Abstract base class for Lagrangian ddt schemes. More...

Inheritance diagram for ddtScheme< Type >:

[legend]

Collaboration diagram for ddtScheme< Type >:

Public Member Functions
	TypeName ("ddtScheme")
	Runtime type information. More...

	declareRunTimeSelectionTable (tmp, ddtScheme, Istream,(const LagrangianMesh &mesh, Istream &is),(mesh, is))
	Declare run-time constructor selection tables. More...

	ddtScheme (const LagrangianMesh &mesh)
	Construct from a mesh. More...

	ddtScheme (const LagrangianMesh &mesh, Istream &)
	Construct from a mesh and a stream. More...

	ddtScheme (const ddtScheme &)=delete
	Disallow default bitwise copy construction. More...

virtual	~ddtScheme ()
	Destructor. More...

const LagrangianMesh &	mesh () const
	Return mesh reference. More...

virtual bool	LagrangianmInitDdt (const dimensionSet &mDims, const LagrangianSubSubField< Type > &psi, const bool instantaneousDdt)=0
	Initialise time-derivative information. Registers fields used to. More...

virtual tmp< LagrangianEqn< Type > >	LagrangianmNoDdt (const LagrangianSubScalarField &deltaT, const dimensionSet &mDims, const LagrangianSubSubField< Type > &psi)=0
	Return the no-time-derivative matrix containing higher-order. More...

virtual tmp< LagrangianEqn< Type > >	LagrangianmDdt (const LagrangianSubScalarField &deltaT, LagrangianSubSubField< Type > &psi)=0
	Return the time-derivative matrix. More...

virtual tmp< LagrangianEqn< Type > >	LagrangianmDdt (const LagrangianSubScalarField &deltaT, const LagrangianSubScalarSubField &m, LagrangianSubSubField< Type > &psi)=0
	Return the time-derivative matrix. More...

virtual tmp< LagrangianSubField< Type > >	LagrangiancDdt (const LagrangianSubSubField< Type > &psi)=0
	Return the instantaneous time-derivative. More...

virtual tmp< LagrangianSubField< Type > >	LagrangiancDdt (const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &psi)=0
	Return the instantaneous time-derivative. More...

void	operator= (const ddtScheme &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from refCount
int	count () const
	Return the current reference count. More...

bool	unique () const
	Return true if the reference count is zero. More...

void	operator++ ()
	Increment the reference count. More...

void	operator++ (int)
	Increment the reference count. More...

void	operator-- ()
	Decrement the reference count. More...

void	operator-- (int)
	Decrement the reference count. More...

void	operator= (const refCount &)=delete
	Disallow bitwise assignment. More...

Static Public Member Functions
static tmp< ddtScheme< Type > >	New (const LagrangianMesh &mesh, Istream &is)
	Return a pointer to a new ddtScheme. More...

static tmp< LagrangianEqn< Type > >	Lagrangianmddt (const LagrangianSubSubField< Type > &psi)
	Return a Euler implicit time derivative matrix. More...

static tmp< LagrangianEqn< Type > >	Lagrangianmddt (const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &psi)
	Return a Euler implicit time derivative matrix. More...

static tmp< LagrangianEqn< Type > >	Lagrangianmddt0 (const LagrangianSubSubField< Type > &psi)
	Return a Euler explicit/forward time-derivative matrix. More...

static tmp< LagrangianEqn< Type > >	Lagrangianmddt0 (const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &psi)
	Return a Euler explicit/forward time-derivative matrix. More...

static tmp< LagrangianSubField< Type > >	LagrangiancdeltaTddt0 (const LagrangianSubSubField< Type > &psi)
	Return the Euler explicit/forward time-derivative multiplied by the. More...

static tmp< LagrangianSubField< Type > >	LagrangiancdeltaTddt0 (const LagrangianSubScalarSubField &m, const LagrangianSubSubField< Type > &psi)
	Return the Euler explicit/forward time-derivative multiplied by the. More...

