DSMC parcel class. More...

Inheritance diagram for DSMCParcel< ParcelType >:

Collaboration diagram for DSMCParcel< ParcelType >:

Classes
class	constantProperties
	Class to hold DSMC particle constant properties. More...

Public Types
typedef ParcelType::trackingData	trackingData
	Use base tracking data. More...

Public Member Functions
	TypeName ("DSMCParcel")
	Runtime type information. More...

	DSMCParcel (const polyMesh &mesh, const vector &position, const label celli, const vector &U, const scalar Ei, const label typeId)
	Construct from a position and a cell, searching for the rest of the. More...

	DSMCParcel (Istream &is, bool readFields=true)
	Construct from Istream. More...

virtual autoPtr< particle >	clone () const
	Construct and return a clone. More...

label	typeId () const
	Return type id. More...

const vector &	U () const
	Return const access to velocity. More...

scalar	Ei () const
	Return const access to internal energy. More...

vector &	U ()
	Return access to velocity. More...

scalar &	Ei ()
	Return access to internal energy. More...

template<class TrackCloudType >
bool	move (TrackCloudType &cloud, trackingData &td)
	Move the parcel. More...

template<class TrackCloudType >
void	hitWallPatch (TrackCloudType &, trackingData &)
	Overridable function to handle the particle hitting a wallPatch. More...

virtual void	transformProperties (const transformer &)
	Transform the physical properties of the particle. More...

Static Public Member Functions
static autoPtr< DSMCParcel >	New (Istream &is)
	Construct from Istream and return. More...

static void	readFields (Cloud< DSMCParcel< ParcelType >> &c)

static void	writeFields (const Cloud< DSMCParcel< ParcelType >> &c)

Protected Attributes
vector	U_
	Velocity of Parcel [m/s]. More...

scalar	Ei_
	Internal energy of the Parcel, covering all non-translational. More...

label	typeId_
	Parcel type id. More...

Friends
class	Cloud< ParcelType >

Ostream &	operator (Ostream &, const DSMCParcel< ParcelType > &)

Detailed Description

template<class ParcelType>
class Foam::DSMCParcel< ParcelType >

DSMC parcel class.

Source files

Definition at line 67 of file DSMCParcel.H.

Member Typedef Documentation

◆ trackingData

typedef ParcelType::trackingData trackingData

Use base tracking data.

Definition at line 130 of file DSMCParcel.H.

Constructor & Destructor Documentation

◆ DSMCParcel() [1/2]

DSMCParcel	(	const polyMesh &	mesh,
		const vector &	position,
		const label	celli,
		const vector &	U,
		const scalar	Ei,
		const label	typeId
	)

inline

Construct from a position and a cell, searching for the rest of the.

required topology

Definition at line 56 of file DSMCParcelI.H.

Referenced by DSMCParcel< ParcelType >::New().

Here is the caller graph for this function:

◆ DSMCParcel() [2/2]

DSMCParcel	(	Istream &	is,
		bool	readFields = `true`
	)

Construct from Istream.

Definition at line 43 of file DSMCParcelIO.C.

References IOstream::ASCII, IOstream::check(), DSMCParcel< ParcelType >::Ei_, IOstream::format(), Istream::read(), DSMCParcel< ParcelType >::readFields(), Foam::readLabel(), Foam::readScalar(), DSMCParcel< ParcelType >::typeId_, and DSMCParcel< ParcelType >::U_.

Here is the call graph for this function:

Member Function Documentation

◆ TypeName()

TypeName ( "DSMCParcel< ParcelType >" )

Runtime type information.

◆ clone()

virtual autoPtr<particle> clone ( ) const

inlinevirtual

Construct and return a clone.

Definition at line 176 of file DSMCParcel.H.

◆ New()

static autoPtr<DSMCParcel> New ( Istream & is )

inlinestatic

Construct from Istream and return.

Definition at line 182 of file DSMCParcel.H.

References DSMCParcel< ParcelType >::DSMCParcel().

Here is the call graph for this function:

◆ typeId()

Foam::label typeId

inline

Return type id.

