Coded internal and patch field initialisation, evaluation and update with dimension checking. More...

Inheritance diagram for Coded< DimensionedFieldType >:

Collaboration diagram for Coded< DimensionedFieldType >:

Public Member Functions
	TypeName ("coded")
	Runtime type information. More...

	Coded (const dictionary &dict, DimensionedFieldType &field)
	Construct with dictionary to initialise given field. More...

	Coded (const Coded &dff, DimensionedFieldType &field)
	Construct a copy for the given field. More...

virtual autoPtr< DimensionedFieldFunction< DimensionedFieldType > >	clone (DimensionedFieldType &field) const
	Construct and return a clone for the specified field. More...

virtual	~Coded ()
	Destructor. More...

virtual void	evaluate ()
	Evaluate the function and set the field. More...

virtual bool	update ()
	Update the field if the function has changed and return true. More...

virtual void	write (Ostream &os) const
	Write data to dictionary stream. More...

Public Member Functions inherited from DimensionedFieldFunction< DimensionedFieldType >
	TypeName ("DimensionedFieldFunction")
	Runtime type information. More...

	declareRunTimeSelectionTable (autoPtr, DimensionedFieldFunction, dictionary,(const dictionary &dict, DimensionedFieldType &field),(dict, field))

	DimensionedFieldFunction (const dictionary &dict, DimensionedFieldType &field)
	Construct with dictionary to initialise given field. More...

	DimensionedFieldFunction (const DimensionedFieldFunction &dff, DimensionedFieldType &field)
	Construct a copy for the given field. More...

	DimensionedFieldFunction (const DimensionedFieldFunction< DimensionedFieldType > &)=delete
	Disallow default bitwise copy construction. More...

virtual autoPtr< DimensionedFieldFunction< DimensionedFieldType > >	clone () const
	Construct and return a clone for the specified field. More...

virtual	~DimensionedFieldFunction ()
	Destructor. More...

virtual void	reset ()
	Reset the field size. More...

void	operator= (const DimensionedFieldFunction< DimensionedFieldType > &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from codedBase
	TypeName ("codedBase")
	Runtime type information. More...

	codedBase (const word &name, const dictionary &dict, const wordList &codeKeys, const wordList &codeDictVars, const word &codeOptionsFileName, const wordList &compileFiles, const wordList &copyFiles, const bool reloadable=true)
	Construct from name and dictionary. More...

virtual	~codedBase ()
	Destructor. More...

bool	updateLibrary (const dictionary &dict) const
	Update library from given updated dictionary as required. More...

void	operator= (const codedBase &)=delete
	Disallow default bitwise assignment. More...

Public Member Functions inherited from dynamicCode
	ClassName ("dynamicCode")

	dynamicCode (const dictionary &contextDict, const dictionary &codeDict, const word &codeName, const word &codeDirName, const wordList &codeKeys, const wordList &codeDictVars, const word &optionsFileName, const wordList &compileFiles, const wordList &copyFiles)
	Construct from the context and code dictionaries. More...

	dynamicCode (const dictionary &contextDict, const word &codeName, const word &codeDirName, const wordList &codeKeys, const wordList &codeDictVars, const word &optionsFileName, const wordList &compileFiles, const wordList &copyFiles)
	Construct from the context dictionary also containing the code. More...

const word &	codeName () const
	Return the code-name. More...

const word &	codeSha1Name () const
	Return the unique code name. More...

fileName	libPath () const
	Library path for specified code name. More...

fileName	libRelPath () const
	Library path for specified code name relative to $FOAM_CASE. More...

HashTable< string > &	varSubstitutions ()

bool	upToDate () const
	Verify if the copied code is up-to-date, based on Make/SHA1Digest. More...

bool	copyOrCreateFiles (const bool verbose=false) const
	Copy/create files prior to compilation. More...

bool	wmakeLibso () const
	Compile a libso. More...

void *	loadLibrary (const fileName &libPath) const

void	createLibrary (const dictionary &dict, const bool masterOnlyRead=false) const

void	read (const dictionary &contextDict, const dictionary &codeDict)

void	read (const dictionary &contextDict)

void	write (Ostream &os) const
	Write the code for restart. More...

