◆ read()

bool read ( const dictionary & modelDict )

virtual

Read dictionary.

Reimplemented from LagrangianModel.

Definition at line 188 of file manualInjection.C.

References LagrangianModel::read().