Definition at line 118 of file DSMCParcelI.H.

◆ U() [1/2]

const Foam::vector & U

inline

Return const access to velocity.

Definition at line 125 of file DSMCParcelI.H.

◆ Ei() [1/2]

Foam::scalar Ei

inline

Return const access to internal energy.

Definition at line 132 of file DSMCParcelI.H.

◆ U() [2/2]

Foam::vector & U

inline

Return access to velocity.

Definition at line 139 of file DSMCParcelI.H.

◆ Ei() [2/2]

Foam::scalar & Ei

inline

Return access to internal energy.

Definition at line 146 of file DSMCParcelI.H.

◆ move()

bool move	(	TrackCloudType &	cloud,
		trackingData &	td
	)

Move the parcel.

Definition at line 33 of file DSMCParcel.C.

References Foam::meshTools::constrainDirection(), TimeState::deltaTValue(), f(), p, polyMesh::solutionD(), and objectRegistry::time().

Here is the call graph for this function:

◆ hitWallPatch()

void hitWallPatch	(	TrackCloudType &	cloud,
		trackingData &
	)

Overridable function to handle the particle hitting a wallPatch.

Definition at line 76 of file DSMCParcel.C.

References TimeState::deltaTValue(), polyPatch::faceAreas(), DSMCParcel< ParcelType >::constantProperties::internalDegreesOfFreedom(), Foam::mag(), polyPatch::magFaceAreas(), DSMCParcel< ParcelType >::constantProperties::mass(), Foam::max(), objectRegistry::time(), and polyPatch::whichFace().

Here is the call graph for this function:

◆ transformProperties()

void transformProperties ( const transformer & transform )

virtual

Transform the physical properties of the particle.

according to the given transformation tensor

Definition at line 168 of file DSMCParcel.C.

References Foam::transform(), and dimensionSet::transform.

Here is the call graph for this function:

◆ readFields()

void readFields ( Cloud< DSMCParcel< ParcelType >> & c )

static

Definition at line 74 of file DSMCParcelIO.C.

References Foam::constant::universal::c, forAllIter, IOobject::MUST_READ, p, Foam::readFields(), U, and Foam::blendedInterfacialModel::valid().

Referenced by DSMCParcel< ParcelType >::DSMCParcel().

Here is the call graph for this function:

Here is the caller graph for this function:

◆ writeFields()

void writeFields ( const Cloud< DSMCParcel< ParcelType >> & c )

static

Definition at line 107 of file DSMCParcelIO.C.

References Foam::constant::universal::c, forAllConstIter, IOobject::NO_READ, p, U, and regIOobject::write().

Here is the call graph for this function:

Friends And Related Function Documentation

◆ Cloud< ParcelType >

friend class Cloud< ParcelType >

friend

Definition at line 153 of file DSMCParcel.H.

◆ operator

Ostream& operator	(	Ostream &	,
		const DSMCParcel< ParcelType > &
	)

friend

Member Data Documentation

◆ U_

vector U_

protected

Velocity of Parcel [m/s].

Definition at line 140 of file DSMCParcel.H.

Referenced by DSMCParcel< ParcelType >::DSMCParcel().

◆ Ei_

scalar Ei_

protected

Internal energy of the Parcel, covering all non-translational.

degrees of freedom [J]

Definition at line 144 of file DSMCParcel.H.

Referenced by DSMCParcel< ParcelType >::DSMCParcel().

◆ typeId_

label typeId_

protected

Parcel type id.

Definition at line 147 of file DSMCParcel.H.

Referenced by DSMCParcel< ParcelType >::DSMCParcel().

The documentation for this class was generated from the following files:

src/lagrangian/DSMC/parcels/Templates/DSMCParcel/DSMCParcel.H
src/lagrangian/DSMC/parcels/Templates/DSMCParcel/DSMCParcel.C
src/lagrangian/DSMC/parcels/Templates/DSMCParcel/DSMCParcelI.H
src/lagrangian/DSMC/parcels/Templates/DSMCParcel/DSMCParcelIO.C