Additional Inherited Members
Static Public Member Functions inherited from DimensionedFieldFunction< DimensionedFieldType >
static autoPtr< DimensionedFieldFunction< DimensionedFieldType > >	New (const dictionary &dict, DimensionedFieldType &field)
	Select null constructed. More...

Static Public Member Functions inherited from codedBase
static word	codedName (const word &name)
	Create a coded name from the given name. More...

Static Public Member Functions inherited from dynamicCode
static word	libraryBaseName (const fileName &libPath)
	Return the library basename without leading 'lib' or trailing '.so'. More...

static fileName	resolveTemplate (const fileName &templateName)
	Resolve code-template via Foam::findConfigFile. More...

Static Public Attributes inherited from dynamicCode
static int	allowSystemOperations
	Flag if system operations are allowed. More...

Protected Attributes inherited from DimensionedFieldFunction< DimensionedFieldType >
DimensionedFieldType &	field_
	Reference to the field the function applies to. More...

Detailed Description

template<class DimensionedFieldType>
class Foam::DimensionedFieldFunctions::Coded< DimensionedFieldType >

Coded internal and patch field initialisation, evaluation and update with dimension checking.

Code can be provided for field initialisation in the evaluate function or field update (time dependent) in the update function which can call the evaluate function if appropriate. The evaluate function provides direct access to the point, cell or face centres in the C field and also time t and the field is set by assignment. If the update function changes the field updated should be set true.

Usage

To initialise the swirl velocity and set the inlet value using Foam::functionalFixedValue in the incompressibleFluid/pipeCyclic case:

internalField
{
    type        coded;

    evaluate
    #{
        field = velocity(1, 0, 0) + (C ^ rate(2, 0, 0));
    #};
}

boundaryField
{
    inlet
    {
        type           functionalFixedValue;

        value
        {
            $internalField;
        }
    }
    .
    .
    .

Source files

Definition at line 90 of file Coded_DimensionedFieldFunction.H.

Constructor & Destructor Documentation

◆ Coded() [1/2]

Coded	(	const dictionary &	dict,
		DimensionedFieldType &	field
	)

Construct with dictionary to initialise given field.

Definition at line 65 of file Coded_DimensionedFieldFunction.C.

References codedBase::codedName(), Foam::name(), Foam::typeName(), codedBase::updateLibrary(), and dynamicCode::varSubstitutions().

Here is the call graph for this function:

◆ Coded() [2/2]

Coded	(	const Coded< DimensionedFieldType > &	dff,
		DimensionedFieldType &	field
	)

Construct a copy for the given field.

Definition at line 116 of file Coded_DimensionedFieldFunction.C.

◆ ~Coded()

virtual ~Coded ( )

inlinevirtual

Destructor.

Definition at line 141 of file Coded_DimensionedFieldFunction.H.

Member Function Documentation

◆ TypeName()

TypeName ( "coded" )

Runtime type information.

◆ clone()

Foam::autoPtr< Foam::DimensionedFieldFunction< DimensionedFieldType > > clone ( DimensionedFieldType & field ) const

virtual

Construct and return a clone for the specified field.

Implements DimensionedFieldFunction< DimensionedFieldType >.

Definition at line 130 of file Coded_DimensionedFieldFunction.C.

◆ evaluate()

void evaluate

virtual

Evaluate the function and set the field.

Implements DimensionedFieldFunction< DimensionedFieldType >.

Definition at line 145 of file Coded_DimensionedFieldFunction.C.

References DimensionedFieldFunction< DimensionedFieldType >::New().

Here is the call graph for this function:

◆ update()

bool update

virtual

Update the field if the function has changed and return true.

otherwise return false

Reimplemented from DimensionedFieldFunction< DimensionedFieldType >.

Definition at line 166 of file Coded_DimensionedFieldFunction.C.

References DimensionedFieldFunction< DimensionedFieldType >::New().

Here is the call graph for this function:

◆ write()

void write ( Ostream & os ) const

virtual

Write data to dictionary stream.

Implements DimensionedFieldFunction< DimensionedFieldType >.

Definition at line 187 of file Coded_DimensionedFieldFunction.C.

References dynamicCode::write().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

src/finiteVolume/fields/DimensionedFields/DimensionedFieldFunctions/Coded/Coded_DimensionedFieldFunction.H
src/finiteVolume/fields/DimensionedFields/DimensionedFieldFunctions/Coded/Coded_DimensionedFieldFunction.C