Protected Attributes
const LagrangianMesh &	mesh_
	Reference to the mesh. More...

Additional Inherited Members
Protected Member Functions inherited from refCount
	refCount ()
	Construct null initialising count to 0. More...

	refCount (const refCount &)=delete
	Disallow copy. More...

Detailed Description

template<class Type>
class Foam::Lagrangian::ddtScheme< Type >

Abstract base class for Lagrangian ddt schemes.

Source files

Definition at line 62 of file LagrangianDdtScheme.H.

Constructor & Destructor Documentation

◆ ddtScheme() [1/3]

ddtScheme ( const LagrangianMesh & mesh )

inline

Construct from a mesh.

Definition at line 94 of file LagrangianDdtScheme.H.

◆ ddtScheme() [2/3]

ddtScheme	(	const LagrangianMesh &	mesh,
		Istream &
	)

inline

Construct from a mesh and a stream.

Definition at line 100 of file LagrangianDdtScheme.H.

◆ ddtScheme() [3/3]

ddtScheme ( const ddtScheme< Type > & )

delete

Disallow default bitwise copy construction.

◆ ~ddtScheme()

~ddtScheme

virtual

Destructor.

Definition at line 69 of file LagrangianDdtScheme.C.

Member Function Documentation

◆ TypeName()

TypeName ( "ddtScheme< Type >" )

Runtime type information.

◆ declareRunTimeSelectionTable()

declareRunTimeSelectionTable	(	tmp	,
		ddtScheme< Type >	,
		Istream	,
		(const LagrangianMesh &mesh, Istream &is)	,
		(mesh, is)
	)

Declare run-time constructor selection tables.

◆ New()

Foam::tmp< Foam::Lagrangian::ddtScheme< Type > > New	(	const LagrangianMesh &	mesh,
		Istream &	is
	)

static

Return a pointer to a new ddtScheme.

Definition at line 33 of file LagrangianDdtScheme.C.

References Foam::endl(), Istream::eof(), Foam::exit(), Foam::FatalIOError, FatalIOErrorInFunction, mesh, and Foam::nl.

Here is the call graph for this function:

◆ mesh()

const LagrangianMesh& mesh ( ) const

inline

Return mesh reference.

Definition at line 126 of file LagrangianDdtScheme.H.

References ddtScheme< Type >::mesh_.

◆ LagrangianmInitDdt()

virtual bool LagrangianmInitDdt	(	const dimensionSet &	mDims,
		const LagrangianSubSubField< Type > &	psi,
		const bool	instantaneousDdt
	)

pure virtual

Initialise time-derivative information. Registers fields used to.

construct for higher-order schemes and to evaluate instantaneous time derivatives.

Implemented in Euler< Type >, and CrankNicolson< Type >.

◆ LagrangianmNoDdt()

virtual tmp<LagrangianEqn<Type> > LagrangianmNoDdt	(	const LagrangianSubScalarField &	deltaT,
		const dimensionSet &	mDims,
		const LagrangianSubSubField< Type > &	psi
	)

pure virtual

Return the no-time-derivative matrix containing higher-order.

modifications to source terms

Implemented in Euler< Type >, and CrankNicolson< Type >.

◆ LagrangianmDdt() [1/2]

virtual tmp<LagrangianEqn<Type> > LagrangianmDdt	(	const LagrangianSubScalarField &	deltaT,
		LagrangianSubSubField< Type > &	psi
	)

pure virtual

Return the time-derivative matrix.

Implemented in Euler< Type >, and CrankNicolson< Type >.

◆ LagrangianmDdt() [2/2]

virtual tmp<LagrangianEqn<Type> > LagrangianmDdt	(	const LagrangianSubScalarField &	deltaT,
		const LagrangianSubScalarSubField &	m,
		LagrangianSubSubField< Type > &	psi
	)

pure virtual

Return the time-derivative matrix.

Implemented in Euler< Type >, and CrankNicolson< Type >.

◆ LagrangiancDdt() [1/2]

virtual tmp<LagrangianSubField<Type> > LagrangiancDdt ( const LagrangianSubSubField< Type > & psi )

pure virtual

Return the instantaneous time-derivative.

Implemented in Euler< Type >, and CrankNicolson< Type >.

◆ LagrangiancDdt() [2/2]

virtual tmp<LagrangianSubField<Type> > LagrangiancDdt	(	const LagrangianSubScalarSubField &	m,
		const LagrangianSubSubField< Type > &	psi
	)

pure virtual

Return the instantaneous time-derivative.

Implemented in Euler< Type >, and CrankNicolson< Type >.

◆ Lagrangianmddt() [1/2]

Foam::tmp< Foam::LagrangianEqn< Type > > Lagrangianmddt ( const LagrangianSubSubField< Type > & psi )

static

Return a Euler implicit time derivative matrix.

Definition at line 77 of file LagrangianDdtScheme.C.

References psi, and tmp< T >::ref().

Here is the call graph for this function:

◆ Lagrangianmddt() [2/2]

Foam::tmp< Foam::LagrangianEqn< Type > > Lagrangianmddt	(	const LagrangianSubScalarSubField &	m,
		const LagrangianSubSubField< Type > &	psi
	)

static

Return a Euler implicit time derivative matrix.

Definition at line 93 of file LagrangianDdtScheme.C.

References OldTimeField< FieldType >::oldTime(), psi, and tmp< T >::ref().

Here is the call graph for this function:

◆ Lagrangianmddt0() [1/2]

Foam::tmp< Foam::LagrangianEqn< Type > > Lagrangianmddt0 ( const LagrangianSubSubField< Type > & psi )

static

Return a Euler explicit/forward time-derivative matrix.

Definition at line 110 of file LagrangianDdtScheme.C.

References psi, and tmp< T >::ref().

Here is the call graph for this function:

◆ Lagrangianmddt0() [2/2]

Foam::tmp< Foam::LagrangianEqn< Type > > Lagrangianmddt0	(	const LagrangianSubScalarSubField &	m,
		const LagrangianSubSubField< Type > &	psi
	)

static

Return a Euler explicit/forward time-derivative matrix.

Definition at line 125 of file LagrangianDdtScheme.C.

References OldTimeField< FieldType >::oldTime(), psi, and tmp< T >::ref().

Here is the call graph for this function:

◆ LagrangiancdeltaTddt0() [1/2]

Foam::tmp< Foam::LagrangianSubField< Type > > LagrangiancdeltaTddt0 ( const LagrangianSubSubField< Type > & psi )

static

Return the Euler explicit/forward time-derivative multiplied by the.

time-step

Definition at line 141 of file LagrangianDdtScheme.C.

References psi.

◆ LagrangiancdeltaTddt0() [2/2]

Foam::tmp< Foam::LagrangianSubField< Type > > LagrangiancdeltaTddt0	(	const LagrangianSubScalarSubField &	m,
		const LagrangianSubSubField< Type > &	psi
	)

static

Return the Euler explicit/forward time-derivative multiplied by the.

time-step

Definition at line 152 of file LagrangianDdtScheme.C.

References OldTimeField< FieldType >::oldTime(), and psi.

Here is the call graph for this function:

◆ operator=()

void operator= ( const ddtScheme< Type > & )

delete

Disallow default bitwise assignment.

Member Data Documentation

◆ mesh_

const LagrangianMesh& mesh_

protected

Reference to the mesh.

Definition at line 71 of file LagrangianDdtScheme.H.

Referenced by ddtScheme< Type >::mesh().

The documentation for this class was generated from the following files:

src/Lagrangian/Lagrangian/Lagrangian/LagrangianDdtSchemes/LagrangianDdtScheme/LagrangianDdtScheme.H
src/Lagrangian/Lagrangian/Lagrangian/LagrangianDdtSchemes/LagrangianDdtScheme/LagrangianDdtScheme.C
